LevelOne WBR-6000 Technical Specification page 2

I
www.level1.com one world_one brand_one level_
Technical Specification
LAN-Interface
4x 10/100 Mbps Auto-MDIX RJ-45 Port
WAN-Interface and Standards
1x 10/100 Mbps Auto-MDIX RJ-45 Port
Static-IP Address, Dynamic IP Address (DHCP Client), PPPoE,
PPTP, L2TP
Connection Scheme
Auto Connect-on-Demand/Auto-Disconnect
Auto Reconnect, Manually Connect/Disconnect
Wireless Data Transfer Rate
802.11n: 300 ~ 78 Mbps (20/40Mhz)
802.11g: 54 ~ 6 Mbps
802.11b: 11 ~ 1 Mbps
Number of Channels
Ch.1 ~ 11 USA
Ch.1 ~ 13 EU, Japan
Operating Frequency
2.4 ~ 2.4835 GHz
Antennas
3x 2dBi Fixed Antenna
Wireless Security
WEP 64/128-bit Web share key encryption
WPA, WPA2
128-bit TKIP/AES encryption
SSID Broadcast On/Off
WiFi Protect Setup (WPS) Push Button Support
Firewall
DoS Detection
NAT Firewall with SPI mode
Virtual Server
DMZ
Schedule-Based URL Filtering
Product Diagram
Internet Cable/DSL Modem
Computer
NAS
Order Information
Package Content
All mentioned brand names are registered trademarks and property of their owners. Technical specifications are subject to change without notice.
© Copyright Digital Data Communications GmbH. All Rights Reserved.
N_Max Router
WBR-6000:
300Mbps N_Max Wireless Broadband Router
WBR-6000, RJ45 Ethernet LAN Cable, Power Adapter, Router Stand,
Quick Installation Guide, CD Manual
QoS Support
User Friendly Quality of Service Interface
802.11e WMM Supported
Other Features
DDNS Supported, UPnP Supported, NTP Time Server, VPN (PPTP,
IPSec, L2TP) Pass-Through
Management
Quick Setup Wizard
Web-Based GUI for Management
Syslog Monitoring and Email Alert
Firmware Upgrade
Web-based (HTTP)
Operating Systems
Windows 2000/XP/Vista/Mac OSX/Linux
Power Adapter
DC12V / 1A
Operating Temperature
0°C ~ 40°C / 85% Humidity
Storage Temperature
-20°C ~ 70°C / 85% Humidity
Dimensions
154mm(L) * 143mm(W) * 30.5mm(H)
Certifications
CE, FCC
Standard Compliant
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
IEEE 802.11e, IEEE802.3x, IEEE 802.3u
WBR-6000
Broadband Routers and Gateways
Wireless USB
Adapter
Wireless PCI
Card
IP Camera

V3.0
