LevelOne WBR-6000 Technical Specification
LevelOne WBR-6000 Technical Specification

LevelOne WBR-6000 Technical Specification

300mbps n_max wireless broadband router
Hide thumbs Also See for WBR-6000:

Advertisement

Quick Links

300Mbps N_Max Wireless

Broadband Router

H/W Version: 3
Overview
The LevelOne N_One Wireless Broadband Router
provides users with extended network coverage
and incredibly fast wireless speeds up to 300 Mbps.
WBR-6000 supports superior performance for
notebooks or PCs equipped with the latest 802.11n
technology, and is also backward-compatible with
11b/g devices for robust and reliable transmission of
legacy wireless devices.
Stream Multimedia Applications to Multiple
Users
The N_One Broadband Router is designed with home
and small office users that want desire ultimate audio/
video streaming and gaming applications, no-latency
Internet calls (VoIP) and high-speed file sharing across
Key Features
- 3 antennas with 2T/3R MIMO Technology for wireless
data rates of up to 300Mbps
- Compliant with 802.11n wireless standard,
300Mbps*
- Backward compliant with 11b and 11g wireless
standards
- Incorporates WPA, WPA2, WEP encryption and other
advanced wireless security features
- Simple Security with WPS Push Button
- Firewall Security with DoS Prevention and Packet
Filtering
- Control your bandwidth with Quality of Service (QoS)
- Integrated 4-port Ethernet Switch
*
Theoretical throughput, actual performance depends on equipment and network conditions.

1
2
the network. In addition users can easily deploy a
home or office IP-based surveillance network thanks
to the additional bandwidth of wireless N_One
technology.
Network Security
WBR-6000 provides solid wireless network protection
with 64/128-bit WEP, WPA and WPA2 encryption.
Also, WBR-6000 provides a double firewall with NAT
and SPI firewall protection against DoS attacks and
unauthorized packet deliveries from the Internet.
Security set-up and configuration is simple to do with
the web-based easy-to-use interface.
1. LED Indicators
2. WiFi Protected
3. LAN Interface
4. WAN Interface
5. Reset Button
6. Power Port
3
4 5 6
Works Well With
WNC-0600USB
N_One Wireless USB Adapter
WCS-0010
Wireless Network Camera
WBR-6000
Setup(WPS) Button

Advertisement

loading
Need help?

Need help?

Do you have a question about the WBR-6000 and is the answer not in the manual?

Questions and answers

Summary of Contents for LevelOne WBR-6000

  • Page 1: Broadband Router

    64/128-bit WEP, WPA and WPA2 encryption. 11b/g devices for robust and reliable transmission of Also, WBR-6000 provides a double firewall with NAT legacy wireless devices. and SPI firewall protection against DoS attacks and Stream Multimedia Applications to Multiple unauthorized packet deliveries from the Internet.
  • Page 2 300Mbps N_Max Wireless Broadband Router Package Content WBR-6000, RJ45 Ethernet LAN Cable, Power Adapter, Router Stand, Quick Installation Guide, CD Manual All mentioned brand names are registered trademarks and property of their owners. Technical specifications are subject to change without notice.
