Summary of Contents for Galaxy Audio Any Spot AS-900
- Page 3 Headphone Jack. Right Channel Input Level Meter. Headphone Level Control. On/Off Switch. Left turn for output level decrease, right Press to switch on, meters will blink turn for output level increase. once. Press again to switch off. Left Channel Input Level Meter. DC Power Input Jack.
-
Page 4: Changing Batteries
Antenna. RF/Low Battery Indicator. GREEN indicates Receiver and Transmitter ON, and receiving RF. RED indicates Low Batteries. Earphone jack. Audio output control and On/Off switch Left turn for output level decrease, right turn for output level increase. Wearing the Bodypack Receiver Clip the receiver to a belt For best results, slide the receiver until the belt is pressed against the base of the clip. - Page 5 System Bodypack Receiver Frequency Range and Transmitter Audio Output Level: 100mW Output Level Sensitivity: Band: UHF Available Frequencies: CODE K1 630.2 MHZ -94dBm for 30dB SINAD, typical CODE K8 659.0 MHz Transmitter Output Level: 10dBm Image Rejection: >70dB Operating Range Under Typical Conditions Dimensions: 150' ( 3.74"...
- Page 7 5. Damage occurring during the shipment or delivery of any Galaxy Audio product to Galaxy Audio after initial delivery of the product to you. 6. Damage to any Galaxy Audio product which has been altered or on which the serial number has been effaced or removed.
