Sharkoon Quickstore Portable Manual

Hide thumbs Also See for Quickstore Portable:
Table of Contents

Advertisement

Quick Links

Download this manual
Manual

Advertisement

Table of Contents
loading

Related Manuals for Sharkoon Quickstore Portable

Summary of Contents for Sharkoon Quickstore Portable

  • Page 1 Manual...

  • Page 2: Table Of Contents

    5. Installing a SATA hard disk drive 6. The backup software 6.1 Installation 6.2 The user interface 6.2.1 The backup window (data backup) 6.2.2 The restore window (data recovery) 6.2.3 The schedule window (time schedule) 6.2.4 The setting window (configuration) QUICKSTORE PORTABLE...

  • Page 3: Features

    For a long life time and to take full advantage of this product we recommend that you read this manual completely. Have a good time with our product! SHARKOON Technologies GmbH 1. Features • Suitable for 2.5" SATA hard disk drives (9.5 mm height) •...

  • Page 4: Parts And Accessory

    Tools CD incl. backup software and extensive manual (PDF / D) Note: If you are missing any of the items listed above, please contact our customer service via e-mail at support@sharkoon.com or call: + 49 (0) 6403 – 775 6100. QUICKSTORE PORTABLE...

  • Page 5: The Device At A Glance

    (see chapter 6) A – Case cover lock – USB plug in its detent – Case cover – SATA connector (data and power) – HDD mounting bay (for one 2.5"-SATA HDD) QUICKSTORE PORTABLE...

  • Page 6: Installing A Sata Hard Disk Drive

    1. Open the case cover lock (fig. 1). fig. 1 2. Remove the case cover from the case body (fig. 2). fig. 2 3. Slide a 2.5“ SATA HDD into the HDD mounting bay (fig. 3). fig. 3 QUICKSTORE PORTABLE...
  • Page 7 6. Fold-out the USB plug from its detent (fig. 6) and connect it to a USB connector of your PC/laptop. fig. 6 The QuickStore Portable will automatically be recognized by the operating system and all required drivers will be in- stalled. The device is now ready.

  • Page 8: The Backup Software

    1. Put the includedTools CD into your CD/DVD drive. 2. In the Windows Explorer open the directory on the Tools CD “SHARKOON” with a double click (left mouse button). 3. Double click (left mouse button) “Setup.exe” , a language se- lection window will open up.
  • Page 9 The installation routine will commence (fig. 1). fig. 1 4. Confirm the copyright note in the next window (fig. 2) with “Next” or “Cancel” the installation process. fig. 2 QUICKSTORE PORTABLE...
  • Page 10 5. Click “Install” in the next window (fig. 3) to install the backup software. “Back” will bring you to the previous window, “Cancel” ends the installation process. fig. 3 6. The backup software will be installed to your system (fig. 4). fig. 4 QUICKSTORE PORTABLE...
  • Page 11 Complete the installation procedure by left clicking “Finish” (fig. 5). fig. 5 8. After finishing the installation process successfully the fol- lowing icon will appear on your desktop: To start the backup software double click (left mouse button) this icon. QUICKSTORE PORTABLE...

  • Page 12: The User Interface

    G – Backup mode: “Only backup modified files“ includes only files which have been changed since the last backup; “Delete the destination file“ erases files inside the target directory which are no longer present in the source directory. QUICKSTORE PORTABLE...
  • Page 13 Click “Close“ to close this window and return to the back- up program or left click “Log File“ to view the backup log. – Click “Save“ to save your settings (confirm the following pop-up with “Yes” or choose “No” to cancel). QUICKSTORE PORTABLE...

  • Page 14: The Restore Window (Data Recovery)

    “Restore to user defined path“ (using a custom path). G – Click „Restore“ to commence the restore procedure or “Save“ to save your settings (confirm the following pop- up with “Yes” , “No” to cancel). QUICKSTORE PORTABLE...

  • Page 15: The Schedule Window (Time Schedule)

    Decide whether the backup shall be performed daily, weekly or monthly. If you do not want to define a recur- ring date choose “None“ . – Click “Save“ to save your settings (confirm the following pop-up with “Yes” , “No” will cancel). QUICKSTORE PORTABLE...

  • Page 16: The Setting Window (Configuration)

    – Buttons for “Help” (?), “Minimize window” (_) and “Close window” (X). – Click “Save“ to save your settings (confirm the following pop-up with “Yes” , “No” will cancel). QUICKSTORE PORTABLE...
  • Page 17 All named products and descriptions are trademarks and/or registered trademarks of the respective manufacturers and are accepted as protected. As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change without prior notice. National product specifications may vary.
  • Page 18 Please act according to your local rules and do not dispose of your old products with your normal household waste. The correct disposal of your old product will help prevent potential negative consequences to the environment and human health. © SHARKOON Technologies GmbH 2009 www.sharkoon.com QUICKSTORE PORTABLE...
