- Page 1 ETL-ES-Quince LED-WH19 OWNER'S MANUAL MANUAL DEL USUARIO Quince LED Please write model number here for future reference: Por favor, incluya el número del modelo aquí para futura referencia: Net Weight: 11.0 LBS Peso Neto: 5.0 KGS...
-
Page 2: Safety Tips
ETL-ES-Quince LED-WH19 SAFETY TIPS OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX AND/OR SUPPORT DIRECTLY FROM BUILDING STRUCTURE. -
Page 3: Consejos De Seguridad
ETL-ES-Quince LED-WH19 CONSEJOS DE SEGURIDAD HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O HERIDAS GRAVES PERSONALES, MONTE EN UNA CAJA DE EMBUTIR ROTULADA “ADECUADA PARA VENTILADORES DE 35 LBS (15,9 KG) O MENOS”... - Page 4 ETL-ES-Quince LED-WH19 FEATURES CARACTERÍSTICAS DOWNROD VAULTED CEILING INSTALLATION INSTALLATION INSTALACIÓN CON INSTALACIÓN PARA VARILLA VERTICAL TECHOS ABOVEDADOS For normal ceilings May require a longer downrod COMBO-BLADE (sold separately) Combo-Blades feature two high quality finishes on one blade. Select the one that best complements Para techos normales your decor, or change the style with just a flip of the blade.
- Page 5 ETL-ES-Quince LED-WH19 PREPARING FOR INSTALLATION ANTES DE LA INSTALACIÓN Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
- Page 6 ETL-ES-Quince LED-WH19 MOUNTING BRACKET INSTALLATION INSTALACIÓN CON SOPORTE DE MONTAJE Remove the screws from the two mating holes (1) on the canopy. Loosen (do not remove) the screws in the mating slots (2) on the canopy. Rotate the mounting bracket and remove from the canopy.
- Page 7 ETL-ES-Quince LED-WH19 MOUNTING BRACKET INSTALLATION MOUNTING OPTIONS INSTALACIÓN CON SOPORTE OPCIONES DE MONTAJE DE MONTAJE Choose a MOUNTING OPTION Elija una OPCIÓN DE MONTAJE NORMAL DOWNROD OPTION If installing downrod supplied with fan, proceed to page 9, step 6. OPCIÓN CON VARILLA VERTICAL PARA TECHO NORMAL Si instala la varilla vertical incluida con el ventilador, proceda a la página 9, paso 6.
- Page 8 ETL-ES-Quince LED-WH19 NORMAL DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL PARA TECHO NORMAL Loosen (but do not remove) the set screws from the down rod coupling. Place down rod assembly into canopy and coupling cover. Insert downrod into downrod coupling. Make sure to align hole in downrod with the hole in downrod coupling.
- Page 9 ETL-ES-Quince LED-WH19 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Slide downrod ball (1) off of downrod and remove pin (2). Deslice la bola de la varilla vertical (1) hasta separarla de la Loosen downrod ball (1) from downrod (2) by removing set screw (3).
- Page 10 ETL-ES-Quince LED-WH19 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Re-install pin into extended downrod, and slide downrod ball up to the top of the downrod. Re-install set screw to secure ball to downrod. Note: Some extended downrods have a pre- drilled set-screw hole.
- Page 11 ETL-ES-Quince LED-WH19 BLADE INSTALLATION BLADE INSTALLATION INSTALACIÓN DE LAS ALETAS INSTALACIÓN DE LAS ALETAS Attach blade assembly to motor using the noise-dampening motor gaskets and motor screws provided. Tighten screws securely. Fije el conjunto de las aletas al motor usando las juntas reductoras de sonido del motor y los tornillos para el motor incluidos.
- Page 12 ETL-ES-Quince LED-WH19 MOUNTING MONTAJE Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. With bracket holding fan assembly, make electrical connections using the following step for wiring instructions.
- Page 13 ETL-ES-Quince LED-WH19 WIRING OPTIONS OPCIÓN DE CABLEADO PULL CHAIN WIRING OPTION WALL CONTROL WIRING OPTION Follow diagram above to make wiring connections for fan pull chain control. Follow diagram above to make wiring connections for wall control operation. OPCIÓN DE CABLEADO PARA CONTROL DE PARED OPCIÓN DE CABLEADO PARA CADENILLA DE TIRO...
- Page 14 ETL-ES-Quince LED-WH19 SECURE TO CEILING ASEGURE EL VENTILADOR AL TECHO For downrod fans, slide the canopy up to the mounting bracket. Para ventiladores con varilla vertical, deslice el dosel hacia arriba hasta el soporte de montaje. The canopy has two mating slots (1) and two mating holes (2). Position both slots on canopy directly under and in line with two screws in the mounting bracket (3). Lift the canopy, allowing the two screws to slide into the mating slots.
- Page 15 ETL-ES-Quince LED-WH19 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO Locate the indentations on the neck of the glass (2) and align with the protrusions from Assemble decorative fob and extension chains from hardware bag to fan pull the light kit (1). Lift the glass up allowing the protrusions to engage the indentations on chains by inserting end of chain into chain coupling.
-
Page 16: Operation
ETL-ES-Quince LED-WH19 OPERATION AND MAINTENANCE Operation Turn on the power and check operation of fan. The pull chain controls the fan speeds as follows: 1 pull - high; 2 pulls - medium; 3 pulls - low; 4 pulls - off. -
Page 17: Operación
ETL-ES-Quince LED-WH19 OPERACIÓN Y MANTENIMIENTO Operación Encienda el ventilador y verifique su funcionamiento. La cadenilla de tiro controla las velocidades del ventilador de la siguiente manera: 1 jalón – rápida; 2 jalones - mediana; 3 jalones - lenta; 4 jalones - apagado. -
Page 18: Troubleshooting Guide
ETL-ES-Quince LED-WH19 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these TROUBLESHOOTING GUIDE installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, please consult with your qualified electrician and do not attempt any electrical repairs yourself. - Page 19 ETL-ES-Quince LED-WH19 Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, instalación o cableado incorrectos. En algunos GUÍA PARA SOLUCIONAR PROBLEMAS casos, estos errores de instalación podrían ser confundidos con defectos. Si experimenta alguna falla, consulte esta guía para solucionar problemas.
-
Page 20: Warranty
If replacement product is not available through seller, please contact www.westinghouselighting.com/contact-us. GARANTÍA Este ventilador de Westinghouse Lighting se ofrece con una garantía limitada de por vida para el propietario original frente a defectos de material y de mano de obra. Esta garantía sustituye cualquier otra garantía expresa o implícita. - Page 21 ETL-ES-Quince LED-WH19 PARTS LIST LISTA DE REPUESTOS Description 1 ....Mounting Bracket 2 ....Blade Bracket 3 .
- Page 22 ETL-ES-Quince LED-WH19...
- Page 23 ETL-ES-Quince LED-WH19...
- Page 24 ETL-ES-Quince LED-WH19 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com , WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are trademarks of Westinghouse Electric Corporation. Used under licensee by Westinghouse Lighting All rights reserved. Made in China...
