Orbit 94075 Installation And User Manual

4-button digital hose faucet timer
Hide thumbs Also See for 94075:

Advertisement

Quick Links

WTM221395 62075-24 rB.qxd
4-Button Digital Hose Faucet Timer
Installation and user's guide
Minuterie Orbit
adaptateur de tuyau
Guide d'installation et d'utilisation
Programador digital de grifo de 4 botones
conectado a la llave de agua
Guía del usuario y de instalación
Timer digitale per attacco diretto a manichetta
Orbit
®
a 4 pulsanti
Installazione e Guida dell'utente
Orbit
®
Digitales zeitgesteuertes
Schlauchhahnventil mit vier Ausgängen
Installationsanleitung und Benutzerhandbuch Inhalt
®
numérique à 4 boutons pour
11/1/2002
Models: 94075, 62075
10:09 AM

Advertisement

loading

Related Manuals for Orbit 94075

Summary of Contents for Orbit 94075

  • Page 1 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM Models: 94075, 62075 4-Button Digital Hose Faucet Timer Installation and user’s guide Minuterie Orbit ® numérique à 4 boutons pour adaptateur de tuyau Guide d'installation et d'utilisation Programador digital de grifo de 4 botones conectado a la llave de agua Guía del usuario y de instalación...
  • Page 2 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM Configuración del Table of Contents programador ... . . 49 Introduction ....3 Otras funciones .
  • Page 3 ..90 The Orbit Timer provides up to 3 start times per day with water- ing periods from 1 to 99 minutes per start time. For ease of use, ..91 the User’s Guide has step-by-step instructions for installation,...
  • Page 4 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM KEY P Indica progra Select SET AUTO MANUAL OFF DELAY LEFT clock water start t Select 88 : 88 Select CYCLE MINS Select 1 2 3 4 all sta Select CLOCK hours START Indica ing on Indica –...

  • Page 5: Key Pad And Display

    WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM KEY PAD AND DISPLAY Indicates different mode settings for Indicates the time to begin watering. programming. Indicates clock, start time and watering Select to set day of the week, to set duration. clock time, to set watering day(s), to set Push to select or unselect a setting.
  • Page 6 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM INSTALLATION GENERAL INFORMATION 1. Location: Choose a spot where water drains away from house and window wells. Warning: For outdoor use in cold water only. If o 2. Plumbing Codes: Follow all watering and back-flow (anti-siphon) prevention codes.
  • Page 7 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM Install three AA 1.5-volt alkaline batteries. Slide compart- ment cover back into place. Check the timer periodically for low voltage. When the battery power drops below the safety zone, the "Low e and Battery" indicator appears on the display. Replace the bat- teries with new fully-charged batteries when this appears.
  • Page 8 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM PROGRAMMING SET CLOCK TIME AND DAY OF WEEK Push the indented RESET area to erase the current settings. After pressing RESET the timer automatically will start in the SET mode. The word SET will blink to indicate that it is selected.
  • Page 9 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM Push CONFIRM button to accept the day setting and advance to set the clock time. The current time with A.M. or P.M. will flash. Push + or – button to select the correct current time. ettings.

  • Page 10: Set Watering Days

    11/1/2002 10:09 AM SET WATERING DAYS Your Orbit timer allows you to choose the days of the week for watering. You can water every day, only certain days or every 2nd or 3rd day. Push CONFIRM button to begin the set mode.
  • Page 11 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM Push + or – button to advance to the next day, or to the 2nd eek for and 3rd day settings. every When chosen day(s) are flashing, push the key to toggle the rain drop (insert raindrop) on/off. The rain drop indicates the day(s) chosen for watering.
  • Page 12 11/1/2002 10:09 AM SET DURATION AND START TIME FOR WATERING The Orbit timer allows you to set the duration and start time for watering in each of three watering cycles. Push CONFIRM button to begin the set mode. Push CONFIRM button two more times and NEXT button once to move past the time/day setting and the watering days.
  • Page 13 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM Push CONFIRM button to confirm the duration and advance to set start time. ime for There are three unique watering start times, or cycles, that can be set: CYCLE A, CYCLE B and CYCLE C. Each cycle will appear on the screen to specify which one is to be set.
  • Page 14 SET. The word SET will blink to indicate that it is selected. AUTOMATIC WATERING Once watering days, duration and start times are programmed, the Orbit ® timer will begin watering automatically. Push MODE button to select AUTO. The word AUTO will blink to indicate that it is selected.
  • Page 15 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM SET AUTO ce to 7:30 MODE auto- ettings. FIGURE 8 ODE but- ected. When watering begins, MINS TO RUN will alternate with the current time and day to indicate the time left on current cycle. In this mode, the unit executes any programmed schedule mmed, or default schedule.
  • Page 16 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM MANUAL ( EXTRA ) OPERATION The manual setting does not alter the automatic settings during or after manual use. Push MODE button to select MANUAL. The words MANUAL and SET will blink to indicate that they are selected. Push CONFIRM button to begin the manual mode.
  • Page 17 DELAY WATERING The Orbit timer allows you to delay automatic watering for 1-24 hours. Push MODE button to select DELAY. The word DELAY will blink to indicate that it is selected. The unit will initiate a 24 hour delay.
  • Page 18 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM OFF M SET AUTO MANUAL OFF DELAY In Off M will occ – MODE CONFIRM FIGURE 10 Push + or – button to change the hour delay within 10 sec- onds after pushing CONFIRM button to begin delay mode. Otherwise, "24 Hr"...
  • Page 19 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM OFF MODE In Off Mode, all watering programs are inactive and no watering will occur. Push MODE button to select OFF. The word OFF will blink to indicate that it is selected. Push CONFIRM button to begin off mode. SET AUTO MANUAL OFF sec- 9:32...
  • Page 20 WTM221395 62075-24 rB.qxd 11/1/2002 10:09 AM OFF-SEASON STORAGE AND MAINTENANCE PROB Turn the water off at the hose faucet. Push MODE button to select MANUAL. The words MANUAL and SET will blink to indicate that they are selected. Push CONFIRM button to begin the manual mode. MINS TO RUN will show with two digits or "- -"...

  • Page 21: Troubleshooting

    WTM221395 62075-24 rB.qxd 11/1/2002 10:11 AM TROUBLESHOOTING PROBLEM / POSSIBLE CAUSES Water does not turn on: 1. Programming is incorrect. ANUAL 2. Batteries are too weak to operate valve. 3. Pressure is in excess of 80 psi. INS TO 4. Hose faucet is turned off. 5.
  • Page 22 WTM221395 62075-24 rB.qxd 11/1/2002 10:19 AM chalten: 62075-24 Rev B...
