Summary of Contents for Cortexa Technology 7202
- Page 1 Copyright Cortexa Technology Inc., @ 2006...
- Page 2 7202 H ortexa ontroller wire ouCH anel wire wIrInG by system HVaC wire eCurity wire udio 1: C Ption ortexa uilt udio layer wire 2: a Ption udio iStriBution yStem wire ideo ameraS wire...
- Page 3 Installing a Home Control system is a smart investment in your home. With this system from Cortexa Technology, you can automate as much or as little of your home as you desire. Even if you are not ready to install a system today, leave your options open and protect the investment in your home by pre-wiring your home to easily facilitate the installation of a system in the future.
- Page 4 As indicated above, it is ideal to locate the Controller next to the incoming broadband connection and also to the security panel. The Cortexa 7202 includes brackets and can easily be mounted in a standard structured wiring can, or may simply sit on a shelf.
- Page 5 Continued Cortexa 7202 Home Controller Network Configuration...
- Page 6 The Cortexa 7202 includes a built-in Audio Player capable of streaming songs and playlists from iTunes running on any PC or server on the LAN. The Cortexa 7202 can therefore be added as a source to an existing music system within the home.
- Page 7 The Cortexa 7202 can be integrated with either digital or analog surveillance cameras. The optional video server board will accommodate up to four analog cameras, with external video servers able to be added to control more than four cameras.
- Page 8 Products supported and pre- wire requirements are as follows: No Pre-wire requirement Z-Wave No Pre-wire requirement Lutron Radio RA RS-22 cable from Radio RA interface to Cortexa 7202 Lutron Homeworks RS-22 cable from HomeWorks interface to Cortexa 7202 Insteon No Pre-wire requirement Vantage...
