INSTALLATION INSTRUCTIONS
HB0073
E60000 SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGE 13 AND 14.
Broan-NuTone LLC; Hartford, Wisconsin www.broan.com 800-558-1711
Broan-NuTone Canada; Mississauga, Ontario www.broan.ca 877-896-1119
REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register
SV08340 rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E60000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Broan E60000 Series

Summary of Contents for Broan E60000 Series

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGE 13 AND 14. Broan-NuTone LLC; Hartford, Wisconsin www.broan.com 800-558-1711 Broan-NuTone Canada; Mississauga, Ontario www.broan.ca 877-896-1119 REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register SV08340 rev. A...

  • Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following

    9. To reduce the risk of fire and electric shock, the Clean ventilating fans frequently. Grease should Broan Elite E60E Series hood must be installed with not be allowed to accumulate on fan or filter. one Broan exterior blower model 331H, 332H, 335 or 336;...

  • Page 3: Range Hood System

    ANKE60 SERIES 4½” 18½” DAPTER SUPPLIED WITH 3¼’’ 10’’ DAPTER DAMPER DOUBLE BLOWER HOOD SUPPLIED WITH SINGLE BLOWER HOOD E60000 SERIES HOOD (1200 UAL BLOWER RMP SERIES (600 INGLE BLOWER 42” 48” ONLY BACKSPLASH TAINLESS STEEL WALL COVERING WITH WARMING...
  • Page 4 USE WITH EXTERIOR LINE BLOWER BLOWERS 8” 10” INCLUDES ONE ODEL ROUND TRANSITION (10” R D DUCT SECTIONS E60000 SERIES HOOD 332KR LINE AND EXTERIOR BLOWER ROUGH IN KIT SUPPLIED WITH HOOD RMP S ERIES ACKSPLASH TAINLESS TEEL WALL COVERING...
  • Page 5 The Broan Elite E60000 Series range hood includes many configurations: hoods with single or double internal blowers (included with the hood), or hoods using external blowers. For this last category, the Broan Elite E60000 Series must be installed with in-line blower models HLB3, HLB6, HLB9 or HLB11, or exterior blower model 331H, 332H, 335 or 336 only.

  • Page 6: Measure Installation

    2. MEASURE INSTALLATION Dimensions for the most common installation are illustrated beside. Ceiling Cabinet, soffit, The minimum hood distance above cooktop must not be less Top of wood decorative flue or mounting strip than 24’’. A maximum of 30” above cooktop is highly non-duct kit flue A + 2’’...

  • Page 7: Install Backsplash

    3. PREPARE THE INSTALLATION (CONT’D) UCTED INSTALLATIONS ONLY Cut-out the openings for duct (A) and power cable (B), in cabinet or wall, according to the direction of discharge chosen. See figures below. NOTE: For all internal blower hoods, the cut-out opening for house wiring can be made in cabinet bottom OR wall, no matter the discharge chosen (vertical or horizontal).

  • Page 8: Remove The Adapter

    5. CHOOSE THE OPENING(S) (INTERNAL BLOWER(S) HOOD ONLY) Remove the knockout(s) for the chosen opening(s) (horizontal at the back of the hood or vertical on top). See illustrations below. ERTICAL DISCHARGE ORIZONTAL DISCHARGE NOTE: For ducted installation only. HR0021 Punch out the appropriate electrical knockout hole on top (A) or back (B) of the hood.

  • Page 9: Horizontal Discharge Installation

    8. HORIZONTAL DISCHARGE INSTALLATION ( INTERNAL BLOWER(S) HOOD ONLY) All internal blower hoods are factory shipped with the blowers mounted for a vertical discharge configuration. For a horizontal discharge configuration, disassemble the blower(s) from the inner top of the hood and mount it (them) to the inner back panel of the hood.

  • Page 10: Install Wood Mounting Strip

    9. INSTALL THE ADAPTER AND THE TRANSITION (IF NEED BE) (INTERNAL BLOWER(S) HOOD ONLY) Using standard 3/8’’ screws provided, secure the adapter to the top (or back) of the hood (2 screws for a 3¼” x 10” adapter/damper and 4 screws for a 4½” x 18½” adapter). Seal the adapter to the hood using duct tape. For round ducting, install an appropriate sized transition and seal the joints with duct tape.

  • Page 11: Install The Hood

    13. INSTALL THE HOOD CAUTION Hold the hood until it is completely secured to the wood mounting strip. OUNTING SCREWS LOCATION NTERNAL BLOWER ONLY Run power cable to installation location. Remove the electrical compartment cover. Insert the cable in the hood and tighten the wire clamp to secure the cable. LL INSTALLATIONS HD0264 Rest the back cavity of the hood on the wood mounting strip.

  • Page 12: Install The Blower

    16. INSTALL THE BLOWER (EXTERIOR OR IN-LINE BLOWER) Refer to instructions included with blower. Plug the 3-prong plug cord from rough-in plate to the 3-prong male connector inside the hood (A) and the 2-prong male connector cord from rough-in plate to the 2-prong plug inside the hood (B). WARNING Do not plug the 2 cords together.

  • Page 13: Operation

    19. USE AND CARE Baffle Filters The baffle filters should be cleaned frequently. Use a warm detergent solution. Wash more often if your cooking style generates greater grease—like frying foods or wok cooking. Remove baffle filters by pushing them towards the back of hood and rotating filters downward. Baffle filters are dishwasher safe. Allow filters to dry completely before reinstalling them in the hood.

  • Page 14: Warranty

    BROAN-NUTONE LLC ONE-YEAR LIMITED WARRANTY Broan-NuTone LLC warrants to the original consumer purchaser of its products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

  • Page 15: Wiring Diagrams

    22. WIRING DIAGRAMS Broan Elite E60000 Series NEON Internal blower(s) hoods SPEED SWITCH CONTROL On 3 Off 2 USE ONLY WITH APPROPRIATE MAKE-UP AIR SYSTEM THERMOSTAT LINE NEUTRAL GROUND LAMP SWITCH COLOR CODE BLACK BLUE BROWN ORANGE WHITE LAMP LAMP...

  • Page 16: Service Parts

    23. SERVICE PARTS Broan Elite E60000 Series Broan Elite E60000 Series Exterior or In-Line blower hoods Internal blower hoods HL0105 HL0106 QTY. ( QTY. ( ESCRIPTION HOOD WIDTH ESCRIPTION HOOD WIDTH 30” 36” 42” 48” 30” 36” 42” 48” 3¼”...
