INSTALLATION INSTRUCTIONS
HB0073
E60000LC SERIES
!
!
INTENDED FOR DOMESTIC COOKING ONLY
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14.
Broan-NuTone Canada ULC; Mississauga, Ontario www.broan.ca
877-896-1119
REGISTER YOUR PRODUCT ONLINE AT: www.broan.ca
21241 rev. 01
Advertisement
Table of Contents
Related Manuals for Broan E60000LC SERIES
Summary of Contents for Broan E60000LC SERIES
- Page 1 INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14. Broan-NuTone Canada ULC; Mississauga, Ontario www.broan.ca 877-896-1119 REGISTER YOUR PRODUCT ONLINE AT: www.broan.ca 21241 rev. 01...
-
Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following
Use an appropriate make-up air device or open a window close to or in the kitchen. 10. To reduce the risk of fire and electric shock, the Broan Elite E60E Series hood must be installed with one Broan exterior blower model 331H, 332H, 335 or 336;... - Page 3 FLUE AEE SERIES 4½" 18½" DAPTER SUPPLIED WITH DOUBLE BLOWER HOOD 3¼" 10" DAPTER AMPER SUPPLIED WITH SINGLE BLOWER HOOD E60000LC SERIES HOOD (1200 LOWER RMP SERIES (600 INGLE LOWER 36", 42" 48" ONLY BACKSPLASH TAINLESS STEEL WALL COVERING WITH WARMING...
- Page 4 ODEL BLOWERS LINE LOWER 8" 10" INCLUDES ONE ODEL ROUND TRANSITION (10" R OUND ECTIONS E60000LC SERIES HOOD 332KR I LINE AND XTERIOR LOWER OUGH SUPPLIED WITH HOOD RMP SERIES BACKSPLASH TAINLESS STEEL WALL COVERING WITH WARMING SHELVES PTIONAL HL0100...
- Page 5 The Broan Elite E60000LC Series range hood includes many configurations: hoods with single or double internal blowers (included with the hood), or hoods using external blowers. For this last category, the Broan Elite E60000LC Series must be installed with in-line blower models HLB3, HLB6, HLB9 or HLB11, or exterior blower models 331H, 332H, 335 or 336 only.
-
Page 6: Measure Installation
2. MEASURE INSTALLATION Dimensions for the most common installation are illustrated at right. Ceiling The minimum hood distance above cooktop is 24" for electric ranges, Cabinet, soffit, Top of wood and 30" for gas ranges. or decorative flue mounting strip A maximum of 30"... -
Page 7: Install Backsplash
3. PREPARE THE INSTALLATION ( CONT’D Cut-out the openings for duct (A) and power cable (B), in cabinet or wall, according to the direction of discharge chosen. See figures below. NOTE: For all internal blower hoods, the cut-out opening for house wiring can be made in cabinet bottom OR wall, no matter the discharge chosen (vertical or horizontal). -
Page 8: Remove The Adapter
5. CHOOSE THE OPENING(S) (INTERNAL BLOWER(S) HOOD ONLY) Remove the knockout(s) for the chosen opening(s) (horizontal at the back of the hood or vertical on top). See illustrations below. ERTICAL DISCHARGE ORIZONTAL DISCHARGE HR0021 Punch out the appropriate electrical knockout hole on top (A) or back (B) of the hood. -
Page 9: Horizontal Discharge Installation
8. HORIZONTAL DISCHARGE INSTALLATION (INTERNAL BLOWER(S) HOOD ONLY) All internal blower hoods are factory shipped with the blower(s) mounted for a vertical discharge configuration. For a horizontal discharge configuration, disassemble the blower(s) from the inner top of the hood and mount it (them) to the inner back panel of the hood. The procedure below applies for one or two blowers. -
Page 10: Install Wood Mounting Strip
9. INSTALL THE ADAPTER AND THE TRANSITION (IF NEED BE) (INTERNAL BLOWER(S) HOOD ONLY) Using standard 3/8" screws provided, secure the adapter to the top (or back) of the hood (2 screws for a 3¼" x 10" adapter/damper and 4 screws for a 4½" x 18½" adapter). Seal the adapter to the hood using metal foil duct... -
Page 11: Install The Hood
12. INSTALL THE HOOD CAUTION Hold the hood until it is completely secured to the wood mounting strip. OUNTING SCREWS LOCATION NTERNAL BLOWER ONLY Run power cable to installation location. Remove the electrical compartment cover. Insert the cable in the hood and tighten the wire clamp to secure the cable. HD0579 LL INSTALLATIONS ALL ANCHORS LOCATION... -
Page 12: Install The Blower
15. INSTALL THE BLOWER (EXTERIOR OR IN-LINE BLOWER) Refer to instructions included with blower. Plug the 3-prong plug cord from rough-in plate to the 3-prong male connector inside the hood (A) and the 2-prong male connector cord from rough-in plate to the 2-prong plug inside the hood (B). -
Page 13: Operation
18. USE AND CARE Baffle Filters The baffle filters should be cleaned frequently. Use a warm detergent solution. Wash often if your cooking style generates a lot of grease— like frying food or wok cooking. Remove baffle filters by pushing them towards the back of hood and rotating filters downward. Baffle filters are dishwasher safe. Allow filters to dry completely before reinstalling them in the hood. -
Page 14: Warranty
IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. During this one-year period, Broan-NuTone will, at its option, repair or replace, without charge, any product or part which is found to be defective under normal use and service. -
Page 15: Wiring Diagrams
21. WIRING DIAGRAMS Broan Elite E60000LC Series Internal blower(s) hoods USE ONLY WITH APPROPRIATE NEON MAKE-UP AIR SYSTEM BLOWER MOTOR ORA ORA 9408 FAN SWITCH A A A A MAIN SWITCH THERMOSTAT LINE NEUTRAL GROUND LED CONTROL COLOR CODE BLACK... -
Page 16: Service Parts
Any third party replacement part used may cause serious damage and drasticallyreduce the performance level of your unit, which will result in premature failing. Broan-NuTone recommends to contact a...
