Broan Pro-Style Range Hood E60 Series Specification Sheet

E60 SERIES
PRO-STYLE

RANGE HOOD

Styling is fresh and modern, yet designed to easily complement
popular pro-style, high performance cooking products.
A complete installation requires several optional components. Refer
to page 2 when planning your installation
FEATURES
HOOd:
•
Widths - 30" to 48" in 6" increments
•
stainless steel, 22 gauge, type 430, #4 brush
•
stainless steel baffle filters with handles -
easily accessible, dishwasher safe
•
2-level cooktop lighting (30" & 36" wide hoods = 2
lamps, 42" & 48" wide hoods = 3 lamps. Uses 50W,
gU10 halogen lamps. Bulbs not included.)
•
solid-state, infinite speed blower control with
speed memory
•
exclusive, Broan Heat sentry™ turns blower ON
to HIgH speed when excess heat is detected
•
3¼" x 10" ducting - single blower (600 cfm)
•
4½" x 18½" ducting - dual blower (1200 cfm)
NON-dUCTed ReCIRCULATINg KIT:
ANKe60 series (Optional)
•
stainless steel, 22 gauge, type 430, #4 brush
•
Available for hood widths up to 48"
•
Charcoal filters included
Replacement charcoal filters:
- service Part # sV08343 - round filter retail pack
BACKsPLAsH:
RMP series (Optional)
•
Widths - 30" to 48" in 6" increments
•
stainless steel, 22 gauge, type 430, #4 brush - protects back
wall and wipes clean easily
•
Two, removable, dual-position condiment storage shelves
sOffIT CHIMNeY:
Aee series (Optional)
•
Widths - 30" to 48" in 6" increments
•
stainless steel, 22 gauge, type 430, #4 brush
•
Recommended for use when installation location has no soffit
sPeCIfICATION:
single Blower
•
120 VAC, 60 Hz, 5.5 Amps
•
600 cfm, sound level no greater than 13.5 sones (high speed, vert. & horiz. discharge)
•
150 cfm, 1.5 sones (working speed, vert. & horiz. discharge)
dual Blower
•
120 VAC, 60 Hz, 9.0 Amps
•
1200 cfm, sound level no greater than 14.5 sones (high speed, vert. & horiz. discharge)
•
350 cfm, 2.0 sones (working speed, vert. & horiz. discharge)
Broan-NuTone LLC Hartford, Wisconsin www.broan.com 800-558-1711
Broan-NuTone Canada Mississauga, Ontario www.broan.ca 877-896-1119
REFERENCE QTY.
Models
E6042TSS
E6048TSS
RMP Serie Backsplash
(Optional)
REMARKS
SPECIFICATION SHEET
Project
Location
Architect
Engineer
Contractor
Submitted By
80L
For domestic
cooking only.
Models
E6030SS
E6036SS
HVI-2100 CeRTIfIed
RATINgs comply with
new testing technologies
a n d p r o c e d u r e s
prescribed by the Home
Ventilating Institute, for
off-the-shelf products,
as they are available
to consumers. Product
performance is rated at
0.1 in. static pressure,
based on tests conducted
in a state-of-the-art test
laboratory. sones are
a measure of humanly-
p e r c e i v e d l o u d n e s s ,
based on laboratory
measurements.
AEE Series
Soffit Chimney
(Optional)
Date
99044446C
