- Page 1 1050 TREADMILL OWNER’S MANUAL Read the TREADMILL GUIDE before using this OWNER’S MANUAL.
- Page 3 If the assembly instructions are not followed correctly, the treadmill could have parts that are not tightened and will seem loose and may cause irritating noises. To prevent damage to the treadmill, the assembly instructions must be reviewed and corrective actions should be taken.
- Page 4 TOUCH PAD PANEL AND DISPLAY WINDOWS SAFETY KEY PLACEMENT CONSOLE MAST MOTOR COVER RUNNING BELT / RUNNING DECK SIDE RAIL ROLLER END CAP REAR ROLLER ADJUSTMENT BOLTS SPEAKERS WATER BOTTLE HOLDER CONSOLE FAN SUPPORT BAR GRIP PULSE HANDRAILS HANDLEBARS ON/OFF SWITCH CIRCUIT BREAKER POWER CORD FOOT LOCK LATCH...
-
Page 5: Pre-Assembly
Unpack the unit where it will be used. The enclosed treadmill is equipped with high-pressure shocks and may spring open if mishandled. Never grab hold of any portion of the incline frame and attempt to lift or move the treadmill. WArninG DO NOT ATTEMPT TO LIFT THE TREADMILL! Do not move or lift treadmill from packaging until specified to do so in the assembly instructions. -
Page 6: Assembly Step
Qty: 1 LEFT CONSOLE MAST MAIN FRAME Open HArDWArE bAG 1. Cut banding straps. Do not move or lift treadmill from packaging. Move LEfT LinKAGE ArM into position. Insert boLT (A) and fLAT WASHEr (b) into LEfT LinKAGE ArM followed by a TEfLon WASHEr (C) and attach to elevation frame. - Page 7 MAIN FRAME ELEVATION FRAME FOOT LOCK LATCH PRE-ATTACHED BOLT ATTEnTion If you have attempted to move the treadmill from the box and the machine has sprung open and cannot be assembled, refer WAVY WASHER (F) 29 mm Qty: 1 to the troubleshooting section in the TREADMILL GUIDE in order to restore the treadmill to its proper position.
- Page 8 ASSEMBLY STEP 3 HArDWArE bAG 3 CONTENTS : BOLT (G) SPRING WASHER (B) 15 mm 15 mm Qty: 4 Qty: 4 Disengage the deck lock latch with your foot to lower the running deck. FLAT WASHER (H) 20 mm Open hardware bag 3. Qty: 4 Gently place the console on top of the console masts.
- Page 9 ASSEMBLY STEP 4 HArDWArE bAG 4 CONTENTS : BOLT (I) 15 mm Qty: 4 Open hardware bag 4. Align support bar with holes in console masts. Insert bolts (i) into all 4 holes of the support bar. NOTE: Look into holes in the right mast before inserting bolts to avoid pinching cables.
- Page 10 Flip this switch to the ‘ON’ position, so that the switch is lit. You will hear a beep and the console will turn on. Before the first use, lubricate the treadmill deck by following the instructions in the MAINTENANCE section in the TREADMILL GUIDE.
-
Page 11: Treadmill Operation
TREADMILL OPERATION This section explains how to use your treadmill’s console and programming. The BASIC OPERATION section in the TREADMILL GUIDE has instructions for the following: • LoCATion of THE TrEADMiLL • USinG THE SAfETy KEy • foLDinG THE TrEADMiLL •... - Page 12 TIME DISTANCE INCLINE SPEED CALORIES HEART RATE time distance calories manual intervals hills weight loss G OA L C E N T E R activated TA R G E T S W O R KO U T S select enter workout select goal...
-
Page 13: Console Operation
Note: when headphones are plugged into the headphone jack the sound will no longer come out through the speakers. MP3 PLAyEr PoCKET: used to store your MP3 player. U) WATEr boTTLE PoCKETS: holds personal workout equipment. v) rEADinG rACK: holds reading material. W) SAfETy KEy PoSiTion: enables treadmill when safety key is inserted. -
Page 14: Display Windows
DiSPLAy WinDoWS • TiME: Shown as minutes : seconds. View the time remaining or the time elapsed in your workout. • DiSTAnCE: Shown as miles. Indicates distance traveled or distance remaining during your workout. • inCLinE: Shown as percent. Indicates the incline of your walking or running surface. •... -
Page 15: Getting Started
1) Check to make sure no objects are placed on the belt that will hinder the movement of the treadmill. 2) Plug in the power cord and turn the treadmill ON. 3) Stand on the side rails of the treadmill. - Page 16 TArGET ProfiLES TArGET 1 – TiME: Allows user to set a target based on how long they would like to workout. Time targets can range from 15:00 – 99:00. TIME will count down. DISTANCE and CALORIES will count up from zero. TArGET 2 –...
- Page 17 3) HiLLS: Simulates running up and down hills to improve stamina. Segment Warm Up Time 4:00 Mins 30 sec Incline 4) WEiGHT LoSS: Promotes weight loss by increasing and decreasing the speed, while keeping you in your fat burning zone. Segment Warm Up Time...
- Page 18 GOAL CENTER your treadmill console, that will allow you to track your fitness goals over time, without the need for paper journals or logs. Read further to learn about how GOAL CENTER GoAL CEnTEr™...
-
Page 19: Cool Down
To rESET THE ConSoLE Hold STOP key for 3 seconds. CooL DoWn Puts treadmill into cool down mode. Cool down lasts for four minutes and reduces speed and incline to allow your heart to readjust to decreased demand. finiSHinG yoUr WorKoUT When your workout is complete, the monitor display will flash “FINISHED”... -
Page 21: Limited Home-Use Warranty
LIMITED HOME-USE WARRANTY... - Page 22 LABOR • 1 YEAR Horizon Fitness shall cover the labor cost for the repair of the device for a period of one year from the date of the original purchase, so long as the device remains in the possession of the original owner.
- Page 23 • Any attempt to repair this equipment creates a risk of injury. Horizon Fitness is not responsible or liable for any damage, loss or liability arising from any personal injury incurred during the course of, or as a result of any repair or attempted repair of your fitness equipment by other than an authorized service technician.
- Page 24 1-800-244-4192 comments@horizonfitness.com www.horizonfitness.com GS1050T Rev. 1.1 | © 2009 Horizon Fitness | Designed & Engineered in the U.S.A. | Made in China Do noT rETUrn Every employee at Horizon Fitness takes pride in providing you with a high quality product.
