ACUIX
™
IP PTZ Dome
SPECIFICATIONS
Outdoor Pendant
Electrical
Input Voltage
24 VAC @ 50/60 Hz, Class 2 LPS
Input Tolerance
21 to 27 VAC
55 W Peak
Power Consumption
41 W Idle
Mechanical
Housing:
Dimensions
Lower Dome: 7.5" Dia (191 mm Dia)
Weight
6.7 lbs (3.04 kg)
Housing:
Construction
Lower Dome: Optical Grade Acrylic
Finish:
Mounting Method
1.5" NPT
Rugged
Electrical
Input Voltage
24 VAC @ 50/60 Hz, Class 2 LPS
Input Tolerance
21 to 27 VAC
55 W Peak
Power Consumption
41 W Idle
Mechanical
Housing:
Dimensions
Lower Dome: 7.5" Dia (191 mm Dia)
Weight
14.75 lbs (6.69 kg)
Housing:
Construction
Lower Dome: Optical Grade Acrylic
Mounting Method
Integral bracket providing 90° tilt
7.7" H x 10.1" Dia
(194.6 mm H x 255.5 mm Dia)
Aluminum
Warm gray
see line drawing
Die-cast aluminum
www.honeywellvideo.com
10.1"
255.5 mm
13.11"
333.0 mm
10.52"
267.2 mm
