- Page 1 SBAY5BK Instruction Manual SATA/SAS Hard Drive Mobile Rack Backplane 5 Drive 3.5” Removable SATA/ SAS Mobile Rack Backplane...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question.
-
Page 3: Table Of Contents
Table of Contents Introduction ..............1 Packaging Contents..............1 System Requirements ..............1 Front View ..................2 Rear View ..................2 Installation ............... 3 Hardware Installation ..............3 Driver Installation .................3 How to Use ..............4 Specifications ..............5 Technical Support ............6 Warranty Information ............6... -
Page 4: Introduction
Introduction The SBAY5BK Trayless Hard Drive Backplane provides a simple, hot-swap compatible internal storage solution with support for up to five 3.5” SAS and/or SATA (SATA 1.5/3.0 Gbps) hard drives. The RAID compatible SAS/SATA backplane features two rear-mounted 60mm cooling fans and is constructed of aluminum and steel for maximum heat dissipation. -
Page 5: Front View
Front View Drive Door Lock Power/Activity Fan Status Rear View 60mm cooling fans LP4 molex power connector 7-pin SATA 7-pin SAS (black) (yellow) -
Page 6: Installation
Prepare 3 adjacent external 5.25” bays in the computer system for the SBAY5BK Mobile Rack and insert it into the computer system. Install as per the computer systems documentation. Standard mounting screws are included, if needed. -
Page 7: Driver Installation
Driver Installation No driver installation is required for any operating system, as this Mobile Rack is a pass through device, so only the hard drives are seen by the computer system. How to Use If the SATA controller supports Hot-Swapping drives, then hard drives can be removed and installed into the Mobile Rack without having to shut the computer system off. -
Page 8: Specifications
Specifications SATA 3.0Gbps Bus Interface SAS 3.0Gbps 5 x 7-pin SATA (black) External Connectors 5 x 7-pin SAS (yellow) 2 x 4-pin LP4 molex 1 x Fan Status LEDs 5 x Drive Power/Activity Fans 2 x 60mm 3.5” SATA 1.5/3.0 Gbps hard drives up to 2TB capacity* Hard Drive Support 3.5”... -
Page 9: Technical Support
