Sony SRS-D313 Service Manual page 12

SRS-D313
Ver 1.4 2002.11
CONTROL
Ref. No. Part No. Description
* A-3062-598-A CONTROL BOARD, COMPLETE
* A-3323-727-A CONTROL BOARD, COMPLETE (AEP,UK,AUS)
*************************
< CAPACITOR >
C101 1-124-259-11 ELECT
C103 1-124-259-11 ELECT
C106 1-124-233-11 ELECT
C108 1-162-927-11 CERAMIC CHIP
C109 1-124-259-11 ELECT
C110 1-124-259-11 ELECT
C111 1-124-259-11 ELECT
C112 1-124-259-11 ELECT
C113 1-124-233-11 ELECT
C114 1-104-666-11 ELECT
C115 1-127-715-11 CERAMIC CHIP
C131 1-124-259-11 ELECT
C201 1-124-259-11 ELECT
C203 1-124-259-11 ELECT
C206 1-124-233-11 ELECT
C208 1-162-927-11 CERAMIC CHIP
C209 1-124-259-11 ELECT
C210 1-124-259-11 ELECT
C211 1-124-259-11 ELECT
C212 1-124-259-11 ELECT
C213 1-124-233-11 ELECT
C214 1-104-666-11 ELECT
C215 1-127-715-11 CERAMIC CHIP
C231 1-124-259-11 ELECT
C301 1-126-382-11 ELECT
C302 1-107-826-11 CERAMIC CHIP
C303 1-126-382-11 ELECT
C304 1-107-826-11 CERAMIC CHIP
C307 1-131-664-11 CERAMIC CHIP
C309 1-107-826-11 CERAMIC CHIP
C310 1-124-259-11 ELECT
C311 1-124-233-11 ELECT
C312 1-107-826-11 CERAMIC CHIP
C313 1-107-826-11 CERAMIC CHIP
C314 1-127-715-11 CERAMIC CHIP
C315 1-124-259-11 ELECT
C316 1-126-382-11 ELECT
C317 1-107-826-11 CERAMIC CHIP
C318 1-107-826-11 CERAMIC CHIP
C319 1-126-382-11 ELECT
C321 1-124-589-11 ELECT
C322 1-124-589-11 ELECT
C323 1-162-927-11 CERAMIC CHIP
C324 1-162-970-11 CERAMIC CHIP
C330 1-107-826-11 CERAMIC CHIP
< CONNECTOR >
CN101 1-566-690-11 PLUG, CONNECTOR (2.5mm) 2P
CN102 1-815-934-11 PIN, CONNECTOR 8P
< DIODE >
D101 8-719-066-58 LED SM2512 (POWER)
12
Remarks Ref. No.
(EXCEPT AEP,UK)
4.7uF 20.00% 16V
4.7uF 20.00% 16V
10uF 20.00% 16V
100PF 5% 50V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
10uF 20.00% 16V
220uF 20.00% 16V
0.22uF 10% 16V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
10uF 20.00% 16V
100PF 5% 50V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
4.7uF 20.00% 16V
10uF 20.00% 16V
220uF 20.00% 16V
0.22uF 10% 16V
4.7uF 20.00% 16V
100uF 20.00% 16V
0.1uF 10.00% 16V
100uF 20.00% 16V
0.1uF 10.00% 16V
0.15uF 10% 10V
0.1uF 10.00% 16V
4.7uF 20.00% 16V
10uF 20.00% 16V
0.1uF 10.00% 16V
0.1uF 10.00% 16V
0.22uF 10% 16V
4.7uF 20.00% 16V
100uF 20.00% 16V
0.1uF 10.00% 16V
0.1uF 10.00% 16V
100uF 20.00% 16V
47uF 20% 16V
47uF 20% 16V
100PF 5% 50V
0.01uF 10% 25V
0.1uF 10.00% 16V
Part No. Description
< IC >
IC101 8-759-100-96 IC NJM4558M-TE2
IC102 8-759-100-96 IC NJM4558M-TE2
IC103 8-759-100-96 IC NJM4558M-TE2
IC104 8-759-385-17 IC NJM4580E(TE2)
< JACK >
J101 1-566-822-21 JACK (INPUT 1)
J102 1-566-822-21 JACK (INPUT 2)
J103 1-815-629-11 JACK (PHONES)
< JUMPER RESISTOR >
JR101 1-216-864-11 METAL CHIP
JR102 1-216-864-11 METAL CHIP
JR103 1-216-864-11 METAL CHIP
JR104 1-216-864-11 METAL CHIP
JR105 1-216-864-11 METAL CHIP
JR106 1-216-864-11 METAL CHIP
JR107 1-216-864-11 METAL CHIP
JR108 1-216-864-11 METAL CHIP
JR109 1-216-864-11 METAL CHIP
JR110 1-216-864-11 METAL CHIP
JR111 1-216-864-11 METAL CHIP
JR112 1-216-864-11 METAL CHIP
JR113 1-216-864-11 METAL CHIP
JR114 1-216-864-11 METAL CHIP
JR115 1-216-864-11 METAL CHIP
JR116 1-216-864-11 METAL CHIP
< TRANSISTOR >
Q101 8-729-038-58 TRANSISTOR
Q102 8-729-038-71 TRANSISTOR
Q103 8-729-038-58 TRANSISTOR
Q104 8-729-038-71 TRANSISTOR
Q105 8-729-920-31 TRANSISTOR
Q205 8-729-920-31 TRANSISTOR
< RESISTOR >
R101 1-216-821-11 METAL CHIP
R102 1-218-344-11 METAL CHIP
R103 1-216-821-11 METAL CHIP
R104 1-216-821-11 METAL CHIP
R107 1-216-837-11 METAL CHIP
R108 1-216-833-11 METAL CHIP
R109 1-216-837-11 METAL CHIP
R110 1-216-833-11 METAL CHIP
R111 1-216-823-11 METAL CHIP
R112 1-216-837-11 METAL CHIP
R113 1-216-833-11 METAL CHIP
R114 1-216-821-11 METAL CHIP
R115 1-216-793-11 RES-CHIP
R116 1-216-793-11 RES-CHIP
R117 1-216-813-11 METAL CHIP
R131 1-216-821-11 METAL CHIP
R132 1-218-334-11 METAL CHIP
R201 1-216-821-11 METAL CHIP
R202 1-216-831-11 METAL CHIP
R203 1-216-821-11 METAL CHIP
R204 1-216-821-11 METAL CHIP
Remarks
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
0 5% 1/16W
KRA107S
KRC107S
KRA107S
KRC107S
DTC343TK-T-146
DTC343TK-T-146
1K 5% 1/16W
7.5K 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
22K 5% 1/16W
10K 5% 1/16W
22K 5% 1/16W
10K 5% 1/16W
1.5K 5% 1/16W
22K 5% 1/16W
10K 5% 1/16W
1K 5% 1/16W
4.7 5% 1/16W
4.7 5% 1/16W
220 5% 1/16W
1K 5% 1/16W
7.5K 5% 1/16W
1K 5% 1/16W
6.8K 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
