Wiring Diagram - Danfoss FH-WS Datasheet

Data sheet

Wiring Diagram:

Dimensions
inches (mm):
Floor Sensor
Characteristics:
Danfoss can accept no responsibility for possible errors in printed materials and reserves the right to alter its products without notice.
All trademarks in this material are property of the respective companies. Danfoss and Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
2
FH-WS
Electronic Room Thermostat
Optional
Timer
Floor
Sensor
100
90
80
70
60
50
40
30
20
10
Danfoss
Toronto, ON
Toll Free: 866-676-8062
Tel.: 905-285-2050, Fax: 905-285-2055
www.na.heating.danfoss.com
VDSGA122 © Danfoss 03/10
Optional
Sensor
Signal
Neutral
Line
3.0
(77.5)
Temperature (˚F) vs Resistance (kOhms)
Floor Sensor for FH-WS
30 35 40 45 50 55 60 65 70 75
Temperature (˚F)
Optional External
Timer
(not included)
Floor
Actuator
Neutral
Line
2.4
(60)
80 85 90 95 100 105
Danfoss
Baltimore, MD
Toll Free: 866-375-HVAC (4822)
Tel.: 443-512-0266, Fax: 443-512-0270
www.na.heating.danfoss.com
24 Volt
Power
Source
