Pioneer DJM-1000 Service Manual page 152

1
No. Pin Name
A
MULTICHANNEL AUDIO SERIAL PORT 1 (McASP1) (CONTINUED)
146 HCNTL0/AXR0[12]/AXR1[3]
145 HCS/AXR0[13]/AXR1[2]
144 HCNTL1/AXR0[14]/AXR1[1]
143 HR/W/AXR0[15]/AXR1[0]
MULTICHANNEL AUDIO SERIAL PORT 0 (McASP0)
GP0[5](EXT_INT5)/AMUTEIN0
6
33 CLKX1/AMUTE0
B
19 CLKR0/ACLKR0
12 TINP1/AHCLKX0
16 CLKX0/ACLKX0
28 CLKS0/AHCLKR0
24 FSR0/AFSR0
21 FSX0/AFSX0
27 DR0/AXR0[0]/AXR1[15]
C
20 DX0/AXR0[1]/AXR1[14]
18 TOUT0/AXR0[2]/AXR1[13]
17 TINP0/AXR0[3]/AXR1[12]
13 TOUT1/AXR0[4]/AXR1[11]
32 DX1/AXR0[5]/AXR1[10]
36 CLKR1/AXR0[6]/AXR1[9]
D
38 FSR1/AXR0[7]/AXR1[8]
152 HD1/AXR0[8]/AXR1[7]
MULTICHANNEL AUDIO SERIAL PORT 0 (McASP0) (CONTINUED)
151 HDS1/AXR0[9]/AXR1[6]
150 HDS2/AXR0[10]/AXR1[5]
147 HD0/AXR0[11]/AXR1[4]
E
146 HCNTL0/AXR0[12]/AXR1[3]
145 HCS/AXR0[13]/AXR1[2]
144 HCNTL1/AXR0[14]/AXR1[1]
143 HR/W/AXR0[15]/AXR1[0]
F
152
1
2
I/O
Host control - selects between control, address, or data registers (I) [default] or McASP0 TX/RX
I/O/Z
data pin 12 (I/O/Z) or McASP1 TX/RX data pin 3 (I/O/Z).
Host chip select (I) [default] or McASP0 TX/RX data pin 13 (I/O/Z) or McASP1 TX/RX data pin 2
I/O/Z
(I/O/Z).
Host control - selects between control, address, or data registers (I) [default] or McASP0 TX/RX
I/O/Z
data pin 14 (I/O/Z) or McASP1 TX/RX data pin 1 (I/O/Z).
Host read or write select (I) [default] or McASP1 TX/RX data pin 0 (I/O/Z) or McASP0 TX/RX
I/O/Z
data pin 15 (I/O/Z).
I/O/Z General-purpose input/output 0 pin 5 and external interrupt 5 (I/O/Z) [default] or McASP0 mute input (I/O/Z).
I/O/Z McBSP1 transmit clock (I/O/Z) [default] or McASP0 mute output (O/Z).
I/O/Z McBSP0 receive clock (I/O/Z) [default] or McASP0 receive bit clock (I/O/Z).
I/O/Z Timer 1 input (I) [default] or McBSP0 transmit high-frequency master clock (I/O/Z).
I/O/Z McBSP0 transmit clock (I/O/Z) [default] or McASP0 transmit bit clock (I/O/Z).
McBSP0 external clock source (as opposed to internal) (I) [default] or McASP0 receive high-
I/O/Z
frequency master clock (I/O/Z).
McBSP0 receive frame sync (I/O/Z) [default] or McASP0 receive frame sync or left/right clock
I/O/Z
(LRCLK) (I/O/Z).
McBSP0 transmit frame sync (I/O/Z) [default] or McASP0 transmit frame sync or left/right clock
I/O/Z
(LRCLK) (I/O/Z).
McBSP0 receive data (I) [default] or McASP0 TX/RX data pin 0 (I/O/Z) or McASP1 TX/RX data
I/O/Z
pin 15 (I/O/Z).
McBSP0 transmit data (O/Z) [default] or McASP0 TX/RX data pin 1 (I/O/Z) or McASP1 TX/RX
I/O/Z
data pin 14 (I/O/Z).
I/O/Z Timer 0 output (O) [default] or McASP0 TX/RX data pin 2 (I/O/Z) or McASP1 TX/RX data pin 13
(I/O/Z).
Timer 0 input (I) [default] or McASP0 TX/RX data pin 3 (I/O/Z) or McASP1 TX/RX data pin 12
I/O/Z
(I/O/Z).
Timer 1 output (O) [default] or McASP0 TX/RX data pin 4 (I/O/Z) or McASP1 TX/RX data pin 11
I/O/Z
(I/O/Z).
McBSP1 transmit data (O/Z) [default] or McASP0 TX/RX data pin 5 (I/O/Z) or McASP1 TX/RX
I/O/Z
data pin 10 (I/O/Z).
McBSP1 receive clock (I/O/Z) [default] or McASP0 TX/RX data pin 6 (I/O/Z) or McASP1 TX/RX
I/O/Z
data pin 9 (I/O/Z).
McBSP1 receive frame sync (I/O/Z) [default] or McASP0 TX/RX data pin 7 (I/O/Z) or McASP1
I/O/Z
TX/RX data pin 8 (I/O/Z).
Host-port data pin 1 (I/O/Z) [ default] or McASP0 TX/RX data pin 8 (I/O/Z) or McASP1 TX/RX
I/O/Z
data pin 7 (I/O/Z).
Host data strobe 1 (I) [default] or McASP0 TX/RX data pin 9 (I/O/Z) or McASP1 TX/RX data pin
I/O/Z
6 (I/O/Z).
Host data strobe 2 (I) [default] or McASP0 TX/RX data pin 10 (I/O/Z) or McASP1 TX/RX data
I/O/Z
pin 5 (I/O/Z).
Host-port data pin 0 (I/O/Z) [ default] or McASP0 TX/RX data pin 11 (I/O/Z) or McASP1 TX/RX
I/O/Z
data pin 4 (I/O/Z).
Host control - selects between control, address, or data registers (I) [default] or McASP0 TX/RX
I/O/Z
data pin 12 (I/O/Z) or McASP1 TX/RX data pin 3 (I/O/Z).
Host chip select (I) [default] or McASP0 TX/RX data pin 13 (I/O/Z) or McASP1 TX/RX data pin 2
I/O/Z
(I/O/Z).
Host control - selects between control, address, or data registers (I) [default] or McASP0 TX/RX
I/O/Z
data pin 14 (I/O/Z) or McASP1 TX/RX data pin 1 (I/O/Z).
Host read or write select (I) [default] or McASP0 TX/RX data pin 15 (I/O/Z) or McASP1 TX/RX
I/O/Z
data pin 0 (I/O/Z).
DJM-1000
2
3
Pin Function
