Summary of Contents for Sharkoon X-Tatic S7

  • Page 1 Manual for use with...

  • Page 2: Package Contents

    Package contents...

  • Page 3: Basic Information

    ON/OFF switch for 3D stereo function SCU power on/off button Volume + Volume - Dolby Headphone button ® X-Tatic S7 headphone connector (G6) Analog output for speakers or non S7 headset (3.5 mm jack) Power/Source LED Dolby ProLogic IIx on/off LED ®...
  • Page 4 Cabling Required parts for PC with SCU Always connect the main USB connector of the USB2.0 Y cable! In case a single USB port of the connected device does not provide sufficient power, please also connect the supplementary USB connector of the USB2.0 Y cable. Sound Control Unit (SCU) USB2.0 Y cable (2x type A >...
  • Page 5 Cabling Required parts for PC without SCU G6 adapter cable (G6 > USB2.0 A and 2x 3.5 mm connectors) In case the USB port of your notebook Using the G6 adapter cable will disable does not provide sufficient power, the microphone volume controller! please switch off the amplifier function.
  • Page 6 Cabling Required parts for PC with other stereo headsets Sound Control Unit (SCU) USB2.0 Y cable (2x type A > type B) Remove the Optical connection protective caps! cable (S/PDIF) Stereo extension cable (3.5 mm plug > 3.5 mm jack)
  • Page 7 SCU settings SCU LED indications Dolby Digital 5.1 Input ® Dolby Headphone Output ® Gaming mode Music mode Stereo bypass Stereo Input Dolby Headphone Output ® Gaming mode Music mode Stereo bypass Press 1x: Dolby Headphone Gaming mode ® Press 2x: Dolby Headphone Music mode ®...
  • Page 8 Please act according to your local rules and do not dispose of your old products with your normal household waste. The correct disposal of As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change your old product will help prevent potential negative consequences to without prior notice.
