- Page 1 PX-E860 EZ(ST) SERVICE MANUAL STEREO TURNTABLE SYSTEM SPECIFICATIONS This Service Manual is the “Revision Publishing” and replaces “Simple Manual” PX-E860<EZST>(S/M Code No.09-993-322-0T1). S/M Code No. 09-993-322-0R3...
- Page 3 ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION 87-027-683-010 IC,TA7325 DIODE 87-001-783-080 DIODE,1N4002 PRE AMP C.B S8-E27-BK0-190 SIGNAL WIRE C102 87-015-995-810 CAP,E 4.7-50V C104 87-010-412-010 CAP,E 10-25V C107 87-015-995-810 CAP,E 4.7-50V C202 87-015-995-810 CAP,E 4.7-50V C204 87-010-412-010 CAP,E 10-25V C207 87-015-995-810 CAP,E 4.7-50V...
- Page 4 WIRING...
- Page 5 SCHEMATIC DIAGRAM...
- Page 6 MECHANICAL EXPLODED VIEW 1/1 SHIELD WIRE (WHITE) WIRE(BLK) GROUND SHEET SHIELD WIRE (RED) 10-1 10-2 U only K only STEEL CLAMPER EZ only (K only) 73 71 64 63 BOTTOM PLATE INSULATION SHEET...
- Page 7 MECHANICAL MAIN PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 67 S0-0B6-001-390 KNOB SHAFT 1 S0-3B6-000-260 HINGE ASS’Y 68 SP-EX8-509-000 CUE,KNOB(PXE860) 2 S4-B60-002-6A0 FOOT FOR DUST COVER(PXE850) 69 S0-0F7-002-590 KNOB SET 3 S0-SL2-4F1-180 PIN (FOR TONEARM SET) 70 S0-0L1-001-330 PULLEY...
- Page 8 COLOR NAME TABLE Basic color symbol Color Basic color symbol Color Basic color symbol Color Black Cream Orange Green Gray Blue Gold Pink Silver Titan Silver Brown Violet White Yellow 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 Printed in Singapore 931196...
