Page 1: Service Manual
TV-C142S KEJ4C SERVICE MANUAL COLOR TELEVISION • This Service Manual contains information about the difference between TV-C142S (KEJ4C) and TV-C142 (KEJ2NP). If requiring other information, see Service Manual of TV-C142 (KE). (S/M Code No. 09-974-156-7FP) S/M Code No. 09-00A-413-0S8... -
Page 2: Specifications
SPECIFICATIONS Category Audio Input Color television 0.5 Vrms., 33 kohms more Broadcasting color system Audio Output PAL (B/G, D/K), SECAM (B/G, D/K, K1) 0.5 Vrms., 2.2 kohms less Television color system (Video input) Speaker PAL, SECAM, NTSC , NTSC , PAL60 76 mm (3 in.) round 3.58 4.43... -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C101 87-A12-087-080 CAP,E 1-50 SMG C102 87-A12-072-080 CAP,E 100-25 SMG 86-LB7-622-010 IC,M37221M6-286SP C103 87-A11-132-080 CAP,TC U 0.01-50 KB 87-A21-133-080 IC,BMR-0101D C104 87-018-119-080 CAP,CER 100P-50 V 87-A21-377-010 IC,S-24C02BDP-1A C212... - Page 4 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C405 87-A12-090-080 CAP,E 4.7-50 SMG 87-A91-538-010 RCR UNIT,SBX1981-72P C406 87-A10-210-010 CAP,CER 0.047-50 M IC802 87-A30-096-010 P-COUPLER,TLP721F C407 87-018-209-080 CAP,CER 0.1-50 V IC803 87-A30-041-110 TR,SE115N C408 87-A10-730-080 CAP,E 1000-16 SMG ICP801 87-001-132-080 PROTECTOR,IC ICP-N38...
-
Page 5: Transistor Illustration
REF. NO. PART NO. KANRI DESCRIPTION L551 87-005-614-080 COIL,100UH J LAV35 R551 87-022-302-090 RES,M/F 12K-1W J R552 87-022-302-090 RES,M/F 12K-1W J R553 87-022-302-090 RES,M/F 12K-1W J SFR551 87-024-522-080 SFR,4.7K DIAV NTP SFR552 87-024-522-080 SFR,4.7K DIAV NTP SFR553 87-024-522-080 SFR,4.7K DIAV NTP SFR554 87-024-519-080 SFR,470 DIAV NTP... - Page 6 WIRING – 1 (MAIN) – 6 –...
- Page 7 WIRING – 2 (NK) – 7 –...
- Page 8 SCHEMATIC DIAGRAM (MAIN / NK) – 8 –...
-
Page 9: Mechanical Exploded View
MECHANICAL EXPLODED VIEW 1 / 1 NK C.B MAIN C.B a i w – 9 –... -
Page 10: Mechanical Parts List
