Aiwa TV-CN140NH Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TV-CN140
NH
SERVICE MANUAL
COLOR TELEVISION
• This Service Manual contains information about the difference between
TV-CN140(NH6L) and TV-CN140(NH1L). If requiring other information,
see Service Manual of TV-CN140(NH), (S/M Code No. 09-99A-418-7R1).
S/M Code No. 09-008-418-7S1

Advertisement

Table of Contents
loading

Related Manuals for Aiwa TV-CN140NH

Summary of Contents for Aiwa TV-CN140NH

  • Page 1 TV-CN140 SERVICE MANUAL COLOR TELEVISION • This Service Manual contains information about the difference between TV-CN140(NH6L) and TV-CN140(NH1L). If requiring other information, see Service Manual of TV-CN140(NH), (S/M Code No. 09-99A-418-7R1). S/M Code No. 09-008-418-7S1...

  • Page 2: Specifications

    SPECIFICATIONS Tuner System Frequency synthesized tuner Operatiing Voltage 120 V AC, 60 Hz TV System NTSC-M Power Consumption 65 W Channel Coverage VHF: 2 to 13 Earphone Jack Monaural-mini jack 5 °C – 40 ° C UHF: 14 to 69 Operating Temperature CATV: 5A, A-1 to A-5, A to W, Operating Humidity...
  • Page 3 ELETRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C210 87-018-115-080 CAP, CER 47P-50V C211 87-018-115-080 CAP, CER 47P-50V 8Z-JBH-622-010 IC,M37272M8-183SP C213 87-A10-326-080 CAP,M 3300P-50 K 87-A91-338-010 RCR UNIT,SBX1981-72P C214 87-A12-086-080 CAP,E 0.47-50 SMG 87-A21-433-010 IC,KS24CO41I C301...
  • Page 4 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C810 87-010-405-080 CAP,E 10-25 SME R801 8Z-JBH-629-080 RES,SD 2.2M-1/2W K ERC 12UG C811 87-A10-867-090 CAP,CER 2200P-2K K R R809 87-A00-277-090 RES,CEM 2.2-10W J RGC C812 87-A10-867-090 CAP,CER 2200P-2K K R R811 87-A00-189-010 RES,CEM 220-15W J ZY...
  • Page 5 WIRING – 1 (MAIN) – 5 –...
  • Page 6 SCHEMATIC DIAGRAM – 1 (MAIN) – –...
  • Page 7 WIRING – 2 (NK) – 7 –...

  • Page 8: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 P.C.B P.C.B LENS,LED – 8 –...

  • Page 9: Mechanical Parts List

    PART NO. KANRI DESCRIPTION 1 8Z-JBJ-007-010 PANEL,CONTROL CN140 2 86-LBU-010-010 LENS,RC 2 3 8Z-JBJ-006-010 CABI,FR CN140 4 87-054-087-010 BADGE,AIWA 40 5 88-JBL-011-010 PLATE,FOOT ST 6 86-LBU-201-010 HLDR,AC CORD 7 87-JBC-628-010 AC CORD SET,NH BLK 8 84-LB3-216-010 HLDR,LED 9 8Z-JBJ-606-010 CONN ASSY,2P V W SPMONO 10 84-LB3-641-010 SP,F DIA 7.6...
