Page 1: Digital Camera
ORDER NO. DSC0602009CE Digital Camera DMC-FX01PP DMC-FX01PL DMC-FX01EB DMC-FX01EE DMC-FX01EF DMC-FX01EG DMC-FX01EGM DMC-FX01GC DMC-FX01GD DMC-FX01GK DMC-FX01GN DMC-FX01GT DMC-FX01SG Vol. 1 Colour (S)...Silver Type (K)...Black Type (except GD) (W)..White Type (except PL/EE/GD/GK/GN) (P)...Pink Type (only PP/EE/GC/GK/GT/SG) (A)...Blue Type (only EE/EF/EG/EGM/GK) © 2006 Matsushita Electric Industrial Co., Ltd. All rights reserved. -
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE PAGE 1 Safety Precaution -------------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure 1.)--------3 1.4. How to Discharge the Capacitor on Flash Top PCB------------------------------------------------------------4 2 Warning --------------------------------------------------------------5 2.1. -
Page 3: Safety Precaution
1 Safety Precaution 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1.) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check. -
Page 4: How To Discharge The Capacitor On Flash Top Pcb
1.4. How to Discharge the Capacitor on Flash Top PCB CAUTION: 1. Be sure to discharge the capacitor on FLASH TOP PCB. 2. Be careful of the high voltage circuit on FLASH TOP PCB when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and Remove the necessary parts/unit. 2. -
Page 5: Warning
2 Warning 2.1. Prevention of Electro Static Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electro static discharge (ESD). -
Page 6: Caution For Ac Cord(For Eb/Gc
A replacement fuse cover can be purchased from your local 2.3.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety. -
Page 7: How To Replace The Lithium Battery
2.4. How to Replace the Lithium Battery 2.4.1. Replacement Procedure 1. Remove the SUB PCB. (Refer to Disassembly Procedures.) 2. Remove the Lithium battery (Ref. No. “Z9101” at component side of SUB PCB) and then replace it into new one. NOTE: This Lithium battery is a critical component. - Page 8 NOTE: Above caution is applicable for a battery pack which is for DMC-FX01 series, as well.
-
Page 9: Service Navigation
3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2. -
Page 10: How To Define The Model Suffix (Ntsc Or Pal Model)
3.4. How to Define the Model Suffix (NTSC or PAL model) There are seven kinds of DMC-FX01, regardless of the colours. • a) DMC-FX01S • b) DMC-FX01PP • c) DMC-FX01EB/EF/EG/EGM/GN • d) DMC-FX01EE • e) DMC-FX01GD • f) DMC-FX01GT • g) DMC-FX01PL/GC/GK/SG (DMC-FX01S is exclusively Japan domestic model.) -
Page 11: Initial Settings
1) As for your reference Default setting condition is given in the following table. • Default setting (After “INITIAL SETTINGS”) MODEL VIDEO OUTPUT LANGUAGE DATE REMARKS a) DMC-FX01S NTSC Japanese Year/Month/Date b) DMC-FX01PP/PL NTSC English Month/Date/Year c) DMC-FX01EB/EE/EF/EG/EGM/GC/GN/SG English Date/Month/Year d) DMC-FX01GK Chinese (simplified) Year/Month/Date e) DMC-FX01GT... -
Page 12: Specifications
4 Specifications... -
Page 13: Location Of Controls And Components
5 Location of Controls and Components... -
Page 14: Service Mode
6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 32 error codes in sequence from the latest. When the error is occurred more than 32, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (when the unit is powered on by the battery, the battery is pulled out) because the error code is memorized to FLASH ROM when the unit is powered off. - Page 15 Attribute Main item Sub item Error code Contents (Upper) High 4 bits Low 4 bits Check point (Lower) LENS Lens drive 1800 1000 PSD (X) error. Hall element (X axis) position detect error in OIS unit. OIS Unit 2000 PSD (Y) error. Hall element (Y axis) position detect error in OIS unit. OIS Unit 3000 GYRO (X) error.
- Page 16 Attribute Main item Sub item Error code Contents (Upper) High 4 bits Low 4 bits Check point (Lower) SOFT Reset 3000 0001 NMI reset Non Mask-able Interrupt 0007 (30000001-30000007 are caused by factors) Card Card 3100 0001 Card logic error SD card data line or IC6001 (VENUS PLUS) 0002 Card physical error...
-
Page 17: Confirmation Of Firmware Version
6.2. Confirmation of Firmware Version The Firmware version can be confirmed by ordering the following steps:. • Step 1. The temporary cancellation of factory setting: Set the mode dial to “[ Normal picture mode ] (Red camera mark)”. Insert the SD memory card which has a few photo data. While keep pressing [ Optical Image Stabilizer ] and “[ UP ] of Cross key”... -
Page 18: Service Fixture & Tools
7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit. -
Page 19: When Replacing The Main Pcb
7.2. When Replacing the Main PCB After replacing the MAIN PCB, be sure to achieve adjustment. The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-PAVC” web-site in “TSN system”, together with Maintenance software. 7.3. Service Position This Service Position is used for checking and replacing parts. -
Page 20: Disassembly And Assembly Instructions
8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart 8.2. PCB Location... -
Page 21: Disassembly Procedure
8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit Item Removal Rear Case Unit Fig. D1 Card Battery 2 Screws (A) 4 Screws (B) Side Ornament (R) Side Ornament (L) 1 Lock A 2 Locks B Fig. D2 FP9001(Flex) FP9002(Flex) Rear Case Unit LCD Unit... - Page 22 8.3.3. Removal of the Front Case Unit Fig. D2 8.3.2. Removal of the LCD Unit Fig. D4 8.3.4. Removal of the Top Operation Unit Fig. D3 Fig. D5...
- Page 23 8.3.5. Removal of the Flash Top P.C.B. 8.3.6. Removal of the Main P.C.B. Fig. D7 8.3.7. Removal of the Lens Unit Fig. D8 Fig. D6...
-
Page 24: Disassembly Procedure For The Lens
8.3.8. Removal of the Sub P.C.B. 8.4. Disassembly Procedure for the Lens NOTE: When Disassembling and Assembling for the Lens 1. To minimize the possibility of the CCD being dirt, perform disassemble and/or assemble under the condition of the CCD is being mounted. Disassembling procedures for the CCD unit, refer to item 8.6. - Page 25 4. Turn the drive gear to the indicated by arrow fully. 6. Push the 1st lens frame unit to the indicated by arrow from lens side, and then remove the unit of 1st lens frame/2nd lens frame move unit from the drive/direct frame unit.
-
Page 26: Assembly Procedure For The Lens
8.4.3. Removal of the 2nd Lens Frame 8.5. Assembly Procedure for the Move Unit Lens 8.5.1. Phase alignment of the Direct Frame and Drive Frame Unit... - Page 27 8.5.2. Phase alignment of the Drive/Direct 8.5.4. Assembly for the Zoom Motor Unit Unit and Fixed Frame Unit Master Frange Unit and 2nd Lens Frame Move Unit 8.5.3. Assembly for the 1st Lens Frame Unit...
-
Page 29: Removal Of The Ccd Unit
8.6. Removal of the CCD Unit 8.7. Applyment Grease To prevent the CCD unit from catching the dust and dirt, do not Method remove the CCD unit except for replacing. The grease apply point of lens unit are as follows. •... -
Page 30: Measurements And Adjustments
9 Measurements and Adjustments 9.1. Matrix Chart for Replaced Part and Necessary Adjustment The relation between Replaced part and Necessary Adjustment is shown in the following table. When concerned part is replaced, be sure to achieve the necessary adjustment(s). As for Adjustment condition/procedure, consult the “Adjustment Manual” which is available in Adjustment software. The Adjustment software is available at “TSN Website”, therefore, access to “TSN Website”... -
Page 31: Maintenace
10 Maintenace 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the their surface. Note: The Lens Cleaning KIT ;... - Page 32 Digital Camera "Standard-Playback" mode when there is no specify mode is mentioned. 4.Although the voltage and waveform available on here is measured with standard frame, DMC-FX01PP DMC-FX01EG DMC-FX01GN it may be differ from actual measurement due to modification of circuit and so on.
-
Page 33: S2. Voltage Chart
S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1. -
Page 34: S3. Block Diagram
S3. Block Diagram S3.1. Overall Block Diagram (28mm ~ 102mm) IC3004 IC3101 PRE PROCESS IC6003 SDRAM/256Mbit CDS,AGC,A/D, 1/25" 6 MEGA PIX ZOOM IRIS SHUTTER OIS UNIT FOCUS IC3002 CARD V-DRIVE IC7001 MOTOR DRIVE, OIS DRIVE& PRE PROCESS IC5001 AUDIO AMP MICROPHONE MICROPHONE AMP IC9003... -
Page 35: S3.2. System Control Block Diagram
S3.2. System Control Block Diagram FLASH TOP P.C.B. IC6001 (VENUS PLUS/MICRO PROCESSOR) IC6003 S8003 CL8007 CL8013 CL8014 CL8012 (SDRAM/256Mbit) ZOOM CONTROL SW CL9019 CL9018 PP9802 PS8001 PP9001 PS9801 PP9802 PS8001 SDBA1 TELE Bank Adr. Bank Adr. PP9001 PS9801 PP9802 PS8001 WIDE SDBA0 POWER SW ON(H) -
Page 36: S3.3. Video/Audio Process Block Diagram
S3.3. Video/Audio Process Block Diagram IC6003 (SDRAM/256Mbit) 256Mbit(2Mx32bitx4pcs) BANK0 BANK2 IC4001 (LCD COLOR DRIVER) BANK1 BANK3 COLUMN CL9037 CKV1 DECODER DECODER FP9001 Y DECODERS CL9038 STV1 FP9001 CL9042 PCG1 FP9001 I/O BUFFER & GATE ADDRESS BUFFER & REGISTER TIMING & MODE REGISTER CL9045 CLKIN CKH2... -
Page 37: S3.4. Sensor Block Diagram
S3.4. Sensor Block Diagram CL3012 CL3013 To IC8001-4 (FLASH TRG) To IC6001-279 (CCDVD) IC3101 IC3004 To IC6001-280 (CCDHD) (CCD IMAGE SENSOR) (CDS/AGC/AD/TG) FLASH VOUT Q3101 D0 39 CCD IN FP9801 12bit (PGA) (12bit) Q3102 IC3003 (AND GATE) VSUB CLI 24 SERIAL (24.75MHz) 20 RG... -
Page 38: S3.5. Lens Drive Block Diagram
S3.5. Lens Drive Block Diagram IC6001 (VENUS PLUS) FP9802 FHP LED PS9801 PP9001 260 FHP CO BARREL & FOCUS ENC ZHP LED MCK48O PS9801 PP9001 197 ZHP ZOOM ENC ZENC1 LED PS9801 PP9001 MCK48I 227 FZHP LEDCNT ZENC2 LED X6001 ZENC1 (48MHz) ZENC2... -
Page 39: S3.6. Power Block Diagram
S3.6. Power Block Diagram CL2004 CL1003 JK2002 F1100 UNREG+ UNREG CL1004 CL1008 CL1010 CL1002 BATTERY TERMINAL Q1102 AF3.4V (MOS-FET: Pch) A3.1V QR1001 IC1001 (7CH SW REGULATOR IC) VOUT Q1100 CL1009 (MOS-FET: Nch) VBAT CONTROL CIRCUIT OVER HEAT& OVER CURRENT IC1002 D1005 PROTECTION (REGULATOR) -
Page 40: S4. Schematic Diagram
S4. Schematic Diagram S4.1. Interconnection Diagram P8001 FLASH TOP P.C.B. PS8001 (FOIL SIDE) P8002 AF ASSIST LED P.C.B. (COMPONENT SIDE) TL9902 TL9901 BATTERY FP9001 LCD UNIT VVDD SUB P.C.B. MAIN P.C.B. (FOIL SIDE) (FOIL SIDE) : (COMPONENT SIDE) : (COMPONENT SIDE) LCD B LCD R LCD G... -
Page 41: S4.2. Flash Top Schematic Diagram
S4.2. Flash Top Schematic Diagram CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 1.25A 32V FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES 1.25A 32V D' INCENDIE N' UTILISERQUE DES FUSIBLE DE MEME TYPE 1.25A 32V. 1.25A 32V DMC-FX01 Flash Top... -
Page 42: S4.3. Af Assist Led Schematic Diagram
S4.3. AF Assist LED Schematic Diagram / S4.4. CCD Flex Schematic Diagram DMC-FX01 DMC-FX01 AF Assist LED CCD Flex Schematic Diagram Schematic Diagram S-11... -
Page 43: S4.5. Lens Flex Schematic Diagram
S4.5. Lens Flex Schematic Diagram POSITIVE VOLTAGE LINE FMAP STEPPING COIL FOCUS MOTOR UNIT FMAN MOTOR FMBN COIL FMBP ZENC2_LED ZENC2 B/C3 PHOTO ZOOM ENCODER 2 SENSOR ZOOM ENCODER 1 ZENC1_LED ZENC1 DCM+ DCM+ DC MOTOR ZOOM MOTOR UNIT DCM- DCM- SHUT2 SHUT2... -
Page 44: S5. Print Circuit Board
S5. Print Circuit Board S5.1. Flash Top P.C.B. / S5.2. AF Assist LED P.C.B. (Component Side) (Component Side) (Foil Side) (Foil Side) DMC-FX01 DMC-FX01 Flash Top P.C.B. AF Assist LED P.C.B. S-13... -
Page 45: S5.3. Ccd Flex P.c.b
S5.3. CCD Flex P.C.B. (Component Side) (Foil Side) DMC-FX01 CCD Flex P.C.B. S-14... -
Page 46: S5.4. Lens Flex P.c.b
S5.4. Lens Flex P.C.B. ZOOM MOTOR OIS UNIT UNIT ZOOM ENCODER SHUTTER UNIT FOCUS ENCODER Pin 39 ZOOM ENCODER 2 Pin 1 ZOOM ENCODER 1 FOCUS MOTOR UNIT DMC-FX01 LENS FLEX P.C.B. S-15... - Page 47 S-16...
-
Page 48: S6. Replacement Parts List
S6. Replacement Parts List Note: 1.* Be sure to make your orders of replacement parts according to this list. 2. IMPORTANT SAFETY NOTICE Components identified with the mark have the special characteristics for safety. When replacing any of these components, use only the same type. 3. - Page 49 DMC-FX01SG-S/K/W/P, PP-S/K/W/P, GK-S/K/P/A, GN-S/K, GC-S/K/W/P, EB-S/K/W, EG-S/K/W/A, EF-S/K/W/A, EGMS/K/W/A, GD-S, GT-S/K/W/P, PL-S/K, EE-S/K/P/A Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ------ P.C.B. LIST ------ VEP56032A MAIN P.C.B. 1 (RTL) E.S.D. VEP51004A SUB P.C.B.
- Page 50 DMC-FX01SG-S/K/W/P, PP-S/K/W/P, GK-S/K/P/A, GN-S/K, GC-S/K/W/P, EB-S/K/W, EG-S/K/W/A, EF-S/K/W/A, EGMS/K/W/A, GD-S, GT-S/K/W/P, PL-S/K, EE-S/K/P/A Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3108 ERJ2GEJ220 M.RESISTOR CH 1/16W 22 R3109 ERJ2GEJ101 M.RESISTOR CH 1/16W 100 VEP58019A FLASH TOP P.C.B.
- Page 51 DMC-FX01SG-S/K/W/P, PP-S/K/W/P, GK-S/K/P/A, GN-S/K, GC-S/K/W/P, EB-S/K/W, EG-S/K/W/A, EF-S/K/W/A, EGMS/K/W/A, GD-S, GT-S/K/W/P, PL-S/K, EE-S/K/P/A Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VHD1843 SCREW VHD1843 SCREW VEP51004A SUB P.C.B. 1 (RTL) E.S.D. VHD1694 SCREW VEP56032A MAIN P.C.B.
- Page 52 DMC-FX01SG-S/K/W/P, PP-S/K/W/P, GK-S/K/P/A, GN-S/K, GC-S/K/W/P, EB-S/K/W, EG-S/K/W/A, EF-S/K/W/A, EGMS/K/W/A, GD-S, GT-S/K/W/P, PL-S/K, EE-S/K/P/A Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks 214 VQT0W20 INSTRUCTION BOOK 1 EE (UR) VQT0W47 O/I PC CONNECTION 1 SG,GC VPF1224 CAMERA BAG...
- Page 53 DMC-FX01SG-S/K/W/P, PP-S/K/W/P, GK-S/K/P/A, GN-S/K, GC-S/K/W/P, EB-S/K/W, EG-S/K/W/A, EF-S/K/W/A, EGMS/K/W/A, GD-S, GT-S/K/W/P, PL-S/K, EE-S/K/P/A Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPF1224 CAMERA BAG 301 ------------ BATTERY 302 DE-A11B BATTERY CHARGER RP-SD016BVE0 SD CARD VFC4090 HAND STRAP...
-
Page 54: S7. Exploded View
S7. Exploded View S7.1. Frame and Casing Section B101 B102 B103 B104 B105 B106 B107 S-23... -
Page 55: S7.2. Packing Parts And Accessories Section (1
S7.2. Packing Parts and Accessories Section (1) (DMC-FX01EB/GC/SG) (DMC-FX01 EE/EF/EG/EGM/GC/SG) (DMC-FX01GD) (DMC-FX01GK/GT) (DMC-FX01GN) S-24... -
Page 56: S7.3. Packing Parts And Accessories Section (2
S7.3. Packing Parts and Accessories Section (2) S-25...
