LevelOne GNC-0107 Specifications

1000BASE-SX Fiber Optic
PCI Card (SC)
H/W Version: 1
Product Overview
The LevelOne GNC-0107 Fiber Gigabit Ethernet
Network Interface Card provides network connectivity
within high-speed Fiber-Optic networks. The high
bandwidth network interface card provides full-
duplex network data speeds of up to 2000Mbps
and support an array of advanced network interface
functionality.
High-Speed Network Interface
The GNC-0107 Gigabit Fiber PCI Card supports a 32 or
64 bits PCI bus configuration for servers that require
a high-bandwidth environment. It is IEEE802.3x
compliant, providing full-duplex flow control for
2Gbps network data transfer speeds over a 550 meter
fiber connection. It also requires less server resources
Key Features
- High-Speed Fiber-Optic network interface card
- Supports 2Gbps Full-Duplex mode
- Full-Duplex Switching: 550m
- Supports 32/64 bits PCI bus configuration
- Compliant with IEEE 802.1Q VLAN
- Supports 802.3ad Link Aggregation
- Compliant with IEEE 802.1p QoS
- Supports on-board IP header verification and TCP/
UDP checksum offload
- Supports Multiple Operating Systems
2
by providing on-board verification of IP headers and
TCP/UDP checksums for received data.
Advanced Networking
The Gigabit Fiber PCI Card provides high-level VLAN
filtering and on-board screening of IEEE 802.3Q VLAN
tagged Ethernet frames for secured and flexible
network usage while IEEE 802.1p (QoS) Quality of
Service protocol support allows for a Layer 2 priority
network data traffic interface and dynamic multicast
filtering.
The GNC-0107 Gigabit Fiber PCI Card further supports
a 9K Jumbo Frame Rate, IEEE 802.3ad link aggregation,
Pre-Boot Execution Environment (PXE), Multi-Boot
Agent (MBA), Remote Program Load (RPL) and
Bootstrap Protocol (BOOTP).
1 2
Works Well With
1. LEDs
2. 1000SX SC-Type Fiber Port
GSW-2476
24-Port TP w/ 4-Port shared SFP
Web Smart Gigabit Ethernet
Switch
GSW-2494
24-Slot TP w/ 2-Port shared
SFP L2 SNMP Gigabit
Ethernet Switch
GNC-0107
