- Page 1 FR-AQ505 FR-A506 SERVICE MANUAL RADIO RECEIVER This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-995-331-9T1). S/M Code No. 09-995-331-9R1...
-
Page 2: Specifications
SPECIFICATIONS FR-AQ505: FR-A506: • • Design and specifications are subject to change without Design and specifications are subject to change without notice notice... -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION CHIP RESISTOR PART CODE L101 88-RU7-626-010 COIL,RF 4.5X3.5T Chip Resistor Part Coding L102 88-RU7-626-010 COIL,RF 4.5X3.5T 87-A21-200-010 IC,LM8562 L105 88-RU7-607-010 BAR-ANT,MW<AQ505EZ> 87-A20-898-010 IC,TDA1083 L107 87-003-146-080 COIL,15UH LAL02 88-RU7-644-010... - Page 4 WIRING SW1 C.B SLEEP ALARM /OFF DOWN ALARM SLEEP L105 MAIN C.B POWER STANDBY ALARM MODE BAND ALARM VOLUME BUZZER RADIO MODEL MODEL 506 MODEL PVC1 MODEL MODEL 15 16 DIMMER HIGH PT101 506 MODEL MODEL BATT DC 9V MODEL SP102 (R CH) PHONES...
-
Page 5: Schematic Diagram
SCHEMATIC DIAGRAM MAIN C. B. PHONES PVC1B L107 15uH L104, PVC1B FM FREQ. ADJ. 470/16 PVC1A T103, 104 AM IF ADJ. L102, PVC1A FM TRACKING ADJ. T101, 102, 105 FM IF ADJ. S101 PVC 1 (A-B) BAND TUNING 505 MODEL PVC1C IF AMP/DET/ 506 MODEL... -
Page 6: Ic Block Diagram
IC BLOCK DIAGRAM ELECTRICAL ADJUSTMENT IC, LM8562 IC, TDA1083... -
Page 7: Voltage Chart
VOLTAGE CHART... -
Page 8: Mechanical Parts List
MECHANICAL PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 88-RU7-127-010 CABI,FRONT EZ2 B<A506EZ> 19 88-RU7-209-010 GEAR,TUN POINTER 1 88-RU7-131-010 CABI,FRONT V<AQ505EZ> 20 88-RU7-203-010 GEAR,POLYVARI 2 88-RU7-106-010 BTN,SNOOZE B 21 88-RU7-102-010 CABI,REAR B 3 88-RU7-119-010 WINDOW,DIAL EZ B<AQ505EZ>... -
Page 9: Mechanical Exploded View
MECHANICAL EXPLODED VIEW 1/1... -
Page 10: Accessories/Package List
ACCESSORIES/PACKAGE LIST REF. NO PART NO. KANRI DESCRIPTION 1 88-RU7-917-010 IB,EZ(6L)C A506<A506EZ> 1 88-RU7-918-010 IB,EZ(PHNCZ)C A506<A506EZ> 1 88-RU7-927-010 IB,EZ(6L)C AQ505<AQ505EZ> 1 88-RU7-928-010 IB,EZ(PHNCZ)C AQ505<AQ505EZ> 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 737004...
