Cisco Video Surveillance 7030 IP Camera
The Cisco
functioned video endpoint with industry-leading image quality and processing power.
The camera is capable of a 2560 x 1920 resolution while optimizing network utilization
with either H.264 or MJPEG compression. Contact closures allow integration with
access control systems. With its open, standards-based design, the camera provides
an ideal platform for integration and operation as an independent device or as part of
a Cisco Video Surveillance network.
The Cisco Video Surveillance 7030 IP Camera offers a variety of benefits, including:
●
True high-definition video: The camera streams crisp and clear video at resolutions up to 2560 x 1920
while maintaining low network bandwidth.
●
Outdoor-ready: An IK10 and IP66-rated enclosure enables outdoor mounting.
●
Dual streaming: The camera can stream H.264 and MJPEG video simultaneously. Each video stream can
be configured with individual resolution, quality, and frame rate settings.
●
Day/night operation: The camera provides true day/night functionality and includes an infrared filter that
automatically switches to night mode in low-light scenes. This function can be set to manual, automatic, or
scheduled control.
●
Integrated infrared illuminator: The infrared illuminator can light an area up to 20 meters away.
●
Privacy regions: The camera supports up to four user-defined privacy regions. Any video within a privacy
region is masked in the video stream.
●
Local storage: Video data can automatically be recorded to a microSD card when the camera loses
network connectivity.
●
Bidirectional audio: The camera supports full-duplex audio and options for half-duplex operation.
●
Open API: Support for ONVIF 2.0 allows for standards based interoperability and communications with
other ONVIF appliances.
●
Flexible power options: The camera supports Power over Ethernet (PoE) 802.3af or 24 VAC power
through an optional external power supply.
●
Medianet support: The camera supports the Cisco Medianet interface. When connected to a Cisco switch
that also supports Medianet, the switch recognizes the camera as a video endpoint and then uses
SmartPort macros to set the right network parameters for the video stream on the network. In addition, the
camera can be automatically discovered and configured when connected to Cisco Video Surveillance
Manager 7.0, thereby minimizing installation time and cost.
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public.
®
Video Surveillance 7030 IP Camera is an outdoor, high-definition, full-
Data Sheet
Page 1 of 7

Advertisement

loading

Related Manuals for Cisco 7030

Summary of Contents for Cisco 7030

  • Page 1 ● Medianet support: The camera supports the Cisco Medianet interface. When connected to a Cisco switch that also supports Medianet, the switch recognizes the camera as a video endpoint and then uses SmartPort macros to set the right network parameters for the video stream on the network. In addition, the camera can be automatically discovered and configured when connected to Cisco Video Surveillance Manager 7.0, thereby minimizing installation time and cost.
  • Page 2 Features Table 1 describes the features of the Cisco Video Surveillance 7030 IP Camera. Table 1. Cisco Video Surveillance 7030 IP Camera Features Item Specification Imaging device 1/2.5-in. progressive-scan CMOS Image control Automatic white balance (AWB), automatic gain control (AGC), automatic exposure shutter (AES), and auto...
  • Page 3 Table 2 lists the video stream support for the Cisco Video Surveillance 7030 IP Camera. Table 2. Cisco Video Surveillance 7030 IP Camera Video Stream Support Primary (H.264) Maximum fps Secondary (H.264 or MJPEG) Maximum fps 2560x1920 1920 x 1080...
  • Page 4 160 x 96 160 x 96 Table 3 lists the video stream support for the Cisco Video Surveillance 7030 IP Camera for 4:3 aspect ratios. Table 3. Cisco Video Surveillance 7030 IP Camera Video Stream Support for 4:3 Aspect Ratios Primary (H.264)

  • Page 5: Specifications

    Connectors Table 4 describes the connectivity and connectors of the Cisco Video Surveillance 7030 IP Camera. Table 4. Cisco Video Surveillance 7030 IP Camera Connectors Item Specification Network connectivity 100 BASE-TX Ethernet with RJ-45 connector Alarm input Three logic level programmable...

  • Page 6: Package Contents

    Figure 1. Cisco Video Surveillance 7030 IP Camera Dimensions All dimensions are in millimeters. Package Contents Table 7 describes the items that ship with the Cisco Video Surveillance 7030 IP Camera. Table 7. Package Contents Item Cisco Video Surveillance 7030 IP Camera...

  • Page 7: Ordering Information

    Services and Support Cisco and our certified partners can help you accelerate success and improve the return on your investment in a Cisco Physical Security solution. The Cisco lifecycle approach to services defines the requisite activities at each phase of the solution lifecycle: ●...
