Packing And Accessories - Sharp R-820BC Supplemental Service Manual

R-820BC
REF. NO. PART NO.
6-14 TLABNB032WRRZ
7- 1 XFPSD40P08K00
7- 2 XEPSD40P25000
7- 3 LX-EZA042WRE0
7- 4 LX-NZ0061WRE0
7- 5 XBPWW30P05K00
7- 6 XCTWW40P08000
7- 7 XHPSD30P06000
7- 8 XHTSD40P08RV0
7- 9 XOTSD40P12RV0
7-10 XOTSD40P12000
7-11 *************
7-12 XOTSF40P08000
7-13 XBTSD40P05000
7-14 XNEUW40-32000
7-15 XRESE40-06000
7-16 XWHUW40-08000
7-17 XWHUW48-08120
7-18 XWSUW40-10000
7-19 LX-CZA070WRE0
7-20 XCPSD40P08000
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.

PACKING AND ACCESSORIES

Touch guide
SCREWS,NUTS AND WASHERS
Screw : 4mm x 8mm
Screw : 4mm x 25mm
Special screw
Flange nut
Screw : 3mm x 5mm
Screw : 4mm x 8mm
Screw : 3mm x 6mm
Screw : 4mm x 8mm
Screw : 4mm x 12mm
Screw : 4mm x 12mm
These line head screws have been changed to 7-9.
Screw : 4mm x 8mm
Screw : 4mm x 5mm
Nut : 4mm x 3.2mm
Ring : 4mm x 0.6mm
Washer : 4mm x 0.8mm
Washer : 4.8mm x 0.8mm
Washer : 4mm x 1.0mm
Special screw (Torx tamper proof screw)
Screw : 4mm x 8mm
HOW TO ORDER REPLACEMENT PARTS
2. REF. NO.
TRAY HOLDER
(SPADFA424WRE0)
TURNTABLE TRAY
RACK
DOOR PROTECTION SHEET
(SPADPA204WRE0)
LAMP CAUTION
TOUCH GUIDE
INSTRUCTION BOOK
TURNTABLE SUPPORT
FOAM SHEET
(SPAKHA012WREZ)
TRAY PAD
(SPADPA577WRE0)
Not Replaceable Items.
DESCRIPTION
3. PART NO.
8
Q'TY CODE
1 AK
13 AA
2 AA
2 AB
4 AA
2 AA
8 AB
1 AA
3 AA
13 AA
10 AA
0 --
1 AA
2 AA
1 AA
1 AA
1 AA
1 AA
1 AA
2 AC
1 AA
4. DESCRIPTION
TOP PAD ASSEMBLY
(FPADBA381WRK0)
WRAP COVER
(SSAKHA034WRE0)
PLASTIC SHEET
(SPADPA616WREZ)
CABINET COVER
(SPAKHA009WRE0)
BOTTOM PAD ASSEMBLY
(FPADBA382WRK0)
PACKING CASE
FPAK-A505WRKZ
