X8STi/X8STi-F/X8STi-3F/X8STi-LN4 Jumpers
JPUSB1 BP USB0/1 Wake-up
JPUSB2 FP USB 2/3, 4/5 Wake-up
JPUSB3 FP USB 6, 7 Wake-up
JWD Watch Dog Timer Enable
X8STi/X8STi-F/X8STi-3F/X8STi-LN4 Headers/Connectors
Connector
COM1/COM2
Fans 1~6
Floppy
I-Button (For X8STi-3F)
JAR
JD1
JF1
JL1
JLED
JOH
JPW1
JPW2
JPWF
JWOL
KB/Mouse
LAN1~LAN4
(IPMI) LAN
NIC3_LED, NIC4_LED
I-SATA 0~5
SAS 0~3, 4~7
SMB_PS1
SPKR1
3-SGPIO-0/1
T-SGPIO-0/1
UID Switch
USB0/1, USB 2/3, 4/5,
USB6, 7
VGA
Description
COM1/2 Serial connection headers
System/CPU fan headers
Floppy Disk Drive connector
I-Button for RAID data storage (See P. 2-27 for more info.)
Alarm Reset
Speaker header (Pins 3/4: Internal, 1~4:External)
Front Panel Control header
Chassis Intrusion header
Power LED Indicator header
Overheat LED header
24-pin ATX main power connector (required)
+12V 8-pin CPU power connector (required)
Power-Fail indication header
Wake-On-LAN header
Keyboard/mouse connectors
Gigabit Ethernet (RJ45) ports (LAN3/4: X8STi-LN4)
IPMI Dedicated LAN (X8STi-F/-3F only)
LAN 3/LAN 4 LED Connectors for front access (X8STi-LN4)
Serial_ATA ports
SAS Ports (X8STi-3F only)
PWR supply (I 2 C) System Management Bus
Internal speaker/buzzer
Serial_link IO headers for SAS (X8STi-3F)
Serial General Purpose IO headers (for SATA)
Backplane USB 0/1, Front panel accessible USB 2/3, 4/5,
USB 6, USB 7
Onboard Video Port
1-5
Chapter 1: Introduction
Pins 1-2 (Enabled)
Pins 2-3 (Disabled)
Pins 2-3 (Disabled)
Pins 1-2 (Reset)
