Land Pride CA25 Series Features And Benefits

Core Aerators
Features and Benefits
Core Aerators
Features
3 Sizes 48", 60" & 72"

Cat. 1 Hitch

Plate steel 'A' frame
Tubular Construction
Expanded metal in weight tray

Hardened steel spoons

Individual Spoon
Replacement

Gang spacing

Spoon gangs

Spoon gang greasing

Storage stands

Spoon spacing – forward
travel

Sq. foot aeration

Optional Water Tanks
CA2560 & CA2572 Only
Designs, specifications, features and information are subject to change without notice.
1/02/09
CA25 Series
Great sizes for small landscapers to golf courses, campuses, cities.
Fits Land Pride Quick-Hitch, and stout enough to work with any Cat. 1 tractor.
Plate steel offers greater strength from natural force applied downward from tractor top
link.
2 1/2" x 2 1/2" x 3/16" Tubing vs. angle iron offers greater strength as well as gives a better
appearance.
Adds safety over spoon area, doesn't allow foreign weight object to fall into spoon area,
keeps cores from being thrown forward.
3/4" ID spoons, with 3 mm wall thickness and beveled edge penetrate the ground easier
than thicker OD spoons, but are just as strong.
Requires removal of only two bolts to replace a worn-out spoon. Don't have to
disassemble the whole rotary section to get to the spoons.
6 1/2" on 48" & 72" Units, 5 1/2" on 60" unit offers optimum core pulling pattern.
Spoon gangs are independent of each other allowing for less side load torque on each
gang and tearing of the turf during turns.
Each gang has a grease zerk for smooth rotation.
Each corner has a storage stand to aid in off the ground storing, as well as aiding in
hooking to the tractor.
7" Spacing in forward travel offers optimum aeration.
4 Cores per sq. ft. on 48" & 72" units, and 6 cores on 60" for optimum aeration.
Easily add up to 490 lbs. to the 60" and 600 lbs. to the 72" to aid in compacted soil
conditions. Can easily reduce weight by draining tank incrementally. Water tanks are safer
due to precise fit and fastening vs. stacking inconsistent sized objects and difficulty in
uniform fastening.
Benefits
14
325-020F
