1.2 LEDs and Interfaces

Front Panel
The following table describes the LEDs of the device.
LEDs Color
Power Green
Red
DSL Green
Internet Green
Red
LAN4/3 Green
/2/1
Status
On The device is powered on or the initiation of
the device is successful.
Off The device is powered off.
On The device is self-testing, the self-test is
failed or the software is upgrading.
On The device has established a connection
with the physical layer of the office end.
Slow No signal is being detected.
Blinks
Fast The device is handshaking with the
Blinks physical layer of the office end.
On The
connection (PPP dial-up is successful) in
the routing mode and no data is being
transmitted on the Internet.
Blinks Data is being transmitted on the Internet in
the routing mode.
Off The device is in the bridged mode.
On In the routing mode, after the successful
synchronization, the WAN connection is
failed (PPP dial-up is failed).
On The
activated.
Blinks Data is being transmitted on the LAN or
data is being transmitted on the Internet in
the bridged mode.
2
GO-DSL-N150
Description
device has a
LAN connection
User Manual
successful WAN
is nomal and
