Honeywell HMLCD17L User Manual

L-series lcd monitor
Hide thumbs

Advertisement

HMLCD17L, HMLCD19L
L-Series LCD Monitor

User Manual

Document 800-00945 – Rev A – 09/07

Advertisement

loading

  Also See for Honeywell HMLCD17L

  Related Manuals for Honeywell HMLCD17L

  Summary of Contents for Honeywell HMLCD17L

  • Page 1: User Manual

    HMLCD17L, HMLCD19L L-Series LCD Monitor User Manual Document 800-00945 – Rev A – 09/07...
  • Page 2 Revisions Issue Date Revisions Sept 2007 Initial Release...
  • Page 3: Fcc Compliance Statement

    • Plug the system into a different outlet so that the system and the receiver are on different branch circuits. If necessary, consult a representative of Honeywell Inc. or an experienced radio/television technician for additional suggestions. The following information is provided on the device or devices covered in this document in compliance with the FCC regulations: •...
  • Page 4 Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock. To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor case. Never use your monitor if the power cable has been damaged. Do not allow anything to rest on the power cable. Keep the power cable away from where people could trip over it.
  • Page 5: Table Of Contents

    Contents Controls and Functions ......... . . 11 OSD Menu .
  • Page 6 Contents...
  • Page 7 Figures Figure 1 Front panel controls........11 Figure 2 Back panel connectors .
  • Page 8 Figures...
  • Page 9 Tables Table 1 Power Consumption ........17 Table 2 LED Indicator .
  • Page 10 Tables...
  • Page 11: Controls And Functions

    Controls and Functions The HMLCD17L and HMLCD19L monitors include the following features: • OSD menu • MPR II certified • DDC1 and DDC2 plug and play functionality • Full range power supply that auto adjusts to accept AC 100V to 240V and 50Hz to...
  • Page 12: Figure 2 Back Panel Connectors

    Controls and Functions Back Panel Controls Figure 2 Audio-in DC power-in VGA-in (D-Sub connector) Video-in (RCA) Video2-in (BNC) Video3-in (BNC) Video3-loop-out (BNC) Audio-in-Right (Video mode) Audio-in-left (Video mode) How to Install the Power Cable: Plug the AC/DC adapter into the DC power-in. Connect the AC power cable to the adapter.
  • Page 13: Osd Menu

    OSD Menu Using the menu: There are two options for configuring the Monitor display: AUTO and MENU. Press AUTO to configure the monitor automatically without user input. Press MENU to enable the monitor to be configured using the OSD menus described below. To scroll through the main menu and select sub menu options use the s and t buttons on the front panel of the monitor.
  • Page 14: Figure 4 Picture Settings

    OSD Menu Picture: Figure 4 H Position Move the picture horizontally on the screen right and left. V Position Move the picture vertically on screen up and down. Phase Adjust the number of horizontal picture elements. Clock Adjust the vertical noise of the screen image. Sharpness Adjust background black level of the screen image.
  • Page 15: Figure 6 Osd Menu Settings

    OSD Menu: Figure 6 Language Select the required supported language from the list. OSD H. Position OSD window horizontal position adjustment. OSD V. Position OSD window vertical position adjustment. OSD Timer Set the OSD screen standby time. Translucent Set the translucency of the OSD. Misc: Figure 7 Signal Source...
  • Page 16 OSD Menu Volume Adjust the monitor audio volume.
  • Page 17: Power Management

    Power Management The power management function for this monitor is controlled by the computer to which it is connected. This monitor enters an appropriate mode as designated by the computer.The stage that the power management system is in is indicated by the LED on the monitor.
  • Page 18: Specifications And Parts

    Specifications and Parts Specifications and Parts Figure 8 HMLCD17L HMLCD19L Monitor dimensions 388mm 388mm 15.28" 98.56" 390mm 390mm 15.35" 99.06" 6.61" 42.67" 168mm 168mm 16.69" 424mm 6.85" 174mm...
  • Page 19: Table 3 Specifications List

    Table 3 Parameter LCD Type Resolution (H x V) Frequency Input Signal Active Display Area (W x H) Dimensions (W x H x L) Weight Power Supply Power Consumption Environment Table 4 Mode Document 800-00945 Rev A 09/07 Specifications list Description Pixel pitch(mm): 0.264(H) 0.264(W) Maximum Pixel Rate: 100MHz...
  • Page 20: Table 5 Parts List

    Specifications and Parts Table 4 Mode Table 5 Part LCD Monitor AC Power Cable Audio Cable VGA Cable DC Power Adapter User Manual Note: technical specifications and parts are subject to change without notice. Pre-Set Display Mode Resolution Horizontal Frequency 1024 x 768 56.5 KHz / 70.1 KHz 1024 x 768...
  • Page 21: Troubleshooting

    Troubleshooting Issue: Possible Solution: Issue: Possible Solution: Issue: Possible Solution: Issue: Possible Solution: Issue: Document 800-00945 Rev A 09/07 No image is displayed on screen. • Check that the power cord has been connected securely into the wall outlet or grounded extension cable or surge protector. •...
  • Page 22 Troubleshooting Possible Solution: Issue: Possible Solution: If red, green or blue are not displayed on the screen, check whether the display cable is properly connected. Sync problem between the monitor and PC • Check if the display input signal is within the specified range (56 - 75 Hz).
  • Page 23 NOTES:...
  • Page 24 ' +34.902. 667.800 © 2007 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell Video Systems. The information in this publication is believed to be accurate in all respects. However, Honeywell Video Systems cannot assume responsibility for any consequences resulting from the use thereof.

This manual is also suitable for:

Hmlcd19l
