American Standard Silhouette 7145.001 Specification Sheet

SILHOUETTE™ 33" DOUBLE BOWL
KITCHEN SINK
• Americast brand engineered material
®
• Dual level double bowl design
• Titanium enamel - heat resistant up to 1000°
• Acid-resisting glossy porcelain finish
• Top mount or undercounter installation
• Silicone sealant supplied
• Available in 1, 3, 4, or 5 faucet hole
configuration
• Customized hole punchings available
(see page G56)
Top Mount/Undercounter:
❏ 7145.001 Center hole only
❏ 7145.803 3 hole
❏ 7145.804 4 hole
❏
7145.805 5 hole
Undercounter Installation Order:
❏
791326-100 Mounting Kit (consists of
cut-out templates and mounting clips)
Nominal Dimensions:
838 x 559 x 241mm
(33" x 22" x 9-1/2")
Bowl sizes:
Right Hand: 359mm (14-1/8") wide
413mm (16-1/4") front to back
229mm (9") deep
Left Hand: 359mm (14-1/8") wide
476mm (18-3/4") front to back
229mm (9") deep
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• ASME A112.19.4M for Americast Plumbing Fixtures
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE SIDE FOR ROUGHING-IN DIMENSIONS
© 2008 AS America Inc.
DOUBLE BOWL SINK
Top Mount Installation
(faucet & soap dispenser not included)
Undercounter Mount Installation
(faucet not included)
To Be Specified:
❏ Color:
❏ Faucet*:
❏ Faucet Finish:
❏ Basket Strainer: 4331.013
❏ Soap Dispenser: 4503.115, (specify color):
❏ Traps:
Optional Accessories:
❏ Large Wood Cutting Board: 9000.250
❏ Small Wood Cutting Board: 9000.185
❏ Colander for Cutting Board: 8102.100, Color:
❏ Large Colander: 8103.100, Color:
❏ Web Cover: 8106.100, Color:
❏ Bottom Sink Rack (Left): 7405.100, Color:
❏ Bottom Sink Rack (Right): 7406.100, Color:
* See faucet section for available models
G27
SILHOUETTE™ 33"
AMERICAST
Revised 2/08
®
