Tripp Lite PDUMNH20 Quick Manual

Single-Phase Monitored PDU, 1.9kW 20A 120V, 1U
Horizontal Rackmount, 8 NEMA 5-15/20R outlets,
NEMA L5-20P input with 5-20P adapter
MODEL NUMBER: PDUMNH20
Description
Tripp Lite single phase Monitored PDU /Power Distribution Unit offers real-time remote monitoring of
voltage,frequency and load levels via built-in network connection. PowerAlert interfacesupports custom
notification of user-specified remote conditions via email,secure web, SNMP, Telnet or SSH interface. PDU
lighted digital display enablesvisual monitoring of PDU output current to prevent circuit overloads asadditional
equipment is added. Offers reliable rackmount multi-outlet powerdistribution from any protected UPS, generator
or mains input power source.High quality design includes rugged all-metal housing and secure
rackmountinstallation with included mounting accessories.
Features
20A single phase 120V Monitored Power Distribution Unit / PDU (agency derated to 16A continuous)
Attached NEMA L5-20P input plug with NEMA 5-20P adapter and 12ft / 3.6m line cord
1U horizontal rackmount installation format supports installation in 2 or 4 post equipment racks
8 NEMA 5-15R outlets
Lighted display reports output power consumption in amps
Built-in SNMP/ethernet interface reports voltage, frequency and PDU loading via network or secure web browser interface with options for user specified
alarm and notification thresholds
Supports in-rack environmental reporting with optional ENVIROSENSE temperature / humidity sensor and rack access notification with up to 4 optional
SRSWITCH door sensors
DHCP/Manual configuration support
10/100 Mbps auto-sensing allows optimal communication with 10/100 Base-T networks
Real-time clock backup maintains the time of day and date even if the PDU is unpowered
Tiered access privileges allow an administrator and a guest to login via web browser for monitoring
Alert notifications via email or SNMP traps offer immediate event notification
Firmware upgrade ability supports future product enhancements.
1 / 4
Highlights
Monitored 20A 120V PDU, 1U
horizontal rackmount format
Reports voltage, frequency &
load level via ethernet interface
Visual current meter, Reversible
housing
NEMA L5-20P input with included
5-20P plug adapter
8 NEMA 5-15/20R outlets with
included cord retention brackets
Temperature, humidity and
contact-closure monitoring
options
Applications
Ideal for datacenters, computer
rooms, network closets and other
applications requiring network
grade monitored power
distribution
Package Includes
Rackmount PDU
Plug retention plates
Rack mounting brackets
Owner's manual
L5-20R to 5-20P adapter
