Tripp Lite SmartOnline SU3000RTXR3UHW Quick Manual

SmartOnline 3kVA On-Line Double-Conversion
UPS, 3U Rack/Tower, 110/120V Hardwire input &
output
MODEL NUMBER: SU3000RTXR3UHW
Description
3000VA / 3kVA online, double-conversion UPS system in 3U rackmount form factor for critical server, network
and telecommunications equipment. 3U rackmount form factor with an installed depth of 29.5 inches (75cm).
Expandable battery runtime with optional BP72V15-2U (limit 1), BP72V28RT-3U (multi-pack compatible) and
BP72V18-2US (multi-pack compatible) external battery packs. Full time sine wave 110 or 120V output with +/-2%
voltage regulation. Online, double-conversion Uninterruptible Power Supply (UPS) actively converts raw incoming AC power to DC, then re-converts output
back to completely regulated, filtered AC output. Operates continuously without using battery power during brownouts to 65V and overvoltages to 150V.
Hardwired AC input and output (L-N-G, 120V). Highly efficient operation in optional economy mode setting, saves BTU heat output and energy costs.
Network-grade AC surge and noise suppression. Zero transfer time between AC and battery operation. Network management interfaces support simultaneous
communications via USB port, DB9 serial port and SNMPWEBCARD slot. Includes USB and DB9 serial ports. Built-in DB9 port offers both enhanced RS-232
enabled monitoring data, plus contact closure monitoring ability. HID-compliant USB interface enables integration with built-in power management and auto
shutdown features of Windows and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and mains power conditions
via all 3 network interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Multi-stage metered current
monitoring and battery charge status LEDs. LED display panel easily rotates for better viewing in rackmount or tower configurations. Dataline surge
suppression for dialup, DSL or network ethernet connection. Mains power and voltage regulation LEDs. Audible Alarm. Self-test. Fault-tolerant auto-bypass
mode. 4 post rackmount accessories included; 2-9USTAND tower kit and 2POSTRMKITHD 2-post rackmount accessories available. Field replaceable, hot
swappable internal batteries and external battery packs. Attractive all-black UPS design. $250,000 Ultimate Lifetime Insurance.
Features
3000VA / 3kVA / 2400 watt online, double-conversion UPS system in 3U rackmount form factor for critical server, network and telecommunications
equipment
True online, double-conversion UPS provides perfectly regulated sine wave output within 2% of 110/120V (user selectable) under all usage conditions
Maintains continuous operation through blackouts, voltage fluctuations and surges with zero transfer time
Removes harmonic distortion, fast electrical impulses, frequency variations and other hard to solve power problems not addressed by other UPS types
Corrects line voltage conditions as low as 65V and as high as 150V back to selectable 110/120V (+/-2%) values
1 / 6
Highlights
3000VA / 3kVA / 2400 watt
on-line double-conversion 3U
rack / tower UPS
110/120V +/-2% output at
50/60Hz, high efficiency
economy mode option
Oversize internal batteries,
Expandable runtime,
Hot-swappable batteries
USB, RS232 & EPO ports;
includes SNMPWEBCARD slot
Front panel status LEDs with
detailed load and battery metering
Hardwire input & output
connections
Package Includes
SU3000RTXR3UHW UPS
System
PowerAlert Software CD and
cabling
Owner's manual with warranty
information
