I
2 2 2 HARTREY AVE.. EVANSTON. IL. 6 0 2 0 4 U.S.A.
1
MODEL SR110 A)
.--
-
8
qD
MICROPHONES AND ELECTRONIC COMPONENTS
I
1
UW
A
SRI 10-2E PROFESSIONAL
A K t A
I;uUt
3 1 Z I X b b . Z Z U U
.
LAMLt: bHuKtMILKU
I
SHEET
MONITOR MIXERS
I
I
TWX:
9 1 0 - 2 3 1 - 0 0 4 8
TELEX: 7 2 - 4 3 8 1
I
OPERATION AND
DESCRIPTION
The Shure Model SR110 Professional Monitor Mixer
is a rack-mounted, eight-channel, line level mixer, de-
signed as an accessory for the Shure Model SRlO1
Series 2 Audio Console or SR109 Professional Mixer.
It can also be used with similar equipment when a
separate stage monitor mixer is desired to be added
to a sound reinforcement system. The SR110 can also
be used in multi-track recording applications as a re-
cording mix panel or in stereo broadcasting.
Interconnections between the SR110 and the SRlO1
or SR109 are made through a single multi-pin con-
nector and cable permanently attached to the SRllO.
The SR110 also contains a matching female multi-pin
connector for "stacking" additional SRllOs.
The SR110 provides eight high-impedance, unbal-
anced, line level inputs to its mixing circuitry, and one
high-impedance, unbalanced line level input to its
output selector switch for monitoring program mate-
rial. The output of the SR110 is a 600-ohm balanced
line level with one three-pin male professional audio
connector and two standard '/4 inch three-circuit
phone jacks, connected in parallel.
The front panel of the SRllO contains eight rotary
volume controls for channel gain, and a combination
rotary master volume controllpower-off switch. An
output selector slide switch, headphones jack and
neon power indicator lamp are provided. Silicon
transistors and other solid-state devices are used
throughout. All components are of the highest quality,
and are operated well within their respective ratings
to assure maximum reliability under normal use con-
ditions.
The SR110 and SR110-2E are identical except that
the SRllO operates from 108-132 Vac, 50160 Hz, and
the SRllO-2E operates from either 105-125 or 210-250
Vac, 50160 Hz (switch-selectable).
SR110 Mixers are supplied with four rack-mounting
screws for mounting in standard 19 in. (483 mm) audio
equipment racks or in an optional Shure A105A Carry-
ing Case (mounted with an SR109). In addition, the
SR110-2E is supplied with a detachable ac line cord
(without power plug). The SRl10 (only) is listed by
Underwriters'
Laboratories, Inc., and is listed by
Canadian Standards Association as certified.
SPECIFICATIONS
Type
. . . .
.
.
.
. . .
. .
.
.All silicon transistor monitor
mixer
SERVICE MANUAL
Number of lnput
Channels
.
.
. . .
.
.
. 8 mixed inputs; 1 program input
Power Output
. . . .
. .
+19.2 dBm (LINE LEVEL Output)
Voltage Gain*
Mixed
Inputs**
.
.
.
. . .
.38 i 2 . 5 dB (LINE LEVEL Output)
14.5 t 2 . 5 dB (PHONES Output)
- 8
+-2
dB (MIX BUS)t
Program
Input**
. . . .
.
.
.
.40 +-2 dB (LINE LEVEL Output)
Frequency
Response
. . .
lnput Sensitivity
.
. .
Distortion
. . .
. . . . . .
Noise
(300 HZ-20 kHz)
Mixed
Inputs**
. . . .
.
.
.
i 3 dB, 20 Hz-20 kHz (LINE
LEVEL Output)
.21 mV max. for + 4 dBm line
level output
.THD less than 1 % at
+
12 dBm,
30 Hz-20 kHz; IM distortion
less than 1 % at +12 dBm
.
- 68 dBV max. (MASTER
Volume Control down)
.
-54 dBV max. (MASTER and
channel Volume Controls up)
Program
Input**
. . .
. . .
.
.
-58 dBV max. (MASTER
Volume Control up)
Hum and Noise
(20 Hz-20 kHz)
. . .
-
64 dBV max. (MASTER
Volume Control down)
Mixed
Inputs**
. . . . .
.
.
-50 dBV max. (MASTER and
channel Volume Controls up)
Program
Input**
.
. . .
. .
.
.
-54 dBV max. (MASTER
Volume Control up)
lnput Clipping
Level at 1 kHz
. . .
.2.5V min. on mixed inputs 1-8
with channel Volume Controls
set at max. (input clipping
level increases with decreased
setting of channel Volume
Control)
lnput Impedance
at 1 kHz:
Mixed
Inputs**
. . .
. . .
.23.5 kilohms
Program
Input**
.
.
. .
. . .
.30 kilohms
*Measurement conditions: Inputs through 150 ohms, LINE LEVEL output
terminated in 600 ohms, PHONES output terminated in
8
ohms, MASTER
and channel Volume full up.
**OUTPUT SELECTOR Switch position.
+MIX BUS terminated in
5.6k.
Copyright 1979, Shure Brothers Inc
27A1291 ( 5 6 )
Printed in
U.S.A.
