Lumagen RadianceMini-3D Owner's Manual

Hide thumbs Also See for RadianceMini-3D:
Table of Contents

Advertisement

Quick Links

Download this manual
RadianceMini-3D™

Video Processor

Owner's Manual
LEGAL NOTICES:
TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL
LUMAGEN, ITS SUPPLIERS, OR ITS DEALERS, BE HELD LIABLE FOR
INJURY TO PERSONS OR PROPERTY, ANY LOST REVENUE, LOST
PROFIT, SPECIAL, INCIDENTAL, INDIRECT, CONSEQUENCIAL, OR
PUNITIVE DAMAGES, IMPAIRMENT OF OR DAMAGE TO OTHER GOODS,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RadianceMini-3D and is the answer not in the manual?

Questions and answers

Related Manuals for Lumagen RadianceMini-3D

Summary of Contents for Lumagen RadianceMini-3D

  • Page 1: Video Processor

    Owner’s Manual LEGAL NOTICES: TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL LUMAGEN, ITS SUPPLIERS, OR ITS DEALERS, BE HELD LIABLE FOR INJURY TO PERSONS OR PROPERTY, ANY LOST REVENUE, LOST PROFIT, SPECIAL, INCIDENTAL, INDIRECT, CONSEQUENCIAL, OR...
  • Page 2 Connect the equipment into an outlet on a circuit different from that which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Unauthorized modifications to this equipment may void Lumagen’s limited warranty and the user’s authority to operate this equipment.

  • Page 3: Table Of Contents

    Table of Contents Section 1 – Getting Started 1 Introduction Key Features Document Conventions and Menu Navigation 3 Unpacking 3 Remote Control Battery Installation 4 Installation Guidelines Section 2 – Overview 5 Front Panel Rear Panel 5 Remote Control Block Diagram Configuration Memories 7 Section 3 –...
  • Page 4 Table of Contents Color Format Color and Hue Y/C Delay 20 Input Size Controls Scale Bias 20 Input Sizing20 Vertical Shift Non-linear Stretch 21 Input Masking Input Enhancement Controls Sharpness 22 Noise Reduction Adaptive Contrast 22 Copy Enhancement Settings 22 Miscellaneous Input Controls Deinterlacing Mode 23 Inter Frame Motion Detection (IFMD)23...
  • Page 5 Table of Contents LED Setup 34 RS-232 Setup Configuration Memory Usage Saving the Configuration 35 Save Undo Restore ISF calibration Revert To Factory Settings Section 9 – Command Interface Direct Commands 36 Miscellaneous Commands IR Command Interface 37 IR Command List Serial RS232 Command Interface Usage RS-232 Power OnMessage/OffMessage...

  • Page 6: Section 1 - Getting Started

    The RadianceMini combines proprietary strides in video technology for small systems with up to two HDMI inputs and as an end-point processor for whole-house audio/video systems using matrix-switch technology. Lumagen’s Radiance series refines and enhances the video images presented by high definition front projectors, top-level rear- screen and flat-panel displays.
  • Page 7 Section 1 – Getting Started Programmable input/output color-space Y/C-delay calibration CUE and ICP filtering Eight channel audio up to 192 kHz, DD True-HD™ 5.1, and DTS Master Audio™ IR and RS232 control inputs (See Tech Tip 11) Universal power supply, INPUT:100-240V~50/60Hz, 0.8A OUTPUT:5.0V, 5.0A RadianceMini rev 11/17/10...

  • Page 8: Document Conventions And Menu Navigation

    Section 1 – Getting Started Document Conventions and Menu Navigation Commands are selected with the supplied infrared remote or the RS232 serial port. To prevent possible command conflict, only one of these methods of command should be used at a time. See the Serial RS232 Command Interface section for information on serial commands.

  • Page 9: Remote Control Battery Installation

    Select a well-ventilated, dry location. Verify that the cooling vents are clear of obstructions to provide convection cooling. Only use the a Lumagen approved power supply. Avoid sudden temperature changes, temperature extremes and excessive humidity. Unplug power to the Radiance before cleaning.

  • Page 10: Section 2 - Overview

    Section 2 – Overview Section 2 – Overview Front Panel IR Sensor The front panel has a light-emitting-diode (LED) indicator, which, by default, is green when the unit is “on.” Note that the green “on” indicator can be turned off if preferred. Rear Panel 5 VDC RS232...

  • Page 11: Remote Control

    Section 2 – Overview Remote Control Power / Standby Input Aspect Ratio Power On 4:3 (1.33) aspect ratio STBY Standby LBOX Letterbox 16:9 16.9 (1.78) aspect ratio Navigation Control 1.85 1.85 aspect ratio CLR Clear menu or partial commands 2.35 2.35 aspect ratio HELP Display context-sensitive help Non-Linear-Stretch...

  • Page 12: Block Diagram

    Section 2 – Overview SWAP Not available for RadianceXS MODE Not available for RadianceXS Block Diagram The function of the Radiance is to process the selected source and output video at the appropriate resolution. If the video input is interlaced, it is first deinterlaced into a progressive format.
  • Page 13 Section 2 – Overview The Radiance has four input memories (MEMA, MEMB, MEMC and MEMD). Each input memory has eight sub-memories that are automatically selected for input resolutions of 480, 576, 720p, 1080i50, 1080i60, 1080p24, 1080p60 and Other. The “Other” memory is reserved as a “catch-all” for unspecified resolutions. The following applies to software revision 102910, and later revisions: Each Input sub- resolution memory can be independently linked to any one of the eight output mode, CMS and style memories.

  • Page 14: Section 3 - Quick Start Guide

    Plug the DC power cable, from the external power supply, into the 12 VDC power connector on the back of the Radiance. Warning: Use only the Lumagen power supply. Plug the removable AC power cord into the connector on the external power supply.

  • Page 15: System Configuration Example

    Section 4 – Basic Commands STEP 5 – Check for an image You should now have an image from your selected active video source visible on your display. System Configuration Example RadianceMini rev 11/17/10...

  • Page 16: Section 4 - Basic Commands

    Section 4 – Basic Commands Section 4 – Basic Commands Power Turn power on by pressing the ON button. Place the Radiance in standby-mode by pressing STBY. Input Selection The eighteen video inputs are numbered 1 to 18. For inputs 1 through 9, press the “Input”...

  • Page 17: Image Zoom

    Radiance menu to set input aspect ratio (4:3, LBOX, 16:9, 1.85, 2.35, NLS), set zoom (Zoom+, Zoom-) and select the user memory (MemA, MemB, MemC, MemD). The “Quick Keys” menu duplicates the function of pressing the corresponding buttons on the Lumagen remote. MENU Other...

  • Page 18: Section 5 - Video Configuration

    Section 5 – Video Configuration Section 5 – Video Configuration Output Video Configuration Commands By default the output is set to Mode0, “Auto” The selection “Auto” means the Radiance automatically reads the EDID for the device connected to its and automatically selects the appropriate output resolution.

  • Page 19: Output Mode - Global Presets

    Section 5 – Video Configuration “Auto.” However, the CMS and Style can be changed. If the 3D option has not been installed, the 3D modes are not applicable Output Mode – Global Presets This command is not generally needed. However, it can be useful when driving displays that do not report EDID and where no video is visible until a specific format is sent.

  • Page 20: Graybar Intensity

    Section 5 – Video Configuration MENU 0 6 (Single output aspect, Output aspect per input aspect) OK xxx or MENU Output Configs [Config] Aspect Ratio (Single output aspect, Output aspect per input aspect) Graybar Intensity NOTE: Consult a home theater specialist for assistance setting the graybar intensity. Some degree of burn-in will occur on any susceptible display, but this command can help minimize it by allowing the intensity of the graybars to be adjusted.
  • Page 21 Section 5 – Video Configuration shrink settings, aspect settings, color management settings and other settings. The command is: MENU Output Copy RadianceMini rev 11/17/10...

  • Page 22: Input Configuration Commands

    Section 5 – Video Configuration Input Configuration Commands After the output is configured, calibrated, and saved, you can calibrate the first input. Note that most often, no input calibration is necessary. After calibrationg the first input, you can copy that configuration to all the other configuration memories if desired. Then calibrate other inputs.

  • Page 23: Selecting An Output Configuration For An Input Memory18

    There are 4 settings for the Lumagen EDID interface. The default setting enables all of the display modes the Radiance supports. The User defined setting allows the user to individually select which capabilities will be advertised to the source.

  • Page 24: Auto Aspect19

    To set the input’s black-level (also referred to as brightness) and white-level (also referred to as contrast) using the Lumagen controls, use a test pattern generator or select PLUGE pattern. Note that the input memory black and contrast are intended to compensate for variations in video source output levels.

  • Page 25: Color Format

    Section 5 – Video Configuration Color Format Bt.601 is used for SD/ED modes and Bt.709 is used for HD modes. If the source is outputting the wrong colorspace this command allows the input colorspace to be selected. The command is: MENU Input Video Setup...

  • Page 26: Vertical Shift

    The goal is to stretch the image to fill the screen in a way that looks as natural as possible. The Lumagen NLS command is very flexible and allows the image to be adjusted to user preferences to achieve this goal. The NLS adjustments are center width, center stretch, top cropping and bottom cropping.

  • Page 27: Input Enhancement Controls

    Section 5 – Video Configuration When you select the command you must first select which mask number you wish to use. There are 15 available masks. They can be shared among different input memories. After selecting the mask number you then can adjust how much the mask covers of the 4 sides of the input.

  • Page 28: Miscellaneous Input Controls

    Genlock is used to minimize video delay, for 480i/1080i to 24Hz conversion, and to avoid an occasional dropped or repeated frame. It can slow down source and mode changes, so Lumagen recommends setting Genlock to ‘off’ for cable and satellite settop boxes. The command is:...

  • Page 29: Input Level

    Section 5 – Video Configuration Input Level This command specifies if an analog input has a black pedestal, and if DVI inputs use video levels or PC levels. If you are unsure, it is better to leave these at 0 IRE for analog, or PC level for HDMI.

  • Page 30: Section 6 - Audio Configuration

    Section 7 - Calibration Section 6 – Audio Configuration The RadianceXS supports the HDMI 1.3 audio formats. This means that the Dolby Digital TrueHD™ and DTS Master-Audio™ are available. By default the audio EDID from the device connected to the HDMI Output is passed back to all source devices.

  • Page 31: Audio Menu Navigation

    Section 7 - Calibration Audio EDID, and audio output enables, are global parameters. That is, they change (only) when the active output changes. NOTE: The Audio EDID mode is independent of the Video EDID mode. You can over-ride the global Audio EDID for a particular HDMI input by selecting MENU Input Audio Setup...

  • Page 32: Audio User Edid

    Section 7 - Calibration Audio Example 3 The HDMI Output drives a TV/projector and you do not use the TV/projector audio. This case is shown below. Condition Uses Audio Audio EDID Output Always User1 EDID 48KHz Y Audio User EDID When selecting specific audio modes, the up and down arrow keys select an entry and the right arrow key is used to turn that mode on or off.

  • Page 33: Section 7 - Calibration

    Calibrate black and white levels using display controls To calibrate the black and white levels in the display, select the Lumagen contrast test pattern. Use the right- arrow key to select the Contrast 1 (or Contrast 2) test pattern. The Contrast 1 pattern has two white rectangles and two black rectangles.

  • Page 34: Color Management

    To calibrate the 100 IRE color-temperature point using the display’s controls, select the Lumagen 100 IRE window test pattern. This pattern has a white window on a black background. Navigate to the Lumagen test pattern menu and then use the right-arrow key to select the 100 IRE Window test-pattern. The command is:...

  • Page 35: Iterate The Gamut And Grayscale/Gamma Calibrations

    Set the Lumagen input aspect ratio as 4:3 (1.33) for a 4:3 screen, 16:9 (1.76) for a 16:9 screen, or 2.35 for a projector with a 2.35 anamorphic lens. The input aspect ratio should be set before adjusting the overscan.
  • Page 36 Video Setup [Resolution] Picture ColorDecoder Display a “Y/C Delay” test pattern. Set Y/C Delay. Use the Lumagen Control to minimize the error in the blue and red timing verses Luma. The and C channels are calibrated independently. MENU Input [Resolution]...

  • Page 37: Section 8 - Miscellaneous Commands

    This adds an optional top-level menu called “Quick Keys” that gives access to functions that are normally selected using buttons on the Lumagen remote. This menu can be used with programmable remotes that have limited buttons. You can use the arrow buttons on the remote to highlight one of the functions and press “Ok”...

  • Page 38: Menu Placement

    Section 8 – Miscellaneous Commands Menu Placement In the “Standard” placement the menu is in the center of the screen. Choose “Center open” to move the menu so that the center of the screen is open for display calibration measurements. The command is: MENU Other Menu control...

  • Page 39: Trigger Out34

    Section 8 – Miscellaneous Commands Trigger Out This command controls the two trigger outputs on the rear panel. By default Trigger 1 is on for when power is on, and Trigger 2 is on when the input aspect ratio is selected as 2.35 aspect.

  • Page 40: Saving The Configuration

    Undo Restore ISF calibration During calibration, the video technician can save the resulting Lumagen configuration to a special hidden configuration memory. This command restores that configuration in the event that the user inadvertently changes the configuration. A Save is required to make the restore permanent.

  • Page 41: Section 9 - Command Interface

    Section 9 – Command Interface Section 9 – Command Interface Direct Commands Direct Commands are entered by using the Lumagen remote control. All of these commands can also be entered by using the RS232 interface. Output Vertical Resolution 480p: MENU 0 2 1...

  • Page 42: Ir Command Interface

    Section 9 – Command Interface IR Command Interface IR Command List Remote Command IR-binary Description 0010 00 0001 11 Power on STBY 0010 00 0010 11 Power to standby MENU 0010 00 0111 11 Activate menu EXIT 0010 10 1001 11 Exit.

  • Page 43: Serial Rs232 Command Interface

    Section 9 – Command Interface Remote Command IR-binary Description RGBS 0010 10 1011 10 Output type is RGBS. <enter> completes command RGsB 0010 00 1011 11 Output type is RGsB. <enter> completes command 480P 0010 10 1100 00 Select Vertical Resolution = 480p 540P 0010 00 1100 01 Select Vertical Resolution = 540p...

  • Page 44: Message Control

    Section 9 – Command Interface Message Control Set baud rate, parity and gap for the Power On/Off Message. The command is: MENU Other OnOff Setup Message Ctl On Screen Display Message Turn On/Off the input display window that is shown at the bottom of the screen when you change inputs. If you use a control system to change inputs on the Radiance you can set OSD enable to “Off”.

  • Page 45: Ascii Command List

    Section 9 – Command Interface ASCII Command List Remote RS232-ASCII Description Power on STBY Power to standby MENU Activate menu EXIT Exit. Often acts as a cancel key HELP Displays on-screen help for highlighted menu item. Force menu off (i.e. can use to assure menu is off for input selection) INPUT Choose input (i.e.
  • Page 46 Section 9 – Command Interface Remote RS232-ASCII Description MEMC Select MEMC MEMD Select MEMD Onscreen messages on Onscreen messages off FREEZE Freeze-frame. Any other character resumes 480P Select Vertical Resolution = 480p 540P Select Vertical Resolution = 540p 600P Select Vertical Resolution = 600p 720P Select Vertical Resolution = 720p 768P...
  • Page 47 Section 9 – Command Interface Remote RS232-ASCII Description and ack/nack. See page 2: “Optional start/end delimiters for RS232 commands”. Set Echo-- 0=echo off, 1=echo on (default), 2=echo off with status. See ZE<0,1,2> page 2: “Echo command”. Basic input info-- returns (logical input#1-18, input memory a-d, physical input #1-18).
  • Page 48 Section 9 – Command Interface Remote RS232-ASCII Description Output color temp-- if using 12 pt returns (IRE point 12), If using 21 pt returns (IRE points 11-20), the value is in range 0-1000, corresponding ZQO89 to 0-100.0 (ZQO09 returns pts 0-10) Output color temp-- if using 12 pt returns (R point 12), If using 21 pt returns (R points 11-20), the value is in range 0-1000, corresponding to ZQO90...
  • Page 49 Section 9 – Command Interface Remote RS232-ASCII Description and must match the selected HDMI input) 06-11coax, 12-13 optical, 14- 17 stereo ZY505SVVV<CR> (Note 1) Set input black level-- S=sign<+,-> VVV=value <000-064> ZY506SVVV<CR> (Note 1) Set input contrast level-- S=sign<+,-> VVV=value <000-127> Set input color format-- 0=auto, 1=Bt.601, 2=Bt.709.

  • Page 50: Section 10 - Specifications

    Inputs Two HDMI 1.4 video inputs Processing 10-bit processing front-end with 12-bit calibration pipeline Proprietary Lumagen “No-ring” ™ scaling Support for HDMI 1.4 3D Each input has 4 user configuration memories, with 8 resolution sub-memories for each 2:2, 3:2 and 3:3 pull-down for SD/HD film sources...
