Rockwell Automation 1784-KTX User Manual

1784-kt series communication interface card
Table of Contents

Advertisement

Quick Links

User Manual

1784-KT x
Communication
Interface Card
(Cat. Nos. 1784-KTX,
-KTXD, and -KTS )

Advertisement

Table of Contents
loading

Summary of Contents for Rockwell Automation 1784-KTX

  • Page 1: User Manual

    User Manual 1784-KT x Communication Interface Card (Cat. Nos. 1784-KTX, -KTXD, and -KTS )
  • Page 2: Important User Information

    Reproduction of the contents of this copyrighted publication, in whole or part, without written permission of Rockwell Automation, is prohibited. Throughout this manual we use notes to make you aware of safety considerations:...
  • Page 3: Adherence To European Union Directive Compliance

    Adherence to European Union Directive Compliance If this product or package is marked with the CE mark, the product complies with the following European Union Directives: Installation Requirements: If this product is installed within the European Union or EEA regions, the following regulations apply. EMC Directive This product is tested to meet Council Directive 89/ 336/EEC Electromagnetic Compatibility (EMC) using a technical construction file...
  • Page 4 1784-6.5.22 - November 1999...
  • Page 5: Table Of Contents

    Introduction to the 1784-KTx Communication Interface Cards How the 1784-KTx Card Operates ......1-2 What to Do Next .
  • Page 6 Connect the Interface Card 1784-KTX Connections ........4-1 1784-KTS Connections .
  • Page 7 Appendix B Run the 1784-KTx Diagnostics for DOS When Do I Run Diagnostics? ....... B-1 Troubleshooting the KTx Card .
  • Page 8 1784-6.5.22 - Novmber 1999...
  • Page 9: Preface

    Appendix B In this document, we refer to the 1784-KTX, 1784-KTXD, and 1784-KTS cards collectively as “1784-KTx card” or KTx card.” When one card differs from the other, this document individually calls out the cards by name. Contents of Your Order...
  • Page 10: If You Ordered A 1784-Kts Interface Card

    1784-KTS customers do not receive the utility disk. With the 1784-KTS package, you should receive: one 1784-KTS communication interface card one 1784-KTx Communication Interface Card User Manual, publication 1784-6.5.22 If you are missing either of these pieces, contact your Allen-Bradley/Rockwell Automation sales representative.
  • Page 11: Specifications

    To the Installer Specifications The operation parameters describe the environment within the KTx slot. Refer to the documentation for your computer for environmental requirements. The KTx card should not exceed those specifications. Operational slot temperature 0 to 60ºC (32 to 140ºF) Non-operational slot temperature -40 to 85ºC (-40 to 185ºF) Relative humidity...
  • Page 12: Summary Of Changes

    To the Installer For DOS applications screen displays and prompts are shown as screen captures and text instructions. Press ENTER to continue with the installation Text that you type is shown as: a:\install c: Summary of Changes Several additions and changes to the KTx card and software information have been made.
  • Page 13: Worksheet Tables

    We recommend that you make one copy of each worksheet for each KTx card or channel (1784-KTXD). See Chapter 2. Related Publications Publication Title Pub. No. 1784-KTx Scanner Reference Manual 1784-6.5.20 1784-KTx Dual-port Reference Manual 1784-6.5.21 1784-CP12 Cable Packing Data 1784-2.41...
  • Page 14 To the Installer 1784-6.5.22 - November 1999...
  • Page 15 Chapter Introduction to the 1784-KT x Communication Interface Cards Your 1784-KTx communication interface card (cat. nos. 1784-KTX, 1784-KTXD, and 1784-KTS) is an ISA half-sized card that must be inserted into a 16-bit ISA or EISA expansion slot. Important: You must not place this card in an 8-bit expansion slot. Improper operation and damage to the card will result.
  • Page 16: Introduction To The 1784-Ktx Communication Interface Cards

    DH-485 networks act as a remote I/O scanner The 1784-KTS card acts only as a remote I/O scanner. The 1784-KTx performs data transmission, management, and local network diagnostics. The interface to the host processor is through a board-resident dual-port memory.
  • Page 17: Configure The Card Hardware

    You must select an area where there is at least a 4 Kbyte memory block available. If you have MS-DOS 6.0 or later, use the memory option in Microsoft Diagnostics (MSD) to identify available memory. The 1784-KTx cards come set to memory address(es): Catalog Number Channel...
  • Page 18 KTx card. To configure the base memory address, you turn rotary switches on the 1784-KTx card. 1. Determine addresses for the channel(s) on your KTx card. A. Use Table 2.A on page 2-3 to determine the recommended memory address settings for your Allen-Bradley products.
  • Page 19 Configure the Card Hardware Table 2.A Recommended memory address settings Equipment Channel # Recommended Memory Location 1784-T35 CB00: CC00: 1784-T50 C300: C400: T53 Industrial Programming Terminal D700: D600: T60 Industrial Workstations D300:, D700:, or DB00: D200:, D600:, or DA00: 6180 Workstations DD00: DC00: 6181 Workstations...
  • Page 20 Configure the Card Hardware Table 2.B System Memory Allocation System Memory Address: Typical PC Assignments: Your System: 0000:0000-07000:FFFF 521 Read/Write Memory on System Board 8000:0000-09000:FFFF 128K Read/Write Memory Expansion in I/O Channel A000:0000-C700:0FFF Video Buffer C800:0000- Expansion Card Area (Area Available for KT x Memory Addresses) CF00:0000- D300:0000-...
  • Page 21 Configure the Card Hardware Table 2.C Address Selections Record the base memory address for the 1784-KT x card’s channel 1: Card: Slot number Using default address: Yes Channel 1 If no, new memory address: Record the base memory address for the 1784-KT x card’s channel 2: Card: Slot number Using default address: Yes...
  • Page 22: Set The Card's Switches

    To set the card’s switches, follow these steps: 1. Follow the card handling instructions on page P-2. 2. Remove the 1784-KTx card from the anti-static clamshell. 3. Use the decision table below. If you need to: Then: use the card’s default memory address...
  • Page 23: Select The Interrupt Setting

    If another card is already using a channel’s default interrupt, you must pick a new interrupt for the channel. About KT x Interrupts The 1784-KTx cards are set to these interrupt(s): Catalog Number Channel Interrupt...
  • Page 24 Configure the Card Hardware If you are: Then: using the card’s default interrupt settings, i.e., go to the next section, Installing the Card no interrupt Inside the Computer setting new interrupts move the jumper to the new interrupt location(s) (as entered on Table 2.E, page 2-10) INTERRUPTS CH2 CH1...
  • Page 25 Configure the Card Hardware 1. Determine the interrupt(s) for the channel(s) on your KTx card. Use Table 2.D to determine which interrupts are available for the KTx card channel(s). Important: If you are using the KTx for remote I/O scanner emulation, you must set an interrupt for the scanner channel.
  • Page 26 2-10 Configure the Card Hardware Table 2.E Jumper Settings Important: If you are using the “no interrupt” setting, you must place the jumper vertically over two pins on the right-side row as show on page 2-7. This way you can save the jumper for future use. Placing the jumper on the left-side row will cause interrupt problems on the motherboard.
  • Page 27: New Dh+ Specification - Link Baud Rate

    Configure the Card Hardware 2-11 New DH+ Specification - Link Baud Rate Allen-Bradley has added 230k baud rate enhancements to the DH+ firmware of the KTx. Note this update to the KTx dualport memory map for DH+, which is documented in publication 1784-6.5.21 Host writes a valid value (KTx baud :0007h...
  • Page 28 2-12 Configure the Card Hardware 1784-6.5.22 - November 1999...
  • Page 29: Install The Card Inside The Computer

    Do I understand where I can and can’t put this card? On the Right Track? Be certain that you know how to: configure the computer’s options before you install the 1784-KTx install hardware into your computer’s expansion slots Consult your computer’s documentation for specific information.
  • Page 30: The Ktx Skirt Area

    Install the Card Inside the Computer The KT x Skirt Area Important: As shown in Figure 3.1, placing the card in certain computers may cause mechanical interference with improperly placed components on the motherboard of the computer. Be certain to position the card away from components that can touch the KTx’s skirt area.
  • Page 31: Access The Computer's Expansion Slots

    3. Remove the computer’s CPU cover (according to the manufacturer’s instructions). 4. Select a vacant 16-bit ISA or EISA expansion slot. Important: The 1784-KTx will function only in a 16-bit ISA or EISA expansion slot. 5. Remove the rear bracket slot’s expansion cover by loosening the screw on the back of the computer.
  • Page 32: E3 Jumper Sets Operating Mode

    Install the Card Inside the Computer E3 Jumper Sets Operating Mode The E3 jumper sets the card to 8- or 16-bit mode. Important: You must place the card in a 16-slot connector regardless of the chosen mode of operation. Eight-bit mode is included only as a fall-back in case of system issues with 16-bit operation;...
  • Page 33: Insert The Card

    Install the Card Inside the Computer Insert the Card To insert the card inside the computer: 1. Follow the instructions on how to handle the card on page P-2. 2. Be certain that you have set correctly all of the switches and jumpers on the card.
  • Page 34 Install the Card Inside the Computer 1784-6.5.22 - November 1999...
  • Page 35: Connect The Interface Card

    - selected SLC 500 processors - classic PLC-5 processors - remote I/O networks acting - enhanced PLC-5 processors a scanner - SLC 5/04 processors - ControlLogix DH+/RIO 1784-KTX Connections Remote I/O 3. Blue 3. Clear 2. Shield/Drain 2. Shield/Drain 1. Clear 1.
  • Page 36: 1784-Kts Connections

    Connect the Interface Card 1784-KTS Connections Remote I/O 3. Clear 1784-KTXD Connections 2. Shield/Drain 1. Blue Remote I/O 3. Clear 3. Blue 2. Shield/Drain 2. Shield/Drain 1. Blue 1. Clear 3. Blue 3. Clear 2. Shield/Drain 2. Shield/Drain 1784 1. Clear 1.
  • Page 37: Before You Begin

    Connect the Interface Card Before You Begin Before you make the connections, be certain that you have the correct cables. This table lists the cables for various programmable controllers and processors: For: Use cable with catalog number: PLC-5/10, -5/12, -5/15, -5/25, -5/VME (6008-LTV) and 1784-CP12 PLC-5/250 classic programmable controllers PLC-5/11, -5/20, -5/30, -5/40, -5/60, -5/80, and -5/VME...
  • Page 38: Connect The 1784-Ktx Card To Dh+ Devices

    PLC-5 processor. Connect the Card to a Classic PLC-5 Processor To connect the 1784-KTX or-KTXD card to a classic PLC-5 processor, follow these steps: 1. Turn off power to the computer.
  • Page 39 Connect the Interface Card 3. Connect the 9-pin D-shell end directly to the 9-pin D-shell connector on the front of the classic PLC-5 processor. PLC-5 Family Processor 1784-KT x Card 1784-CP12 Cable Peer Communication Interface Connector 18341 4. Restore power to the computer. 1784-6.5.22 - November 1999...
  • Page 40: Connect The Card To An Enhanced Plc-5 Processor

    Connect the Interface Card Connect the Card to an Enhanced PLC-5 Processor To connect the 1784-KTX or -KTXD card to an enhanced PLC-5 processor, use a 1784-CP12 cable and a 1784-CP7 adapter. Follow these steps: 1. Connect the 3-pin Phoenix end of the CP12 cable to the KTx card.
  • Page 41: Terminate The Last Node

    42138 Connect the Card to a Data Highway Plus Network To connect the 1784-KTX or -KTXD card to a Data Highway Plus network, use Allen-Bradley 1770-CD or approved cable to construct custom cable. Important: You must terminate the last physical node of the network with a resistor of appropriate value.
  • Page 42: Connect The Card Via A Dh-485 Network

    An SLC 500 CPU is connected to each of the link couplers (1747-AIC) with a 1747-C11 cable. The 1784-KTX or -KTXD card is connected to the network at one of the link couplers, as shown in Figure 4.1. The communication cable consists of three segments of cable daisy-chained at each link coupler.
  • Page 43: Connect The Card To An Slc 500 Processor

    -KTXD card and an SLC 500 processor. The SLC 500 CPU is connected directly to the 1784-KTX or -KTXD card with a 1784-CP14 cable, as shown. Figure 4.2 Communicating to a single SLC 500 using a point-to-point DH-485 link...
  • Page 44: Terminate The Last Node

    Highway II/Data Highway-485 Cable Installation Manual, for additional information about cable issues. What to Do Next If you have read each chapter, completed the worksheets, run diagnostics, and still have questions, please call Rockwell Automation Technical Support at 440.646.5800. 1784-6.5.22 - November 1999...
  • Page 45: Run The 1784-Ktx Card Diagnostics For Windows Nt

    Run the 1784-KTx Card Diagnostics for Windows NT Read this chapter to learn how to operate the 1784-KTx card on Windows NT. Read the following before you install your 1784-KTx card. Important: The 1784-KTS card will not run the dual-port test. It will attempt to run and fail.
  • Page 46: Install The Diagnostics

    Be aware of the following important points before installing the Windows NT diagnostics for 1784- card. Important: Before you can install the diagnostics for the 1784-KTx card, you must be logged in as an administrator of the machine or have administrator privileges. Being an administrator gives you permission to install or make changes to the machine software.
  • Page 47 Run the 1784-KTx Card Diagnostics for Windows NT 3. Turn your machine on and logon as an administrator. Important: Remember, in order for the installation process to run correctly, you must have (administrator) privileges to install the software. 4. Insert the installation diskette into the floppy disk drive.
  • Page 48 Run the 1784-KTx Card Diagnostics for Windows NT 6. Type the path a:\setup.exe. Substitute a:\ for the drive of your floppy disk, i.e b:\. 7. Click Please wait until InstallShield is finished. 1784-6.5.22 - November 1999...
  • Page 49 Run the 1784-KTx Card Diagnostics for Windows NT 8. Read the information and decide either to continue or to cancel. 9. Click to continue with the install. 1784-6.5.22 - November 1999...
  • Page 50 Run the 1784-KTx Card Diagnostics for Windows NT You see: 10. To accept agreement and continue, click 1784-6.5.22 - November 1999...
  • Page 51 Run the 1784-KTx Card Diagnostics for Windows NT You see: 11. Click if you have administrator permissions. If you don’t know if you have administrator permissions, click see if the install process continues and go to Step 10. If the process does not continue you don’t have administrator permissions, contact your Systems...
  • Page 52 Run the 1784-KTx Card Diagnostics for Windows NT 12. Now you have the opportunity to choose the destination of the software. 13. Click to accept the default location (recommended). If you would like to change the destination folder, click 1784-6.5.22 - November 1999...
  • Page 53 Run the 1784-KTx Card Diagnostics for Windows NT 14. After you choose to select the default destination. Select a program folder. The default is displayed. If you choose not to use the default, click on the folder you created or assigned in the previous window.
  • Page 54 A-10 Run the 1784-KTx Card Diagnostics for Windows NT The install process is very fast. You will see a couple small windows appear and disappear quickly. When the installation process is over you see: and: 16. Click to end the install process.
  • Page 55 Run the 1784-KTx Card Diagnostics for Windows NT A-11 You see: 17. Decide whether or not you want to reboot now or later and click Important: You must reboot before this program will be able to run. 1784-6.5.22 - November 1999...
  • Page 56: Run The 1784-Ktx Diagnostics For Windows Nt

    A-12 Run the 1784-KTx Card Diagnostics for Windows NT Run the 1784-KTx Diagnostics for Windows NT This section contains instructions for you to run 1784-KTX, -KTXD, and KTS diagnostics, which check network and host communications, interrupts, and memory access. Important: The 1784-KTS card will not run the dual-port test. The test will attempt to run and fail.
  • Page 57 Run the 1784-KTx Card Diagnostics for Windows NT A-13 Follow these instructions to run the KTx diagnostic tool for Windows NT: 1. Select Start. 2. Select Programs. 3. Select Rockwell Automation. 4. Select KTXDIAG.EXE. 1784-6.5.22 - November 1999...
  • Page 58 A-14 Run the 1784-KTx Card Diagnostics for Windows NT You see: 5. Type the number of the card that you need to test. You see: 1784-6.5.22 - November 1999...
  • Page 59 Run the 1784-KTx Card Diagnostics for Windows NT A-15 6. Decide whether or not you want to load and view the network protocol (network who). – Yes displays the protocol. – No displays the previous menu. When you load the protocol, you see: 7.
  • Page 60 A-16 Run the 1784-KTx Card Diagnostics for Windows NT You see: 8. Either exit or continue to test other cards installed. 1784-6.5.22 - November 1999...
  • Page 61: Error Message

    Rockwell Automation Customer Support at 440.646.5800. incorrect seating in the card slot Follow the card installation instructions in Chapter 3 and try the diagnostics again. If you continue to get this error, call Rockwell Automation Customer Support at 440.646.5800. 1784-6.5.22 - November 1999...
  • Page 62: View The Readme.txt File

    A-18 Run the 1784-KTx Card Diagnostics for Windows NT View the readme.txt file Please view the readme.txt for additional information. 1784-6.5.22 - November 1999...
  • Page 63: Remove The Card's Diagnostics In Windows Nt

    Run the 1784-KTx Card Diagnostics for Windows NT A-19 Remove the Card’s Diagnostics in Windows NT We recommend uninstalling the diagnostics program after you have verified your card’s operation. You can access the uninstaller through Windows NT’s Add/Remove programs applet to remove the card’s drivers from your system.
  • Page 64 A-20 Run the 1784-KTx Card Diagnostics for Windows NT You see: 5. Click to remove the diagnostics from your computer. 6. Close the Control Panel. 1784-6.5.22 - November 1999...
  • Page 65: Run The 1784-Ktx Diagnostics For Dos

    Appendix Run the 1784-KTx Diagnostics for DOS This appendix contains instructions for you to run 1784-KTX, -KTXD, and KTS diagnostics, which check network and host communications, interrupts, and memory access. Important: The 1784-KTS card will not run the dual-port test, i.e., it will attempt to run and fail.
  • Page 66: Troubleshooting The Ktx Card

    Run the 1784-KTx Diagnostics for DOS Troubleshooting the KT x Card If your KTx card is not functioning properly, follow these steps: 1. If you changed the default settings for the KTx card, check and correct the configuration. You may have configured the KTx card at an address already in use by another module.
  • Page 67: Install Dos Diagnostics To Your Hard Drive

    Run the 1784-KTx Diagnostics for DOS 3. If you received any failures, print the log file (see page B-20) 4. Call Rockwell Automation Customer Support at 440.646.5800. Instructions are printed at the beginning of the log file. Install DOS Diagnostics to Your Hard Drive Install the diagnostic files with the installation program on the KTx Utility Disk, which came in the box with your KTx card.
  • Page 68 Run the 1784-KTx Diagnostics for DOS You see: Important: In some instances, the status bar does not reach 100% even though all of the appropriate files have been copied. 5. Press: Enter You see the Select Option screen. 6. Select: Exit You see the DOS prompt.
  • Page 69: Access Diagnostics

    Run the 1784-KTx Diagnostics for DOS Access Diagnostics ATTENTION: You can run diagnostics on only one card or channel (1784-KTXD) at a time. If you run diagnostics using a memory address that is incorrect, the computer may lock up. Be certain to run diagnostics using the correct address setting (see page 2-4 for the memory address(es) your configured).
  • Page 70 Run the 1784-KTx Diagnostics for DOS You see the introductory screen: Press this key: Go to page: View the diagnostics menu F1 (Start Diags) Exit the software F10 (Exit) 1784-6.5.22 - November 1999...
  • Page 71: Start Diagnostics

    Run the 1784-KTx Diagnostics for DOS Start Diagnostics From the introductory screen (see page B-6), press F1. You see the main menu: The following instructions take you through running the diagnostic tests individually and viewing the error log file. 7. Use the decision table below.
  • Page 72: Define A Ktx Card To Test

    Run the 1784-KTx Diagnostics for DOS Define a KT x Card to Test If you have more than one KTx card installed or you are using a 1784-KTXD card, you need to define which card or which memory address you want to test Important: If you need to use settings other than the default settings, you must define those settings on this screen.
  • Page 73 Run the 1784-KTx Diagnostics for DOS To change the: Press this key: And: DH+ address F6 (DH+ Address) You will be prompted to enter an address DH-485 address F7 (DH485 Address) DH+ [0 . . . 77] DH-485 [0 . . .31] 3.
  • Page 74: Run M16 Tests

    B-10 Run the 1784-KTx Diagnostics for DOS Run M16 Tests 1. From the main menu (see page B-7), press F3. You see: Important: If you are in 8-bit mode, you’ll see only the first two lines; those lines will indicate 8-bit mode ON and Extended M16 OFF. You cannot run M16 tests in 8-bit mode.
  • Page 75: Test Your Computer

    Run the 1784-KTx Diagnostics for DOS B-11 Test Your Computer 1. From the main menu (see page B-7), press F4. You see: 2. Use the decision table below. Press this key: execute the tests F1 (Execute Tests) return to the main menu (page B-7) without...
  • Page 76 B-12 Run the 1784-KTx Diagnostics for DOS If you pressed F1, you see: If an error occurs, the diagnostics report a failure and continues with the next test. Errors are recorded in the log file (page B-20). Diagnostic: Description: If this test fails: Dual Port Tests the computer’s ability to read...
  • Page 77: Test The Ktx Card

    Run the 1784-KTx Diagnostics for DOS B-13 Test the KT x Card 1. From the main menu (page B-7), press F5. You see: 2. To execute the tests, press F1. To return to the main menu (page B-7) without running the test, press F10.
  • Page 78 B-14 Run the 1784-KTx Diagnostics for DOS If an error occurs, the diagnostics report a failure and continues with the next test. Errors are recorded in a log file (see page A-20). Diagnostic Description If the test fails: Memory Tests the KT x card’s ability The KT x card’s RAM may have a...
  • Page 79: Test The Dual Port

    Run the 1784-KTx Diagnostics for DOS B-15 Test the Dual Port 1. From the main menu (page B-7), press F7. You see: 2. Use the decision table below. To load this protocol to the KT x card: Press this key:...
  • Page 80 B-16 Run the 1784-KTx Diagnostics for DOS Then you see: For DH+ For DH-485 1784-6.5.22 - November 1999...
  • Page 81 Run the 1784-KTx Diagnostics for DOS B-17 3. Use the decision table below for both protocols. Press this key: enable the KT x card on a DH+ or DH-485 link (page B-17) F4 Enable disable the KT x card from a DH+ or DH-485 link (disables the card...
  • Page 82 B-18 Run the 1784-KTx Diagnostics for DOS For DH-485 1784-6.5.22 - November 1999...
  • Page 83 Run the 1784-KTx Diagnostics for DOS B-19 Important: The address of the KTx card for this test is fixed at 77 octal. If other nodes use this address, you will see duplicate nodes on the network. This field: Indicates: KT x node address is...
  • Page 84: Print The Log File

    ..COMPLETED 1784-KTX Diagnostic v1.0 3. Call Rockwell Automation Technical Support at: 440.646.5800 and request a customer log number and the name of a technical support specialist. Include this information on the fax cover letter along with the log print-out. Fax everything to the number indicated on the print-out.
  • Page 85: Use The Ktx Card With 6200 Software

    KTX Card and 6200 Software for PLC-2 Direct-connect and PLC-3 Direct-connect Important: You can use only the 1784-KTX card for PLC-2 and PLC-3 direct-connect. The 1784-KTS and 1784-KTXD do not support direct connection to a PLC-2 or PLC-3 processor.
  • Page 86 Use the KTx Card with 6200 Software 2. Install the card in the computer by following the instructions in Chapter 3. Important: The following procedure to run the installation program is not necessary with later versions of software. If your software lists the KTx as an option, the utility is already installed.
  • Page 87 Use the KTx Card with 6200 Software Update target drive PLC 3 files with 1784 KTX files You see: Important: In some instances, the status bar does not reach 100% even though all of the appropriate files have been copied. For a PLC-2 processor, select: 1784-6.5.22 - November 1999...
  • Page 88 Use the KTx Card with 6200 Software Update target drive PLC 2 files with 1784 KTX files You see: 6. Exit the installation program. 1784-6.5.22 - November 1999...
  • Page 89 Use the KTx Card with 6200 Software 7. Connect the appropriate cable from the card to the port on the programmable controller: • 1784-CP15 for PLC-2 • 1784-CP16 for PLC-3 8. Start 6200 software for the PLC-2 or PLC-3 programmable controller running on the computer.
  • Page 90 Use the KTx Card with 6200 Software 1784-6.5.22 - November 1999...
  • Page 91 6200 software address selection worksheet base memory address recommended memory address settings base memory location connecting to an SLC 500 processor connecting via a DH-485 network connecting devices to the 1784-KTX card DH+ networks DH-485 DH-485 networks A-12, B-1 diagnostics accessing...
  • Page 92 expansion slots host computer IRQ assignments intalling the card’s driver on Windows NT 2-10 jumper settings worksheet KTx interrupts B-20 log file B-10 M16 test PLC classic programmable controlers PLC enhanced programmable controllers PLC-2 direct connect PLC-3 direct connect remote I/O removing the card’s driver A-19 in Windows NT...
  • Page 93 Allen-Bradley Publication Problem Report If you find a problem with our documentation, please complete and return this form. Pub. Name Cat. Pub. Pub. Part Date Check Problem(s) Type: Describe Problem(s) o Technical Accuracy text illustration o Completeness o illustration procedure/ definition o guideline What information is missing?
  • Page 94 NO POSTAGE NECESSARY IF MAILED IN THE BUSINESS REPLY MAIL FIRST-CLASS MAIL PERMIT NO. 18235 CLEVELAND OH POSTAGE WILL BE PAID BY THE ADDRESSEE Technical Communication 1 ALLEN BRADLEY DR MAYFIELD HEIGHTS OH 44124-9705...
  • Page 96 Back Cover Publication 1784-6.5.22 - November 1999 PN 955135-70 Supersedes Publication 1784-6.5.22-RN1 July 1997 Supersedes Publication 1784-6.5.22 - December 1994 © (1999) Rockwell International Corporation. Printed in the U.S.A.

This manual is also suitable for:

1784-ktxd1784-kts
