Audio Note M2 Phono Owner's Information page 11

TECHNICAL SPECIFICATIONS
INPUT IMPEDANCE
INPUT SENSITIVITY
GAIN @ 1KHz
OUTPUT IMPEDANCE
OUTPUT NOISE (unweighted RMS)
TUBE COMPLIMENT
FUSE RATINGS
MAX. POWER CONSUMPTION
UNIT WEIGHT
SHIPPING WEIGHT
(ORIGINAL PACKAGING)
UNIT DIMENSIONS
SHIPPING DIMENSIONS
(ORIGINAL PACKAGING)
NOTE
100 KOhms Line
47 KOhms Phono
126mV for 1V Output
23dB Line Feedback off
17dB Line Feedback on
60dB Phono Feedback off
54dB Phono Feedback on
5KOhm Feedback off
2.5KOhm Feedback on
<0.4mV Line
<12mV Phono Feedback on
1 x 6SN7WGTA
1 x 6DJ8
1 x ECC83
1 x 6X5
1 x ECL82
1A anti-surge (110 / 120V supply)
500mA anti-surge (220 / 240V supply)
55 Watts
7 KG
10 KG
140mm (h) x 295mm (w) x 450mm (d)
240mm (h) x 400mm (w) x 550mm (d)
Due to Audio Note (UK)ʼs ongoing research and
development program, specifications are subject
to change without notice.
Feedback Off
