Technical Specifications - Audio Note M8 Line Owner's Information

TECHNICAL SPECIFICATIONS

INPUT IMPEDANCE
INPUT SENSITIVITY
GAIN
OUTPUT IMPEDANCE
OUTPUT NOISE
TUBE COMPLIMENT
FUSE RATINGS
MAX. POWER CONSUMPTION
UNIT WEIGHT
SHIPPING WEIGHT
(ORIGINAL PACKAGING)
UNIT DIMENSIONS
SHIPPING DIMENSIONS
(ORIGINAL PACKAGING)
100 KOhms
(Balanced and Single Ended)
126mV for 1V Output
18dB at 1KHz
<10 Ohms
<0.08mV unweighted (RMS)
1 x ECC82
1 x 7044
1 x 6X5
1 x ECL82
1 x OB2
1A anti-surge (110 / 120V supply)
500mA anti-surge (220 / 240V supply)
81 Watts
16 KG
19 KG
135mm (h) x 440mm (w) x 410mm (d)
235mm (h) x 540mm (w) x 510mm (d)
