Sharp R-21LTF Service Manual page 23

KEY DISPLAY
0 0 End of each stage
1 1 After 10% of total cooking time is passed
: : :
9 9 After 90% of total cooking time is passed
START A There is no pause
2) To check the constants of Express defrost.
" ": Flicker /
PAD DISPLAY
CHECK
EXPRESS DEFROST
( A )
( +-B )
P - 60
( PL )
( A )
( +-B )
P - 40
( PL )
( pause time )
P - 20
( PL )
( repeat )
CHECK
3) To set user counts
Practice for inputting total number of using times (Ex. 3100 times), and
using times of Memory 1 (Ex. 100 times).
PAD DISPLAY
(Door close)
CHECK
CHECK 82 68
(user total count)
DOUBLE QUANTITY
SIGNAL
SET
3,1,0,0 31 00
SET 31 00
(user total count 3100 set)
#A 1
(after 1 sec.) 1 32
(memory 1 count)
SET
1,0,0 1 00
SET 1 00
(memory 1 count 100 set)
CHECK
NOTE: 1) To input using times of other memory, touch necessary
Memory key at above step #A.
2) To input using times of manual cooking, touch SELECTA-
TIME key at above step #A.
3) o input using times of Express Defrost, touch EXPRESS
DEFROST key at above step #A.
PAUSE
: 0.1 sec BUZZER
INDICATOR PHONE
.
. "No." CHECK
0.20 DEF
0
0.15
0
5
.
" ": Flicker / : 0.1 sec BUZZER
INDICATOR PHONE
.
.
. CHECK No.
CHECK
0
1 No.
0
.
x 4
x 3
9 – 4
