Procedure For Checking/Clearing Service Counts Of Microwave Oven - Sharp R-21LTF Service Manual

5) Ensure that these leads remain isolated from other components
and oven chassis by using insulation tape.
6) After that procedure, re-connect the power supply cord.
After checking the performance of the touch control panel,
1) Disconnect the power supply cord.
2) Open the door and block it open.
3) Re-connect the leads to the primary of the power transformer.
4) Re-install the outer case (cabinet).
5) Re-connect the power supply cord after the outer case is
installed.
6) Run the oven and check all functions.
a) On some models, the power supply cord between the touch
control panel and the oven itself is so short that the two can't
be separated. For those models, check and repair all the
controls (sensor-related ones included) of the touch control
panel while keeping it connected to the oven.
b) On some models, the power supply cord between the touch
control panel and the oven proper is so long enough that
they may be separated from each other. For those models,
therefore, it is possible to check and repair the controls of the
touch control panel while keeping it apart from the oven
proper; in this case you must short both ends of the door
sensing switch (on PWB) of the touch control panel with a
jumper, which brings about an operational state that is equiv-
alent to the oven door being closed. As for the sensor-
related controls of the touch control panel, checking them is
possible if the dummy resistor(s) with resistance equal to
that of the controls are used.
2. Servicing the touch control panel with power supply from an exter-
nal power source:

[3] PROCEDURE FOR CHECKING/CLEARING SERVICE COUNTS OF MICROWAVE OVEN

The following procedure enables the servicer to obtain the total using
times (cook cycles) since the microwave oven is purchased and the
total operation time (hours) since the microwave oven is purchased.
The maximum capacity of the total using is 999,999 times, and the
maximum capacity of total operation time is 999,999 hours.
1. Practice for checking total using times (Ex.
345678 times).
... Flashing /
PAD DISPLAY
(Door close)
CHECK
CHECK #1 82 68
(user total count)
#2
SIGNAL
SIGNAL
DOUBLE 34 56
QUANTITY
(service total count upper figure)
3456XX
1 (No 1)
(after 1 sec.) 34 56
(service total count upper figure)
2 (No 2)
(after 1 sec.)
(service total count lower figure)
CHECK
... 0.1sec BUZZER
INDICATOR PHONE
.
.
. CHECK No.
CHECK
1 No.
2 No.
78
.
Disconnect the touch control panel completely from the oven
proper, and short both ends of the door sensing switch (on PWB) of
the touch control panel, which brings about an operational state
that is equivalent to the oven door being closed. Connect an exter-
nal power source to the power input terminal of the touch control
panel, then it is possible to check and repair the controls of the
touch control panel; it is also possible to check the sensor-related
controls of the touch control panel by using the dummy resistor(s).
3. Servicing Tools
Tools required to service the touch control panel assembly.
1) Soldering iron: 60W
(It is recommended to use a soldering iron with a grounding termi-
nal.)
2) Oscilloscope: Single beam, frequency range: DC - 10MHz type or
more advanced model.
3) Others: Hand tools
4. Other Precautions
1) Before turning on the power source of the control unit, remove the
aluminium foil applied for preventing static electricity.
2) Connect the connector of the key unit to the control unit being sure
that the lead wires are not twisted.
3) After aluminium foil is removed, be careful that abnormal voltage
due to static electricity etc. is not applied to the input or output ter-
minals.
4) Attach connectors, electrolytic capacitors, etc. to PWB, making
sure that all connections are tight.
5) Be sure to use specified components where high precision is
required.
2. Practice for checking total operation time (Ex.
4567 hours).
PAD
(Door close)
CHECK
CHECK #1
(user total count)
#2
SIGNAL
SIGNAL
DOUBLE
QUANTITY
(service total count upper figure)
3456XX
9 (No 9)
(after 1 sec.)
(Total operation time upper figure)
0 (No 0)
(after 1 sec.)
(Total operation time lower figure)
CHECK
#1 : No key entry signal.
#2 : To set -B, touch the selectapower key twice.
9 – 2
... Flashing / ... 0.1sec BUZZER
DISPLAY INDICATOR PHONE
.
.
. CHECK No.
82 68 CHECK
34 56
9 No.
45
0 No.
67
.
R21LTF
