ProForm LX 360 User Manual

Hide thumbs

Advertisement

Table of Contents

Model No. PFTL39020
Serial No.
Serial Number
QUESTIONS?
If you have questions, or if there
are missing or damaged parts,
we will guarantee complete sat-
isfaction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Decal
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LX 360 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProForm LX 360

Summary of Contents for ProForm LX 360

  • Page 1 USER'S MANUAL Model No. PFTL39020 Serial No. Serial Number Decal QUESTIONS? If you have questions, or if there are missing or damaged parts, we will guarantee complete sat- isfaction through direct assis- tance from our factory. TO AVOID DELAYS, PLEASE CALL DIRECT TO OUR TOLL- FREE CUSTOMER HOT LINE.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .
  • Page 3 16. The treadmill is capable of high speeds. 20. Inspect and properly tighten all parts of the Adjust the speed in small increments to treadmill regularly. avoid sudden jumps in speed. 21. Never insert any object into any opening. 17. Never leave the treadmill unattended while it DANGER: is running.

  • Page 4: Before You Begin

    Thank you for selecting the revolutionary PROFORM Department toll-free at 1-800-999-3756, Monday ® LX 360 treadmill. The LX 360 treadmill combines ad- through Friday, 6 a.m. until 6 p.m. Mountain Time (ex- vanced technology with innovative design to help you cluding holidays).

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.

  • Page 6: Tween The Two Holes Points Upward. Thread The Wire

    3. Orient a Handrail Spacer (106) so that the arrow be- tween the two holes points upward. Thread the Wire Harness (42) through the upper hole in the Handrail Spacer as shown. Identify the Right Handrail (72), which has a large hole in the side near the upper end. Insert the Wire Harness into the Right Handrail and out of the large hole.
  • Page 7 6. Hold the Console (43) near the Console Base (47). Touch the Right Handrail (72) to discharge any static. Plug the widest connector on the Wire Harness (42) into the widest connector on the Console. If the connector does Ties not fit easily, rotate it and then connect it.

  • Page 8: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT an equipment-grounding conductor and a grounding plug. Plug the power cord into a surge suppressor, Your treadmill features a walking belt coated with and plug the surge suppressor into an appropriate PERFORMANT LUBE , a high-performance lubricant.
  • Page 9 CONSOLE DIAGRAM Displays Note: If there is a thin sheet of Pulse Sensor plastic on the console, remove it. Clip Insert the key fully into the console. After a moment, CAUTION: the displays will light. Test the clip by carefully tak- Before operating the ing a few steps backward until the key is pulled console, read the following precautions.
  • Page 10 To stop the walking belt, press the Stop button. continue to hold the Stop button for a moment. An The elapsed time will begin to flash in the “E” for English miles or an “M” for metric kilometers Time/Distance display. will appear in the Fat Calories/Calories/Pulse dis- play.

  • Page 11: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill. 1.
  • Page 12 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.

  • Page 13: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a.
  • Page 14 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.

  • Page 15: Conditioning Guidelines

    CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.

  • Page 16: Ordering Replacement Parts

    • The NAME OF THE PRODUCT (PROFORM ® LX 360 treadmill) • The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) • The KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the EXPLODED DRAWING and PART LIST...

  • Page 17: Part Identification Chart

    PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. 3/4” Screw (2)–8 1” Latch Screw (110)–2 1” Tek Screw (58)–4 Crossbar Screw 1/2” Silver (39)–2 Screw (49)–3 5/16”...
  • Page 18 PART LIST—Model No. PFTL39020 R1102A No. Qty. Description No. Qty. Description No. Qty. Description Hood Wire Harness Isolator Cushion 3/4” Screw Console Frame Motor Belt Wire Cover Releasable Tie Motor Tension Bolt Warning Decal Clamp Screw Flat Washer Bookrack Cable Tie Clamp Motor Star Washer Console Base Ground Wire...
  • Page 19 EXPLODED DRAWING—Model No. PFTL39020 R1102A...
