QuickSpecs
Overview
1.
Power button
2.
Headphone
3.
Microphone
4.
USB 2.0
1.
DisplayPort 1.1a
2.
VGA
3.
USB 2.0
4.
RJ-45 NIC
5.
AC power
6.
Security cable slot
Hardware features:
Texas Instruments TMS320DM8148 ARM® Cortex™-A8 (1 GHz, 256 KB L2 cache, 1 core) processor with Neon extensions
1 GB 400 MHz DDR3 SDRAM
FRONT
BACK
DA - 14266 Worldwide — Version 16 — April 25, 2014
HP t410 Smart Zero Client
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP t410

Summary of Contents for HP t410

  • Page 1 QuickSpecs HP t410 Smart Zero Client Overview FRONT Power button Headphone Microphone USB 2.0 BACK DisplayPort 1.1a USB 2.0 RJ-45 NIC AC power Security cable slot Hardware features: Texas Instruments TMS320DM8148 ARM® Cortex™-A8 (1 GHz, 256 KB L2 cache, 1 core) processor with Neon extensions 1 GB 400 MHz DDR3 SDRAM DA - 14266 Worldwide —...

  • Page 2: Warranty

    QuickSpecs HP t410 Smart Zero Client Overview 4 GB embedded Multi Media Card Flash memory 10/100/1000 Gigabit Ethernet (RJ-45) Supports up to 2 displays, 1 VGA, 1 DisplayPort 1.1a Supports resolutions up to 1920x1200 (60Hz) for single and dual displays. Actual performance and resolutions available will vary depending on client virtualization protocol being used and content being displayed.
  • Page 3 QuickSpecs HP t410 Smart Zero Client Overview contracts beyond your standard warranties. For more details visit: http://www.hp.com/go/lookuptool. DA - 14266 Worldwide — Version 16 — April 25, 2014 Page 3...

  • Page 4: Operating System

    Supports up to 2 displays; 1 VGA, 1 DisplayPort 1.1a with resolutions up to 1920x1200 for single or dual displays. Actual performance and resolutions available will vary depending on client virtualization protocol being used and content being displayed. CRT displays with resolutions greater than 1600x1200 (60Hz) are not compatible with the HP t410 Smart Zero Client.
  • Page 5 ICA with HDX Windows Server 2008 R2 SP1 or later VMware Horizon View through RDP Windows Server 2008 R2 SP1 or later SOFTWARE for HP t410 Smart Zero Client DA - 14266 Worldwide — Version 16 — April 25, 2014 Page 5...
  • Page 6 QuickSpecs HP t410 Smart Zero Client Technical Specifications Host Environment HP Smart Zero Technology Microsoft RemoteFX (RFX) Citrix VMware Horizon View PCoIP no longer supported Protocol Clients Smart Zero Citrix Receiver 12.1.4 Citrix Online Plugin 12.1.4 Microsoft Remote Desktop Client...

  • Page 7: Regulatory Compliance

    H2W22AT HP t410 Smart Zero Client with Teradici Optimized PCoIP H2W23AA HP t410 Smart Zero Client with, Citrix ICA/HDX, Microsoft RDP/RFX, and VMware Horizon View through RDP or PCoIP H2W23AT HP t410 Smart Zero Client with, Citrix ICA/HDX, Microsoft RDP/RFX, and VMware Horizon View through RDP or PCoIP DA - 14266 Worldwide —...

  • Page 8: Supported Printers

    QuickSpecs HP t410 Smart Zero Client Technical Specifications SUPPORTED PRINTERS The following printers have been tested and confirmed to work correctly with the t410 Smart Zero Client. Protocol Printer Citrix VMware PCoiP LaserJet, Single functional: LaserJet P2035 LaserJet P2055d InkJet, Single functional:...

  • Page 9: Energy Consumption

    QuickSpecs HP t410 Smart Zero Client Technical Specifications – Environmental Data ECO-LABEL CERTIFICATIONS & DECLARATIONS This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these markets: Energy Star®...

  • Page 10: Technical Specifications - Environmental Data

    The packaging for this product is 100% (by weight) recyclable when disposed of properly. RoHS COMPLIANCE Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations, including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis.
  • Page 11 Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards. End-of-life Management and Recycling Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/recycle or contact your nearest HP sales office.
  • Page 12 America and Asia-Pacific/Japan. © Copyright 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products and services are set forth in the express limited warranty statements accompanying such products and services.
