Specifications

Monitor Specifications
LCD Module
Viewable Image Size: 61.1 cm/24.0 inches
Native Resolution (Pixel Count): 1920 x 1200
Input Signal
Display Colours
Synchronization Range
Viewing Angle
Resolutions Supported
Active
Landscape: Horiz.: 518 mm/20.4 inches
Display Area
Portrait: Horiz.: 324 mm/12.8 inches
USB Hub
Speakers
Practical Audio Output: 1.0 W + 1.0 W
Power Supply
Current Rating
Dimensions
Height Adjustment: 110.0 mm/4.3 inches (Landscape condition)
Weight
Environmental Considerations
Operating Temperature: 5°C to 35°C / 41°F to 95°F
Storage Temperature: -10°C to 60°C / 14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
Technical specifications are subject to change without notice.
NOTE:
MultiSync EA241WM
Diagonal: 61.1 cm/24.0 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level Positive/Negative
Composite sync.TTL Level Positive/Negative
Sync on Green (Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
16,777,216
Horizontal: 31.5 kHz to 81.1 kHz (Analog)
31.5 kHz to 81.1 kHz (Digital)
Vertical: 56.0 Hz to 76.0 Hz (Over SXGA: 60Hz) Automatically
Left/Right: ±
85°
(CR > 10)
Up/Down: ±80° (CR > 10)
720 x 400*
640 x 480*
800 x 600*
832 x 624*
1024 x 768*
1152 x 870*
1280 x 1024*
1400 x 1050*
1440 x 900*
1600 x 1200*
1680 x 1050*
1920 x 1200 at 60 Hz.......................... resolution for optimal display performance.
Vert.: 324 mm/12.8 inches
Vert.: 518 mm/20.4 inches
I/P: USB Specification Revision 2.0
Port: Upstream 1
Downstream 4
Load Current: Maximum 0.5A per port
AC 100-240 V ~ 50/60 Hz
1.25-0.65 A (with USB and Audio)
Landscape: 558.6 mm (W) x 437.0 - 547.0 mm (H) x 272.4 mm (D)
22.0 inches (W) x 17.2 - 21.5 inches (H) x 10.7 inches (D)
Portrait: 366.2 mm (W) x 574.1 - 646.7 mm (H) x 272.4 mm (D)
14.4 inches (W) x 22.6 - 25.4 inches (H) x 10.7 inches (D)
72.6 mm/2.8 inches (Portrait condition)
10.5 kg (23.1 lbs)
Humidity: 20% to 80%
Altitude: 0 to 6,562 Feet / 0 to 2,000 m
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet / 0 to 12,192 m
1
: VGA text
1
@ 60 Hz to 75 Hz
1
@ 56 Hz to 75 Hz
1
@ 75 Hz
1
@ 60 Hz to 75 Hz
1
@ 75 Hz
1
@ 60 Hz to 75 Hz
1
@ 60 Hz
1
@ 60 Hz
1
@ 60 Hz
1
@ 60 Hz
English-14
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.270 mm dot pitch;
400 cd/m
2
white luminance; 1000:1 contrast ratio,
typical.
Digital Input: DVI-D with HDCP
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes listed.
NEC DISPLAY SOLUTIONS cites recommended
