To view tracks that are stored in MOJO 1's memory:
1. Run MoodLogic.
2. Power ON MOJO 1 and using the USB cable, connect MOJO 1 to your PC.
3. Click MoodLogic's MP3 PLAYER tab to view the contents of MOJO 1's memory.
4. Click REFRESH to ensure that the displayed information is current.
Navigating Activated Tracks by Genre, Tempo, Year and Mood
After tracks have been activated, they can be navigated by genre, tempo, year and mood. See below for details.
To navigate by genre:
The genres of your tracks are listed in the GENRE box.
• Click a genre to view tracks in that genre in the TRACK LIST window.
• Click ANY GENRE to view tracks in all genres in the TRACK LIST window.
To navigate by tempo:
Tempo is the speed of music, also known as beats per minute (BPM).
• Click the TEMPO checkbox and adjust the left (minimum desired tempo) and right (maximum desired tempo) sliders to view
tracks with the desired tempo(s) in the TRACK LIST window. For example, for medium to fast tracks, keep the left slider in the
middle and move the right slider to the far right. Only tracks that have tempos in the desired range will be displayed in the
TRACK LIST window.
To navigate by year:
This filter sorts music by when it was released.
• Click the YEAR checkbox and adjust the left (earliest release date) and right (latest release date) sliders to view tracks
released in the desired range of years in the TRACK LIST window. For example, to view or listen to tracks from the 80s, put the
left slider on 80 and the right slider on 90. MoodLogic will display your tracks that were released within that range of years in
the TRACK LIST window.
To navigate by mood:
Unlike most applications MoodLogic can sort your activated tracks by mood.
• Select the mood or moods of the tracks that will be displayed in the TRACK LIST window. For example, to view or listen to
tracks with hard, aggressive beats, click AGGRESSIVE.
NOTE : From the My Music screen (see above), you can navigate activated tracks by any combination of
criteria. For instance, you could navigate by alternative tracks that have a fast tempo and were released in the '90s.
27
CONFIGURING FM RADIO PRESETS
The included MOJO 1 PC Software is used to program MOJO 1's FM radio presets. It can also be used to erase MOJO 1's memory
and to upgrade the firmware should a firmware update become available.
NOTE : After connecting MOJO 1 to your computer and running this software, a list of presets currently stored on MOJO 1 will
appear in the RADIO PRESET ORGANIZER LIST. Presets 1-20 must be programmed using this software. Presets 21-25 must be
programmed with MOJO 1's controls, as described in the"Using Mojo 1" section.
To run the MOJO 1 PC Software:
1. Click the MOJO 1 PC Software desktop icon.
OR
In Windows, click START, PROGRAMS, MOJO 1 UTILITY TOOLS, MOJO 1 PC SOFTWARE.
To set MOJO 1's preset FM radio stations:
1. With MOJO 1 connected to your PC and powered ON, run the MOJO 1 PC Software.
2. Use the STATION SLIDER and/or the LEFT and RIGHT ARROWS to select the desired radio station.
STATION SLIDER
3. When the desired station is displayed, click ADD TO LIST to add the station to the RADIO PRESET ORGANIZER list.
RADIO PRESET ORGANIZER LIST
4. Repeat steps 2 and 3 to add additional stations.
& UPGRADING FIRMWARE
