Summary of Contents for TDK mojo
- Page 2 SAFETY CAUTION! This product uses a Class 1 laser. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Do not open covers and do not repair yourself. Refer servicing to qualified personnel. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
- Page 3 LISTENING PRECAUTIONS Do not use while operating motorized or wheeled vehicles. You should use • extreme caution and discontinue use in potentially hazardous situations. Do not play headphones at high volume. If you experience a ringing in your • ears, reduce volume or discontinue use immediately. Do not turn up the volume to the point that you can’t hear what’s around you.
- Page 4 NAVIGATING THE MOJO MANUAL OPTION 1: Toggle between the TABLE OF CONTENTS and specific topics. 1. Clicking on the desired subject heading takes you to it's location in the manual. 2. Clicking on a page number within the manual takes you back to the T able of Contents.
-
Page 5: Table Of Contents
CONTENTS Intro: MOJO At A Glance....................1 About Software........................ 1 System Requirements..................... 2 Handling Instructions..................... 2 Cleaning and Servicing....................2 Using and Replacing Batteries..................3 Power Sources......................... 3 Your MOJO Player......................4 Controls.......................... 4 Setting up MOJO......................6 Using Your MOJO......................7 Playing Audio CDs...................... -
Page 6: Intro: Mojo At A Glance
CD-R/RW discs any way you find most convenient. To use MOJO’s Dire c t o ry function you need to set up a dire c t o ry stru c t u re on your C D - R / RW disc. -
Page 7: System Requirements
Do not use liquid or aerosol cleaners. • Clean your MOJO with a soft cloth. Clean the laser lens using a soft brush • such as a camera brush. Do not service the system yourself. Do not modify batteries. Servicing •... -
Page 8: Using And Replacing Batteries
USING AND REPLACING BATTERIES Insert batteries according to the polarity markings in the MOJO player’s battery compartment. (see page 6) Handle leaking batteries with rubber gloves. • Dispose of used batteries as required by local ordinances or regulations. • Keep batteries out of reach of children. -
Page 9: Your Mojo Player
YOUR MOJO PLAYER Included with your MOJO CD-MP3 Digital Jukebox are: AC Adapter • Software Disc with TDK Navitrack PC Software and MusicMatch Jukebox • Headphones • Operations Manual • 2 AA Batteries • CONTROLS: THE 4-LINE LCD DISPLAY - Shows all MP3 and Audio CD information, including: 1. -
Page 10: Option
[ SELECT ] button - 1. Used to finalize a choice from the menu. 2. Press to rotate through RANDOM modes during playback. [ REMOVE ] button - 1 . Used to select what will be deleted from your playlist when in the playlist menu. 2. -
Page 11: Setting Up Mojo
Insert the (supplied) batteries into the MOJO, following the polarity markings inside the battery compartment. Using the headphones 1. Insert the headphones into the headphone jack on the side of your MOJO. 2. Make sure volume control is set low to avoid hearing damage. 3. Press PLAY. -
Page 12: Using Your Mojo
USING YOUR MOJO TIP: Getting the most out of MOJO’s navigation capabilities requires you to convert all filenames into the FIF format using the supplied Navitrack software. To maximize the DIRECTORIES function, it is important to store all of your MP3 files in directories on your hard drive and burn your CDs using folders rather than individual songs. -
Page 13: Playing Mp3 Cds
PLAYING MP3 CDS NOTE: The unit remembers the last song played and the playback settings of up to three MP3 CDs. To select a Song by Artist, Title, Genre or Directory: 1. Press the MODE button. 2. Highlight ‘Song Select’ and press NEXT. 3. -
Page 14: Selecting An Entire Directory Within A Playlist
To select an entire directory within a playlist 1. Press the MODE button. 2. Highlight ‘Song Select’ and press NEXT. 3. Scroll down to DIRECTORY, press NEXT. 4 . S c roll down to the folder or folders you want and press SELECT to select it. (when the dire c t o ry has been selected, its icon will appear filled in instead of hollow. -
Page 15: Adding And Removing Items From Your Playlist
Adding and removing items from your playlist Selected items will have the icon in front of it filled in. Removed items will have the icon in front of it hollowed out. The first time you insert a new CD, all the songs on that CD will be in your playlist. 1. -
Page 16: Adjusting System Settings
(LOCK icon disappears) HOLD activated HOLD deactivated CHANGING EQ SETTINGS You can adjust the EQ settings of your MOJO to suit your listening tastes. 1. Quickly press REMOVE to toggle through the different EQ settings during playback mode. - or - 2. -
Page 17: Changing Repeat Modes
CHANGING REPEAT MODES Normal - Plays straight through the playlist and stops. Repeat 1 - Repeats one song from the playlist infinately. Repeat All - Repeats the playlist infinately. Random - Randomly picks songs from the playlist. 1. In the main display, quickly press SELECT to toggle through different Repeat Modes during playback. -
Page 18: Setting The Bass
SETTING BASS ON/OFF 1. Press and hold the REMOVE button to turn the bass ON/OFF. - or - 2. Press MODE. 3. Scroll down to BASS, press NEXT. 4. Select ON or OFF and press SELECT. 5. Press MODE to save and return to the main display. 3. -
Page 19: Setting The Backlight Display
SETTING BACKLIGHT DISPLAY You can set the display screen’s backlight to 3 Secs ON, Always ON, or Always OFF after a button is pressed. To adjust the backlight display options: 1. Press MODE. 2. Scroll down to SYSTEM, press NEXT. 3. -
Page 20: Setting Autoplay
SETTING AUTOPLAY The AutoPlay feature begins playback of your CDs as soon as you put it in your MOJO player. The AutoPlay default setting is ‘ON’. To set AutoPlay: 1. Press MODE. 2. Scroll down to SYSTEM, press NEXT. 3. Scroll down to AUTOPLAY, press NEXT. -
Page 21: Setting Contrast
5. Press SELECT then MODE to save and return to the main display. 2. SYSTEM select 3. CONTRAST settings RESETTING TO SYSTEM DEFAULTS At any time, you can reset your MOJO to its original, factory set defaults. System Defaults: Repeat-Off, EQ-Normal, Bass-Off, ESP-ON (audio CD), FIF Mode-On. 1. Press MODE. -
Page 22: Setting Fif Or Id3
SETTING FIF OR ID3 NOTE: The FIF mode lets MOJO scan, sort and navigate by the information contained in the filename area of a properly named MP3 file. Use the Navitrack software to make full use of MOJOs navigation by c o n v e rting your MP3s to FIF compatible MP3s. -
Page 23: Using Tdk Navitrack Software (Pc)
TDK Navitrack Software arranges your MP3 filenames into a format that allows MOJO to easily read sort and organize your songs. This file format is called FIF (Field In Filename). Although the file is renamed in the Navitrack software, the actual file will have an MP3 file extension and can be played with any MP3 player or software. -
Page 24: Converting Songs To An Fif Compatible Format
Artist, Title and Genre If you select the Art i s t - Title format, that information will be copied into the MP3’s new filename. This will eliminate your ability to search by Genre with MOJO. Setting a FIF Type The default FIF Type is set to recognize filenames as “ARTIST-TITLE-... -
Page 25: Selecting Songs To Convert To An Fif Compatible Format
SELECTING SONGS TO CONVERT TO AN FIF COMPATIBLE FORMAT Using the navigation frame on the left side of the screen, select the • folder that holds your MP3s. Your MP3 files will appear in the display window on the right side. •... - Page 26 To deselect a song,uncheck the box next to the song. • - or - To deselect all songs, press the “CLEAR ALL” button. • NOTE: A selected song will have a check in the box, a song that has not been selected will not have a check in the box. After you have selected the songs you want to convert, p ress the Display Final List Button which will take you to the Conversion Scre e n .
-
Page 27: Converting Songs Manually
If there are songs in the Auto Convert List press the AUTO CONVERT button. • These MP3s will be converted to FIF compatible files. If you have songs in the Manual Convert List, see the section below titled • “Converting Songs Manually.” All songs that were converted will now have an “F”... -
Page 28: Saving Before Burning
SAVING BEFORE BURNING After conversion is complete, the original MP3 will also be recognized as a FIF compatible file. If you would like to save and copy your selected songs into folders or other directories, follow these steps: NOTE: Saving songs using the Navitrack program will actually make another copy of your file. -
Page 29: Troubleshooting
Completely close CD lid. • • SYMPTOM: Sound skips CAUSES: SOLUTIONS: Dirty disc Clean disc. • • Optical lens is dirty. Carefully clean the lens as prescribed • • in the manual. Excessive jolting. Place MOJO on a stable surface. • •... -
Page 30: Specifications
FIF mode. Use the Navitrack software to make FIF • compatible MP3s. SYMPTOM: MOJO doesn’t play all the songs on my mixed CD SOLUTIONS: CAUSES: Burn data-only or audio only CDs. If burning a mixed CD, the audio is •... -
Page 31: Warranty
Product is discontinued and no longer available, then it may be re p l a c e d with Product determined by TDK to be of similar value and perf o rm a n c e . TDK does not warrant that the operation of the Product will be uninterrupted or error free. - Page 32 EXCLUSIVE REMEDIES. TDK’S LIABILITY UNDER ANY LEGAL THEORY FOR ANY LOSS OR DAMAGE IN ANY WAY RELATED TO THE PRODUCT SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCT. IN NO EVENT SHALL TDK BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT.
