This is

X-10 POWERHOUSE

Mini Timer (MT522)
Instantly controls up to eight X-10 mod-
ules and programs up to four modules to
turn on and off at specific times. Can
turn lights on at random times for added
security. Dims lights too!
Home Automation Interface (CP290)
Set up from an IBM, Mac, Apple IIe/IIc
or Commodore 64/128 computer and
then disconnected. It doesn't tie the com-
puter up. Controls up to 256 Modules. 7
day timer can be set for 128 timed
events. Software included.
Maxi Controller (SC503)
Controls up to 16 modules from any-
where in the house. Has All Lights On
button and dims lights too!
Mini Controller (MC460)
Compact unit allows you to control up to
eight modules from anywhere in the
house. Has All Lights On button and
dims lights too!
SUNDOWNER T M (SD533)
Turns on up to 4 modules at dusk and
turns them off again at dawn. Also has
all the features of the Mini Controller.
Telephone Responder (TR551)
Plugs into a regular phone jack and con-
trols up to 10 X-10 modules from any
touch-tone phone in the world. Can also
flash lights when the phone rings.
Lamp Module (LM465)
Can be turned on and off and even
dimmed from X-10 controllers. Rated for
300W. Incandescent lamps only.
Appliance Module (AM486 - 2 pin)
(AM466 - 3 pin grounded)
For turning on an air conditioner, coffee
pot, TV, stereo, and so on. Rated at 15A
resistive (for coffee pots etc.), 1/3 HP for
motors, 5OOW for lamps.
Split Receptacle Module (SR227)
Replaces your existing outlet and works
like an Appliance Module. Rated at 15
Amps unrestricted, Top outlet is con-
trolled, bottom one is a regular outlet.
Wall Switch Module (WS467)
Replaces your existing wall switch and in-
stalls like a dimmer. Rated at 500W max.
60W min. incandescent lamps only.
3 - Way Wall Switch (WS4777)
For controlling a light which is presently
controlled by two switches. Rated at 500W
max. 60W min. incandescent lamps only.
Heavy Duty Appliance Modules
(HD243 - 220V, 15A)
(HD245 - 220V, 20A)
For controlling 220V room air condition-
ers, water heaters etc. For single phase or
split phase 110/220V wiring only (not suit-
able for 3 phase wiring).
Universal Module (UM506)
Momentary or sustained dry contact clo-
sure to control low voltage items such as
sprinkler systems etc. Also contains a
beeper to use as an annunciator. Works
with all X-10 Controllers and Timers (ex-
cept BR52 1, BC53 1 and ND65 1).
