Page 1 Owner’s Manual Diesel and Electric Heating System for Recreational Vehicles...
Page 2 ITR reserves the right to modify or change without notice, materials, applications, equipment, accessories, and/or prices. All measurements and weights are approximate. Copyright © 2011 International Thermal ® OASIS is a registered trademark of International Thermal Research Ltd. - 2 - The OASIS Owner’s Manual...
Page 3 Telephone__________________________ Email______________________________ Motorhome Model______________________________________________________ Date of Motorhome Purchase_____________________________________________ Dealer’s Name_______________________________City_______________________ OASIS Serial Number____________________________________________________ Owner’s Signature_________________________________ Date________________ NOTE: This warranty card must be filled in completely, signed and returned to ITR within 30 days of the motorhome purchase. This warranty is not transferable by the owner.
Page 4 - 4 - The OASIS Owner’s Manual...
Page 5: Table Of Contents
Features of your OASIS Heating System ....... 7 • Operating Instructions for the OASIS Heating Module ..... 9 • Turning the Power to the OASIS Heating Module ON ....9 • Activating the Burner (Primary) and AC Heat (Secondary) from the Remote Operating Panel ........9 •...
Page 6 - 6 - The OASIS Owner’s Manual...
Page 7: Features Of Your Oasis Heating System
Heating System. READ THIS MANUAL AND SAVE IT FOR REFERENCE. Features of Your OASIS Heating System The OASIS Heating Module uses a diesel burner (12 VDC) controlled by a multi- functional electronic controller as the primary source of heating coolant fluid (anti- freeze and water).
Page 8 Heating Module as well as protecting your warranty. Your model can be identified by locating the serial number label on the outside case of the OASIS Heating Module. The serial number identifies the model type through the first series of letters and numbers.
Page 9: Operating Instructions For The Oasis Heating Module
! DANGER recognized as safe ”GRAS” by the FDA in the OASIS Heating Module and Distribution Module. The OASIS exhaust is hot; do not park in areas such as tall dry grassy fields, as a fire may result. Activating Burner...
Page 10: Activating The Cabin Fan Heaters Through The Thermostats
OASIS Heating Module will turn ON after ten seconds. The Burner LED will turn ON when the diesel burner has been activated. The burner will continue to operate until the coolant in the OASIS Heating Module reaches the set operating temperature range.
Page 11: Activating The Engine Heat & Preheat Function
Turn the burner switch on the Remote Operating Panel to the ON position. The OASIS Heating Module will come up to the set operating temperature range and will cycle OFF. The heat from the vehicle engine will be transferred from the engine to the domestic water and space heating loop.
Page 12: Functions Of The Heating Module Control Panel
OASIS™ Heating Module Control Panel located on the front of the OASIS™ Heating Module. There are indicator LED’s on the panel that are used for diagnostics. Refer to the description of the OASIS Heating Module Control Panel for further details.
Page 13: Functions Of The Distribution Module Zone Control Panel
The voltage fault LED (Red) turns ON when a voltage fault has been detected. Low Water (Red) • The Low Water LED (red) turns ON when a low coolant level in the OASIS Heating Module has been detected. Functions of the Distribution Module Zone Control Panel •...
Page 14: Maintenance
• The major components such as the air compressor, fuel pump, fuel nozzle, and combustion air fan should be examined for wear and should be replaced by the service technician as required. - 14 - The OASIS Owner’s Manual...
Page 15: Protecting The Heating Module And Distribution Module
The combustion tube should be inspected by the service technician for wear and replaced if necessary. To access the combustion tube, the front panel of the OASIS must be removed along with the burner box cover. The fuel block must then be removed from its mounting position. Finally, the burner and counter- flow tube must be taken out by removing the nuts holding the burner box in position.
Page 16: Customer Service Contact
IN THE UNITED STATES: 2431 Simpson Road Suite B, 11915 56 Circle Richmond, BC, Canada V6X 2R2 Vancouver WA USA 98682 Tel: 1-800-755-1272 or 604-278-1272 Tel: 1-800-993-4402 or 360-993-4877 Fax: 604-278-1274 Fax: 360-993-1105 Email: info@itrheat.com - 16 - The OASIS Owner’s Manual...
Page 17: Warranty Information
ITR within 30 days of the date of the initial “in-service” date. General Warranty ITR warrants the OASIS® CH50, AND OASIS® COMBI (referred to as “heater(s)”) DISTRIBUTION MODULE and all accessories or other supplied components with the original purchase to be free of defects in materials and workmanship under design usage and service conditions for ONE (1) year from the heater “in-service”...
Page 18: Not Covered Under Warranty
• Travel time and expenses by an ITR dealer. • Removal and re-installation expenses for the ITR heater. - 18 - The OASIS Owner’s Manual...
Page 19 Factory repairs or replacement will be done as quickly as possible, with an estimated turnaround of five working days. All repairs done under warranty are subject to the terms and conditions of the flat-rate schedule. International Thermal Research Ltd. - 19 -...
