Wiper Blades
RELEASE BUTTON
2.
Disconnect the blade assembly
from the wiper arm by pushing in
the release button. Then slide the
blade assembly out of the wiper
arm.
322
RELEASE TAB
COVER
3.
Pull up the cover release tab on
the end of the blade assembly,
then remove the cover.
BLADE
HOLDER
4.
Slide the blade out of the holder.
