Chord U-SERIES User Manual

Uhf wireless systems
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

U-SERIES
UHF Wireless Systems
User Manual
Version 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Chord U-SERIES

Summary of Contents for Chord U-SERIES

  • Page 1 U-SERIES UHF Wireless Systems User Manual Version 2.0...
  • Page 2 Introduction Thank you for choosing the Chord UHF-series wireless system. This professional wireless set provides a high quality microphone with UHF radio system for freedom of movement without loss of audio quality. Please read this manual before using this equipment in order to avoid damage through incorrect operation and to get the best performance from your purchase.

  • Page 3: Handheld Transmitter

    Handheld Transmitter Bodypack Transmitter 1. Windshield UHF antenna 2. Slide switch – OFF/MUTE/ON LED power indicator 3. Battery compartment cover Slide switch OFF/MUTE/ON MIC input, threaded 3.5mm jack Frequency label GAIN ADJUST rotary Battery compartment Receiver Rear Panel 1. Antennae 2.

  • Page 4: Operation

    Operation For handheld transmitters, insert the supplied 2 x AA batteries by carefully unscrewing the base to reveal the battery compartment inside the microphone body, connect the batteries (ensure + and - are the correct way round for each cell) and carefully screw the base back on. For bodypacks, squeeze down the clip in the centre of the front panel of the bodypack to unfasten the lower half, which hinges outwards to reveal the battery compartment.

  • Page 5: Specifications

    Specifications Carrier type UHF 863 - 865MHz Frequency stability ±0.005% Maximum deviation ±25kHz Audio frequency response 40Hz – 20kHz Signal to noise ratio >105dB Audio dynamic range >80dB T.H.D. <0.5% @ 1kHz Maximum range Operating temperature -10ºC to +50ºC Receiver Power supply 12 - 18Vdc 500mA (mains adapter supplied) Audio outputs...

  • Page 6: Troubleshooting

    Frequency Chart (all regions) Model Stock code Mic 1 Mic 2 171.822 863.1MHz 171.823 864.1MHz 171.825 863.3MHz 864.3MHz 171.826 863.8MHz 864.8MHz 171.838 863.1MHz 171.839 864.1MHz 171.827 863.3MHz 864.3MHz 171.828 863.8MHz 864.8MHz 171.820 863.3MHz 864.3MHz UHN2 171.821 863.8MHz 864.8MHz 171.846 863.1MHz 171.847 864.1MHz Troubleshooting...

This manual is also suitable for:

U seriesUh1Uh2Un1Un2Uhn2 ... Show all
