CUISINART™ C560S
Assembly Manual
85-3030-8 (G41208) Propane
85-3031-6 (G41209) Natural Gas
LiMited 5-YeAr WArrAntY
read and save manual for future reference.
Assemble your grill immediately.
Missing or damaged parts should be
claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-800-309-3452.
www.cuisinartbbqs.com
Manual Revision #: 22102010 PD

Advertisement

loading
Need help?

Need help?

Do you have a question about the C560S and is the answer not in the manual?

Questions and answers

Summary of Contents for Cuisinart C560S

  • Page 1 CUISINART™ C560S Assembly Manual 85-3030-8 (G41208) Propane 85-3031-6 (G41209) Natural Gas LiMited 5-YeAr WArrAntY read and save manual for future reference. Assemble your grill immediately. Missing or damaged parts should be claimed within 30 days of purchase. For product inquiries, parts, warranty and troubleshooting support, please call 1-800-309-3452.
  • Page 2: Hardware Pack

    HARDWARE PACK No. Description Part Number Quantity tOOLS needed FOr ASSeMBLY ¼"-20UNCX13 Screw 20120-13013-250 • #2 Phillips screwdriver (long and short) ¼"-20UNCX38 Screw 20120-13038-250 • ¼” Slotted screwdriver (long and short) ¼"-20UNCX16 Screw 20120-13016-250 ø7 Lock Washer 41400-07000-250 • Adjustable wrench ø7 Washer 40300-07000-250 •...
  • Page 3 PARts List (PRoPAnE) foR 85-3030-8 (G41208) EXPLoDED DiAGRAM (PRoPAnE) foR 85-3030-8 (G41208) Item No. Quantity Description Part No. Top Lid G412-6300-01 Lid Handle G412-0035-01 Thermometer G512-0085-01 Screw for Top Lid G501-0005-02 Lid Bumper G508-0063-01 Burner Box Weldment G412-6500-01 Rear Panel, Burner Box G416-0013-01 Upper Side Panel - Left G412-1700-01...
  • Page 4 PARts List (nAtuRAL GAs) foR 85-3031-6 (G41209) EXPLoDED DiAGRAM (nAtuRAL GAs) foR 85-3031-6 (G41209) Item No. Quantity Description Part No. Top Lid G412-6300-01 Lid Handle G412-0035-01 Thermometer G512-0085-01 Screw for Top Lid G501-0005-02 Lid Bumper G508-0063-01 Burner Box Weldment G412-6500-01 Rear Panel, Burner Box G416-0013-01 Upper Side Panel - Left...
  • Page 5: Assembly Instructions

    AssEMBLY instRuCtions AssEMBLY instRuCtions Separate the 2 different types of wheels, 2 Assemble the left and right pillars (DG), to the locking wheels (DJ) and 2 regular wheels (DK). cart side panels, as shown in figure A and B. Insert the U Pin (#10) into one of the regular wheels (DK), as shown in image B.
  • Page 6 AssEMBLY instRuCtions AssEMBLY instRuCtions Attach the right side shelf fascia(DD) to the right tHiS SteP reQUireS 3 Or MOre PeOPLe. dO nOt AtteMPt ALOne. eXtreMeLY side shelf (DC). HeAVY. Front Position the top lid and burner box assembly (A and B) onto the cart assembly (C) as shown. in figure A.
  • Page 7 AssEMBLY instRuCtions AssEMBLY instRuCtions Attach the left side burner shelf fascia (DB) to the Remove the hardware that is pre-assembled to Front left side burner shelf table (DA). the side burner valve bracket (Cl1), as shown in figure B. Insert the side burner valve stem through the rear of the left side shelf fascia(DB).
  • Page 8 AssEMBLY instRuCtions AssEMBLY instRuCtions Place the heat shield (CG) into the groove which a. Use the side burner Venturi clip (#14) to is located at the back side of the front panel as connect the side burner (CM) to the side shown in figure A.
  • Page 9 AttentiOn: For your families safety, do not attempt to light this BBQ until you have reviewed pages 4-7 of the Cuisinart™ Safe Back view Use and Care Manual. All Safety and leak test b. Place the grease cup (CI) onto the tracks,...
