RME Audio HDSP 9632 Brochure & Specs page 2

Features
The HDSP 9632 provides unique features:
- Balanced stereo analog in- and output, 24-Bit/192kHz, > 110 dB SNR
- Optional analog expansion boards with 4 balanced in- or outputs
- All analog I/Os capable of 192 kHz, constant number of available channels
- 1 ADAT digital I/O, supporting 96 kHz S/MUX operation
- 1 SPDIF digital I/O, 192 kHz-capable
- 1 Breakout cable for coaxial SPDIF*
- Up to 16 I/Os can be used simultaneously!
- 1 Stereo headphone output, parallel to the analog out, additional level settings
- 1 MIDI I/O with 16 channels of hi-speed MIDI via breakout cable
- DIGICheck, RMEs unique metering- and analysing tool
- HDSP Meter Bridge: freely scalable level meters, peak- and RMS calculation directly in hardware
- TotalMix: 512 channel Mixer with 40 Bit internal resolution
* The HDSP 9632 ships in a basic version including two RCA/phono breakout cables (headphone: TRS jack).
Therefore all analog I/Os and the SPDIF I/O are unbalanced. XLR breakout cables are available as an option
(headphone: Neutrik TRS locking jack), turning analog and AES/EBU into balanced mode.
HDSP 9632 debuts SteadyClock (TM), a newly developed clock technology, combining professional features like
maximum jitter suppression at full varipitch capabilities and software controlled sample rates.
Settings
Just click on the hammer symbol in the systray of the taskbar and the settings dialog of the HDSP 9632 comes up. The clear structured, easy to understand window plus the unique
informative status windows for input signal, clock mode and sample rate make your work with Hammerfall DSP to a real pleasure.
When working with several digital sources it is not only necessary to know if these are properly locked, but also if they are totally synchronized. RMEs exclusive SyncCheck® checks all
input signals and displays their actual state, and thanks to our Intelligent Clock Control (ICC) concept you have all clocks and states under control - with ease.
The optional 9632 Word Clock Module provides a galvanically isolated word clock input and two word clock outputs via BNC jacks. Compared to the well-known DIGI96/8 series, the
HDSP 9632 not only offers a further improved analog interface, but also all the features of the award-winning Hammerfall DSP series: All inputs and outputs simultaneously available,
MIDI I/O and TotalMix, the DSP-based realtime mixer/router. Hardware updates through software and driver updates are risk-free thanks to the Secure BIOS Technology.
In short: The HDSP 9632 is the ultimate audio interface for PC or Mac, digital or analog.
